P83317-005 HPE ML110 Gen11 5416S 2.0GHz MR408i-o 2x960GB 16C Server

HPE ProLiant ML110 Gen11 Server

The HPE ProLiant ML110 Gen11 (Part Number: P83317-005) is a high‑performance enterprise tower server engineered for reliability, scalability, and advanced data processing. Designed for modern workloads, this Smart Choice model integrates powerful Intel Xeon processing, DDR5 memory, and flexible storage options ideal for growing businesses.

General Details

• Brand: HPE
• Model Number: P83317-005
• Device Category: Enterprise Tower Server

Processor Specifications

CPU Features

• Processor: Intel Xeon Gold 5416S
• Base Frequency: 2.0 GHz
• Turbo Boost: Up to 4.0 GHz
• Total Cores: 16‑core
• Installed CPU Count: 1
• Maximum Supported CPUs: 1
• Thermal Design Power: 150W
• CPU Socket: LGA4677 Socket‑E
• Technologies: Intel Turbo Boost, Hyper‑Threading

Chipset & Memory Support

• Chipset: Intel C741
• Memory Compatibility: DDR5 up to 4400 MT/s (1DPC & 2DPC)

Cache Memory

• L3 Cache Installed: 30 MB
• Cache Per CPU: 30 MB

System Memory (RAM)

Installed & Maximum Capacity

• Installed RAM: 64 GB (2×32GB)
• Maximum RAM: 1 TB

Memory Technology

• DDR5 SDRAM with Advanced ECC
• Effective Speed: 4400 MHz
• Rated Speed: 4800 MHz
• Form Factor: 288‑pin DIMM
• Total Slots: 16 (14 available)
• HPE SmartMemory Registered Modules

Internal Storage Capabilities

Drive Configuration

• Drive Type: SSD
• Drive Size: 2.5-inch
• Interface: SATA 6 Gb/s
• Drive Bays: 8 SFF
• Installed SSDs: 2 × 960GB
• Total Storage: 1.92 TB

Storage Controller

RAID Controller Specifications

• Model: HPE MR408i‑o Gen11
• Interface: SATA‑600 / SAS 3.0 / PCIe NVMe
• Channels: 8
• Cache: 4 GB

Supported RAID Levels

• RAID 0
• RAID 1
• RAID 5
• RAID 6
• RAID 10
• RAID 50
• RAID 60

Graphics Controller

• Video Memory: 16 MB
• Video Output: VGA

Networking & Remote Management

Network Interfaces

• 2 × Gigabit Ethernet Ports
• Controller: Broadcom BCM5720
• Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet

Management Features

• SNMP 3, IPMI 2.0
• Integrated Lights‑Out 6 (iLO 6)
• Wake‑on‑LAN
• PXE Boot Support
• ACPI Support

Expansion & Connectivity

Drive Bays

• 1 × External 5.25-inch (free)
• 8 × 2.5-inch SFF hot‑swap (6 free)

Expansion Slots

• 2 × PCIe 5.0 x16 (available)
• 1 × PCIe 5.0 x16 OCP 3.0 (available)

Interface Ports

• 1 × VGA
• 2 × Gigabit LAN
• 1 × HPE iLO RJ‑45 (rear)
• 3 × USB 3.0 (1 front, 2 rear)
• 1 × HPE iLO Type‑A (front)

Additional Features

Included Accessories

• 2 Standard Non‑Hot‑Plug Fans

Compliance Standards

• AES, WEEE, Triple DES
• TLS v1.2, Redfish API
• ASHRAE Class A3 & A4
• UEFI, FIPS 140‑3
• ACPI 6.4, SMBIOS 3.4

Power Specifications

Power Supply Details

• Type: Hot‑plug PSU
• Redundancy: Optional 1+1
• Installed Units: 2
• Maximum Supported: 2
• Voltage: AC 100–120 / 200–240V (50/60Hz)
• Output: 800W
• Certification: 80 Plus Platinum

Software & Operating Environment

Included Software

• HPE iLO Standard with Intelligent Provisioning
• HPE OneView Standard (downloadable)

Environmental Conditions

• Operating Temperature: 50°F – 95°F
• Humidity Range: 8% – 90% (non‑condensing)

Physical Dimensions & Weight

• Width: 7.7 in
• Depth: 23.1 in
• Height: 18.2 in
• Weight: 44.31 lbs

P83317-005 ProLiant ML110 Gen11 Tower Server  Overview

The HPE ProLiant ML110 Gen11 server category represents a new generation of enterprise-grade tower servers engineered for organizations that demand balanced performance, expandability, and reliability in a compact yet powerful form factor. Within this category, configurations such as the HPE P83317-005 ML110 Gen11 system address the evolving needs of growing businesses, remote offices, and edge deployments that require data-center-class capabilities without the complexity of rack-only infrastructures. The ML110 Gen11 category is positioned to support modern workloads including virtualization, data analytics, transactional databases, and line-of-business applications while maintaining cost efficiency and operational simplicity.

This category is defined by its ability to integrate the latest Intel Xeon Scalable processor technologies, high-speed DDR5 memory, advanced storage controllers, and redundant power options. The HPE ML110 Gen11 family emphasizes adaptability, allowing organizations to scale compute, memory, and storage resources as operational demands increase. With a focus on long-term reliability, security, and manageability, this category is designed to provide a foundation for mission-critical workloads in environments where flexibility and performance are equally important.

Processor Architecture and Compute Capabilities

At the core of the HPE ML110 Gen11 server category is support for Intel Xeon Scalable processors optimized for enterprise workloads. Configurations featuring the Intel Xeon Silver 5416S processor, operating at a base frequency of 2.0GHz with 16 cores, exemplify the category’s balanced compute philosophy. This processor architecture delivers efficient multi-threaded performance, making it suitable for virtualization hosts, application servers, and data processing tasks that benefit from parallel execution.

The single-processor design within this category ensures optimal power efficiency while still providing substantial computational capacity. Advanced features such as Intel Hyper-Threading, Turbo Boost, and support for modern instruction sets enhance performance consistency across diverse workloads. The ML110 Gen11 category is engineered to deliver predictable performance under sustained load, which is critical for business applications that require high availability and responsiveness.

Single-Socket Efficiency and Scalability

The single-socket architecture of the ML110 Gen11 category is particularly attractive for organizations seeking to maximize performance per watt and reduce overall infrastructure complexity. By focusing on a single high-core-count processor, these systems minimize latency and simplify thermal management while still offering significant expansion capabilities. This design approach aligns with modern IT strategies that prioritize efficiency, reduced operational costs, and streamlined maintenance.

Despite being a single-processor platform, the category does not compromise on scalability. Support for high-capacity memory, multiple storage options, and advanced networking ensures that systems within this category can grow alongside business needs. This scalability makes the ML110 Gen11 category suitable for both initial deployments and long-term infrastructure planning.

Memory Architecture and DDR5 Advancements

The HPE ML110 Gen11 server category leverages next-generation DDR5 memory technology to deliver higher bandwidth, improved power efficiency, and increased capacity compared to previous generations. Configurations featuring 2x32GB registered DIMMs provide a robust baseline of 64GB memory, supporting memory-intensive applications and virtualization environments. The use of registered memory enhances signal integrity and stability, which is essential for enterprise workloads.

DDR5 memory within this category enables faster data access and improved overall system responsiveness. This advancement is particularly beneficial for applications that rely on rapid data processing, such as in-memory databases, analytics platforms, and multi-user environments. The ML110 Gen11 category is designed to support future memory expansion, ensuring that organizations can adapt to increasing workload demands without replacing the entire system.

Memory Reliability and Key Optimization

Reliability is a cornerstone of the ML110 Gen11 category’s memory architecture. Features such as error-correcting code support and advanced memory management technologies help protect data integrity and reduce the risk of system downtime. These capabilities are essential for businesses that depend on continuous operation and accurate data processing.

Performance optimization is further enhanced through intelligent memory interleaving and optimized memory channel utilization. This ensures that applications can fully leverage available memory bandwidth, resulting in smoother performance and reduced latency. The ML110 Gen11 category’s memory design reflects HPE’s commitment to delivering enterprise-grade reliability and performance.

Storage Subsystem and 8SFF Flexibility

The storage architecture of the HPE ML110 Gen11 server category is designed to accommodate diverse data storage requirements. With support for an 8SFF configuration, this category enables the integration of multiple small form factor drives, providing a balance between capacity, performance, and expandability. The inclusion of dual 960GB drives offers a solid foundation for operating systems, applications, and frequently accessed data.

This category supports a wide range of storage media, including solid-state drives optimized for performance and reliability. The flexibility of the 8SFF design allows organizations to tailor their storage configurations based on workload requirements, whether prioritizing speed, redundancy, or capacity. This adaptability makes the ML110 Gen11 category suitable for both transactional workloads and data-intensive applications.

Advanced Storage Controller Integration

The inclusion of the MR408i-o storage controller within this category provides advanced RAID functionality and improved data protection. This controller supports multiple RAID levels, enabling organizations to design storage configurations that align with their performance and redundancy needs. Hardware-based RAID acceleration ensures consistent performance even under heavy I/O workloads.

Advanced caching and error-handling capabilities further enhance storage reliability and efficiency. These features are particularly important for applications that require consistent data access and minimal downtime. The ML110 Gen11 category’s storage controller integration reflects a focus on enterprise-grade data protection and performance optimization.

Power Supply Redundancy and Energy Efficiency

The HPE ML110 Gen11 server category emphasizes power reliability and efficiency through support for redundant power supplies. Configurations featuring dual 800W power supplies provide fault tolerance, ensuring continuous operation even in the event of a power supply failure. This redundancy is critical for business environments where uptime is essential.

Energy efficiency is also a key consideration within this category. The power supplies are designed to meet high efficiency standards, reducing overall energy consumption and operational costs. Intelligent power management features allow the system to adapt to workload demands, optimizing power usage without compromising performance.

Operational Stability and Power Management

Operational stability is enhanced through advanced power monitoring and management capabilities. These features provide real-time insights into power usage and system health, enabling proactive maintenance and reducing the risk of unexpected downtime. The ML110 Gen11 category’s power design supports long-term reliability and predictable performance.

Efficient power distribution and thermal management ensure that components operate within optimal temperature ranges. This contributes to extended hardware lifespan and consistent performance, aligning with enterprise expectations for durability and reliability.

Networking and Expansion Capabilities

The networking capabilities of the HPE ML110 Gen11 server category are designed to support modern connectivity requirements. Integrated network interfaces provide reliable and high-speed communication, supporting both internal network traffic and external data exchange. This connectivity is essential for applications that rely on real-time data access and collaboration.

Expansion options within this category allow organizations to add additional network adapters, storage controllers, or accelerators as needed. The flexible expansion architecture ensures that systems can evolve alongside changing business requirements, protecting infrastructure investments over time.

PCIe Gen5 Readiness and Future-Proofing

The ML110 Gen11 category supports advanced expansion standards, including readiness for PCIe Gen5 technologies. This forward-looking design ensures compatibility with next-generation peripherals and accelerators, enabling organizations to adopt new technologies without replacing their core infrastructure.

Future-proofing is a central theme within this category, allowing businesses to remain competitive and responsive to technological advancements. The ML110 Gen11 platform is engineered to accommodate evolving performance and connectivity demands.

Security Features and Hardware-Level Protection

Security is a fundamental aspect of the HPE ML110 Gen11 server category. Hardware-based security features are integrated to protect data, firmware, and system integrity from emerging threats. These protections begin at the silicon level and extend throughout the system lifecycle.

Technologies such as secure boot, firmware validation, and runtime intrusion detection help safeguard the system against unauthorized modifications and cyber threats. This comprehensive security approach is essential for organizations handling sensitive data and operating in regulated industries.

Trusted Platform and Secure Lifecycle Management

The ML110 Gen11 category incorporates trusted platform features that ensure only verified firmware and software components are executed. This reduces the risk of malware infiltration and enhances overall system trustworthiness. Secure lifecycle management tools enable administrators to maintain system integrity through updates and configuration changes.

These security capabilities are designed to integrate seamlessly with enterprise security frameworks, providing a robust defense against evolving threats while maintaining operational efficiency.

Manageability and Remote Administration

Efficient management is a defining characteristic of the HPE ML110 Gen11 server category. Integrated management tools provide comprehensive visibility into system health, performance metrics, and configuration settings. These tools enable administrators to monitor and manage systems both locally and remotely.

Remote administration capabilities reduce the need for on-site intervention, which is particularly valuable for distributed environments and remote offices. The ML110 Gen11 category supports streamlined deployment, monitoring, and maintenance processes, contributing to reduced operational overhead.

Automation and IT Efficiency

Automation features within this category simplify routine management tasks, such as firmware updates and system provisioning. By reducing manual intervention, organizations can improve consistency, reduce errors, and free up IT resources for strategic initiatives.

The focus on IT efficiency ensures that the ML110 Gen11 category aligns with modern operational models, supporting agile and scalable infrastructure management.

Form Factor, Physical Design, and Deployment Scenarios

The tower form factor of the HPE ML110 Gen11 server category offers deployment flexibility for environments without dedicated data center space. This design is well-suited for offices, retail locations, and edge deployments where space and acoustic considerations are important.

Despite its compact footprint, the category provides ample internal space for expansion and cooling. Thoughtful physical design ensures ease of maintenance and component access, reducing downtime during upgrades or repairs.
