P83302-005 HPE Proliant Dl380 Gen11 Intel Xeon Gold 16-core 2.0GHz 2U Rack-Mountable Server

HPE Proliant DL380 Gen11 Server Overview

The HPE P83302-005 Proliant DL380 Gen11 is a high-performance 2U rack-mountable server designed for enterprise workloads. Powered by an Intel Xeon Gold 16-core 2.0GHz processor, this server delivers reliable, scalable, and efficient computing for critical business applications.

Key Specifications

• Model: P83302-005
• Processor: 4th Gen Intel Xeon Gold 5416s, 16 cores, 2.0 GHz base clock
• Memory: 64 GB DDR5 SDRAM (2x32 GB) expandable up to 8 TB
• Internal Storage: 2x 960 GB SATA SSDs, 8 SFF hot-swap bays
• Power Supply: Dual 1000W Flex Slot Platinum, hot-plug capable
• Network: Broadcom BCM57416 10Gb Ethernet, 2 ports
• Form Factor: 2U rack-mountable, 2-way scalable

Processor & Chipset Features

• Intel Xeon Silver 5416s CPU, upgradable to 2 processors
• Supports Hyper-Threading and Intel Turbo Boost Technology
• Max Turbo Frequency: 4.0 GHz
• Socket Type: Intel 4677, Chipset: Intel C741

Cache Memory

• Smart Cache: 30 MB per processor
• Optimized for high-performance server workloads

Memory Configuration

• Installed RAM: 64 GB DDR5 SDRAM, speed up to 4800 MHz
• Total DIMM slots: 32 (30 available)
• Supports HPE SmartMemory and ECC reliability
• Memory expandability: 3.0 TB load-reduced, 1.5 TB registered, 192 GB NVDIMM

Internal Storage & Controllers

• 2x 960 GB SATA SSDs for high-speed data access
• HPE MR416i-o Gen11 Storage Controller with 8 GB cache
• RAID support: 0, 1, 5, 6, 10, 50, 60
• Interfaces: SATA-600, SAS 3.0, PCIe NVMe

Additional Storage Features

• 8 hot-swap 2.5" bays, 6 empty for expansion
• External universal media bay for removable storage

Networking & Remote Management

• Broadcom BCM57416 10Gb 2-port Ethernet adapter
• Supports Gigabit, Fast Ethernet, and advanced networking protocols
• Remote management via Integrated Lights-Out 6 (iLO6)
• Wake-on-LAN (WOL) and PXE boot support

Expansion Slots & Connectivity

• 2 FlexibleLOM slots for additional network adapters
• PCIe 5.0 x16 slots (full-length/full-height and half-length/full-height)
• USB 3.0 ports (front, rear, internal) and VGA output
• RJ-45 LAN and iLO service port for remote administration

Power & Energy Efficiency

• Dual 1000W hot-plug power supplies with redundancy (1+1)
• 80 Plus Titanium certified for maximum efficiency
• Supports AC input: 100–120V / 200–240V, 50/60 Hz
• Energy Star 3.0 certified for sustainability

Compliance & Environmental Standards

• Compliant with AES, FIPS 140-2, TLS v1.2, and low halogen standards
• ASHRAE Class A3/A4, WEEE 2002/95/EC, ACPI 6.3, ERP Lot 9
• Operating temperature: 50–95 °F, Humidity: 8–90% RH (non-condensing)

Dimensions & Weight

• Width: 17.6 in | Depth: 28.6 in | Height: 3.4 in
• Weight: 35.27 lbs

Operating System & Software Support

• OS Certified: Microsoft Windows Server, Red Hat Enterprise Linux, VMware ESXi, Oracle Linux, Ubuntu, Citrix
• UEFI server firmware preinstalled
• No OS pre-installed (BTO configuration)

Performance and Efficiency

This server provides exceptional processing power and energy efficiency, making it suitable for demanding virtualized environments, data analytics, and mission-critical enterprise applications.

• Optimized for multi-threaded workloads
• Energy-efficient design reduces operational costs
• Supports virtualization and cloud deployment
• High memory bandwidth for faster data processing

Advanced Security Features

The HPE DL380 Gen11 incorporates robust security mechanisms to safeguard sensitive data and maintain system integrity.

• Secure boot and firmware validation
• Trusted Platform Module (TPM) support
• Enhanced intrusion detection and monitoring
• Role-based access control for administrators

Scalable Storage Options

Flexible storage configurations allow businesses to scale based on workload requirements.

• Supports both SSD and HDD drives
• Hot-swappable drive bays for uninterrupted operation
• RAID configurations for data redundancy and performance
• Expandable storage capacity as business grows
