P83314-005 HPE Proliant Dl380 Gen11 Xeon 32-core Gold 2.1GHz DDR5 2U Rack-Mountable Server

HPE P83314-005 Proliant DL380 Gen11 Overview

The HPE P83314-005 Proliant DL380 Gen11 is a powerful 2U rack-mountable server, equipped with Intel Xeon 32-core Gold processors, DDR5 memory support, and optimized for demanding enterprise workloads.

General Information

• Manufacturer: Hewlett Packard Enterprise
• Model Number: P83314-005
• Server Type: 2U Rack-Mountable
• Scalability: Dual-processor capable
• Hot-swap Drive Bays: 8 SFF
• Power Supply: Dual 1000W Flex Slot Platinum, hot-pluggable

High-Performance Processor Features

Intel Xeon 32-Core Gold 6530

• Base Clock Speed: 2.1 GHz, Turbo up to 4.0 GHz
• Hyper-Threading and Intel Turbo Boost Technology
• Socket: Intel 4677, Chipset: Intel C741
• Single CPU Installed, expandable to 2 CPUs

Cache Memory Configuration

• Intel Smart Cache: 160 MB per processor
• Optimized for high-speed data access and reduced latency

Memory Specifications

DDR5 SDRAM Modules

• Installed Memory: 64 GB (2x32 GB)
• Maximum Supported: 8 TB
• Memory Speed: 4800 MHz effective, 5600 MHz rated
• Form Factor: 288-pin DIMM
• Slots: 32 total (30 empty), HPE Smart Memory supported

Internal Storage Options

High-Speed SSD Drives

• Type: SATA SSD
• Capacity: 960 GB per drive, 2 drives installed
• Hot-swappable and easily expandable

Advanced Storage Controller

HPE MR416i-o Gen11

• Interface: Serial ATA-600 / SAS 3.0 / PCIe
• Cache: 8 GB
• RAID Levels: 0, 1, 5, 6, 10, 50, 60
• 8 Lanes X16, optimized for high-performance storage tasks

Networking & Connectivity

Intel E810-XXVDA2 Ethernet Adapter

• Ports: 2 x 10/25Gb SFP28
• Data Rate: 25/10/1 GbE per port
• PCIe 4.0 Interface (16 GT/s)

Expansion & Interface Slots

• PCIe 5.0 x16 Full-length/Full-height: 2 slots
• PCIe 5.0 x16 Half-length: 1 slot (x8 mode)
• FlexibleLOM: 2 slots
• External Media Bay: 1 slot
• Hot-swap 2.5" SFF Bays: 8 total (6 free)

Peripheral Interfaces

• USB 3.0: 4 ports (front, rear, internal, HPE iLO service)
• VGA: 1 rear port
• LAN: 4 x Gigabit RJ-45
• HPE iLO management: RJ-45

Power & Efficiency

• Redundant Power: 1+1 configuration
• Voltage Input: AC 100-120 / 200-240 V, 50/60 Hz
• 80 Plus Titanium Certified for maximum energy efficiency
• Energy Star Version 3.0 certified

Operating System Compatibility

• No OS pre-installed, supports multiple enterprise OS
• Certified for: Windows Server, Red Hat Enterprise Linux, VMware ESXi, Oracle Linux, Ubuntu, Citrix
• UEFI firmware for advanced system management

Dimensions & Weight

• Width: 17.6 in, Depth: 28.6 in, Height: 3.4 in
• Weight: 35.27 lbs

Included Accessories & Compliance

• Cable Management Arm, High-Performance Heatsink, 6 Fans
• SFF Easy Install Rail Kit
• Compliant Standards: AES, FIPS 140-2, TLS v1.2, Low Halogen, ASHRAE A3/A4, WEEE, ACPI 6.3, ERP Lot 9

High-Performance Processor Configuration

• Dual Intel Xeon Gold 32-core processors for extreme computing power
• Base clock speed of 2.1GHz ensuring smooth multitasking
• Advanced hyper-threading for accelerated parallel processing
• Enhanced AI and machine learning capabilities for modern applications

Memory and Storage Capabilities

DDR5 Memory Support

• Supports DDR5 RAM for faster data access and reduced latency
• Expandable memory modules for future-proof performance
• Optimized memory bandwidth for virtualization and database workloads

Flexible Storage Options

• Multiple SFF drive bays supporting NVMe, SAS, and SATA drives
• Hot-swappable drives for uninterrupted operations
• Configurable RAID options for data redundancy and protection

Networking and Connectivity

• High-speed Ethernet ports for seamless network integration
• Optional Fibre Channel adapters for SAN environments
• Advanced I/O expansion slots for added connectivity

Reliability and Manageability

Proven HPE Reliability

• Redundant power supplies and cooling fans for maximum uptime
• Predictive failure analytics to reduce unplanned downtime
• HPE iLO management for remote server monitoring and control

Enterprise-Grade Security

• Silicon root of trust to prevent firmware attacks
• Secure boot and trusted platform module (TPM) support
• Role-based access controls for secure administrative management
