P83319-005 HPE Proliant Ml350 Gen11 Xeon 12-core 2.4GHz DDR5 4U Rack-Mountable Server

HPE P83319-005 ProLiant ML350 Gen11 Server Overview

The HPE P83319-005 ProLiant ML350 Gen11 is a high-performance rack-mountable server engineered for reliability, scalability, and speed. With its 12-core Intel Xeon processor and advanced DDR5 memory, it ensures optimized computing for both enterprise-level applications and data-intensive workloads.

Key Technical Specifications

• Model: HPE P83319-005 ProLiant ML350 Gen11
• Processor: Intel Xeon 12-core, 2.4GHz base frequency
• Memory: DDR5 for accelerated data handling
• Form Factor: 4U rack-mount design
• Scalability: Expandable architecture for growing business needs

General Product Details

• Brand: Hewlett Packard Enterprise
• Part Number: P83319-005
• Chassis: 4U Tower Form Factor
• Scalability: Dual-processor support
• Drive Bays: 8x hot-swappable SFF slots
• Power Supply: 2x 800W FS Platinum certified redundant units

Processor and Chipset

• Processor: Intel Xeon Silver 4510
• Base Frequency: 2.4GHz
• Maximum Turbo Speed: 4.1GHz
• Cores: 12-core, Hyper-Threading enabled
• Socket: LGA4677 (Socket-E)
• Chipset: Intel C741 platform
• CPU Upgrade Support: Expandable up to 2 CPUs

Cache Architecture

• L3 Cache: 30MB per processor
• High-efficiency data handling

Memory and Expansion

• Installed RAM: 64GB DDR5 SDRAM (2x32GB)
• Expandable Capacity: Up to 8TB
• Memory Technology: Advanced ECC DDR5
• Speed Ratings: 4400 MHz effective / 5600 MHz rated
• DIMM Slots: 32 slots total, 30 available
• Features: Dual Rank, Registered, Online Spare, SmartMemory support

Storage and Controllers

• Primary Controller: HPE NS204i-u Gen11 NVMe Boot Optimized Device
• Additional Controller: HPE MR408i-o Gen11 with 4GB Cache (x8 Lanes OCP SPDM)
• Hot-swap Bays: 8x 2.5" SFF drive slots
• Pre-installed HDD/SSD: None
• Optical Drive: Not included

Networking and Connectivity

• Ethernet Controller: Broadcom BCM5719
• LAN Ports: 4x 1GbE RJ-45 interfaces
• Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: iLO 6 with SNMP 3, IPMI 2.0, SMASH CLP
• Features: PXE Boot, Wake-on-LAN

Expansion Slots

• PCIe Slots: 4x Gen5 x16 (x8 mode)
• Interfaces: VGA, DisplayPort 1.1a, iLO service & management ports, USB 3.2, USB 2.0

Graphics and Display

• Controller: Integrated VGA
• Video Memory: 16MB
• Ports: VGA and DisplayPort (front)

Security and Compliance

• Locking Options: Kensington security slot, padlock eye
• Standards: TLS v1.2, ACPI 6.1, SMBIOS 3.1, UEFI 2.7, FIPS 140-3
• Energy Star Certified
• ASHRAE Class A3/A4 Compliant

Power and Efficiency

• Type: Hot-plug redundant power supply
• Installed Units: 2x 800W PSU
• Redundancy Scheme: 1+1 configuration
• Voltage: 100–240V AC, 50/60Hz
• Certification: 80 Plus Platinum

Software and Management Tools

• Included Software: HPE iLO Standard, Intelligent Provisioning
• Additional Tools: HPE OneView Standard (downloadable)
• OS: No pre-installed operating system

Dimensions and Weight

• Width: 6.9 inches
• Depth: 28 inches
• Height: 18.2 inches
• Weight: 54.52 lbs

Performance and Processing Power

Powered by Intel Xeon 12-core CPU, this server is ideal for multitasking, virtualization, and advanced cloud solutions. Its 2.4GHz processing speed ensures smooth handling of complex operations with reduced latency.

Advantages of DDR5 Memory

• Faster data transfer rates compared to DDR4
• Improved energy efficiency for cost savings
• Supports higher workloads with enhanced stability

Design and Form Factor

Built with a 4U rack-mount chassis, the ML350 Gen11 provides flexibility for data center environments. Its design allows for seamless expansion while maintaining superior airflow and cooling efficiency.

Scalability and Storage Options

• Flexible drive bay support for future upgrades
• Optimized for both SSD and HDD integration
• Expandable storage architecture to match enterprise demands
