P83320-005 PHPE roliant ML350 4516Y 2.2GHz 24-Core Server.

HPE P83320-005 Proliant ML350 2.2GHz 24-Core Server

Discover the HPE ProLiant ML350 Gen11, part number P83320-005, a robust and expandable 4U tower solution engineered for performance-intensive workloads. This enterprise server combines a high-core-count Intel processor with advanced HPE DDR5 memory and flexible storage in a versatile tower form factor ideal for office environments and data centers.

General Information

• Brand Name: HPE
• Manufacturer Part Number: P83320-005
• Product Name: Server

Processor Performance and Computational Power

Central Processing Unit (CPU) Specifications

• Processor Model: Intel Xeon 4516Y (1 Processor Installed)
• Total Core Count: 24 Cores
• Base Clock Speed: 2.20 GHz
• Last Level Cache: 45 MB L3 Smart Cache
• Socket Configuration: Single processor design (1P)

Memory Configuration and Intelligent RAM Technology

Installed RAM Details

• Total Installed Memory: 64 GB
• Memory Configuration: 2 x 32 GB modules
• Memory Technology: HPE DDR5 Smart Memory
• Memory Transfer Rate: 5600 MT/s (MegaTransfers per second)
• Error Correction: ECC (Error-Correcting Code) support for data integrity

Storage Subsystem and Data Controller

Drive Bays and Installed Storage

• Form Factor: 8 x Small Form Factor (SFF) drive bays
• Installed Solid State Drives: 2 x HPE 960GB SATA SSDs
• Total Raw Capacity: 1.92 TB
• Drive Type: Read-Intensive Multi-Vendor SATA 6Gbps Solid State Drives
• Optical Drive Support: Optional DVD-ROM, DVD-RW, or RDX removable cartridge drive

Storage Controller and RAID Capabilities

• Controller Model: HPE MR408i-o Gen11 Storage Controller
• Controller Cache: 4 GB dedicated cache memory
• Interface Lanes: x8 PCIe lanes with OCP SPDM form factor
• Supported Protocols: SATA, SAS, NVMe for flexible drive compatibility
• RAID Functionality: Hardware RAID support for data protection

Networking and Expansion Capabilities

Integrated Network Interface

• Network Controller: Broadcom BCM5719 OCP 3.0 Adapter
• Ethernet Ports: 4 x 1Gb BASE-T RJ45 ports
• Form Factor: Open Compute Project 3.0 slot
• Management Features: Wake-on-LAN, teaming, and virtualization support

Accelerator and Expansion Slot Support

• PCIe Expansion Slots: 2 to 10 PCIe Gen 5 slots (configuration dependent)
• OCP Slots: 2 x OCP 3.0 slots for specialized adapters
• GPU Accelerator Support: Compatible with NVIDIA L40, A16, L4, and RTX 4000 Ada Generation GPUs for HPE (optional)
• Use Cases for Accelerators: AI inference, virtual desktop infrastructure (VDI), rendering, and computational workloads

Power Supply and Cooling Infrastructure

Power System Configuration

• Power Supply Type: Hot Plug Flex Slot Power Supply
• Installed Quantity: 2 x Power Supply Units
• Wattage per PSU: 800 Watts
• Efficiency Certification: 80 PLUS Platinum
• Environmental Compliance: Low Halogen design
• Power Redundancy: N+1 configuration for continuous uptime

Thermal Management System

• Cooling Fans: 8 x Standard Fans for optimal airflow
• Thermal Design: Optimized for quiet operation in office environments
• Airflow Management: Front-to-rear cooling for efficient heat dissipation

Physical Specifications and Form Factor Details

Dimensions and Weight

• Form Factor: 4U Tower (convertible to rackmount with optional kit)
• Height: 30.48 cm (12 inches)
• Width: 58.42 cm (23 inches)
• Depth: 98.43 cm (38.75 inches)
• Shipping Weight: 43.26 kg (95.372 lbs)
• Chassis Material: Durable steel construction with tool-less design

HPE P83320-005 Proliant ML350 24-Core Server Overview

The HPE ProLiant ML350 Gen11 server category is engineered to deliver enterprise-grade performance, flexibility, and resilience within a tower-based form factor that can also adapt to rack deployment. This category is positioned for organizations that require powerful compute capabilities, extensive storage options, and long-term scalability without immediately committing to a full rack infrastructure. Built on the latest Intel Xeon Scalable processor platform, the ML350 Gen11 series addresses the evolving demands of growing enterprises, branch offices, remote locations, and core data center deployments.The ML350 Gen11 category emphasizes adaptability, offering a balance between raw performance and operational simplicity. Its modular internal design allows IT teams to scale compute, memory, storage, and networking resources as workloads expand. This makes the category especially relevant for businesses running mixed workloads, including file and print services, virtualization, databases, enterprise applications, and edge computing scenarios. The tower design also supports quieter operation and flexible placement, enabling deployment in environments where traditional data center infrastructure may not be available.

Intel Xeon Scalable 4516Y Reliable Multi-Core Performance

At the heart of this server category is the Intel Xeon Scalable 4516Y processor, operating at a base frequency of 2.2GHz and providing 24 cores in a single-processor configuration. This processor is optimized for balanced performance across compute-intensive and memory-driven workloads, ensuring consistent throughput for enterprise applications. The 24-core architecture enables efficient parallel processing, making this category well-suited for virtualization hosts, application servers, and data processing tasks.The Intel Xeon 4516Y processor incorporates advanced instruction sets and architectural enhancements that improve performance per watt, enabling organizations to maximize compute density while managing power consumption. Its support for modern security extensions and virtualization technologies ensures compatibility with contemporary software platforms and hypervisors. This processor configuration allows businesses to consolidate workloads onto fewer systems while maintaining performance and reliability.

Optimized Single-Socket Design for Effective Scaling

The single-processor architecture of this category provides a cost-efficient entry point into enterprise-class computing. By focusing on high core count and strong per-core performance within a single socket, organizations can achieve excellent performance without the added complexity and expense of dual-processor configurations. This approach is particularly beneficial for small to mid-sized enterprises seeking enterprise reliability with controlled capital expenditure.

Consistent Performance for Virtualization and Application

Virtualization platforms benefit from the predictable performance characteristics of the 4516Y processor. The high core count supports multiple virtual machines with stable resource allocation, while advanced cache architecture reduces latency for application workloads. This makes the ML350 Gen11 category a reliable foundation for private cloud environments and consolidated server deployments.

DDR5 Registered Configuration and Expansion Capabilities

Memory performance is a defining factor in modern server environments, and the HPE ProLiant ML350 Gen11 category leverages DDR5 Registered DIMM technology to deliver higher bandwidth, improved power efficiency, and enhanced reliability. The configuration includes 2x32GB registered memory modules, providing a total of 64GB of DDR5 memory that supports demanding workloads out of the box while leaving ample room for future expansion.

DDR5 technology significantly improves data transfer rates compared to previous generations, enabling faster access to application data and reducing bottlenecks in memory-intensive workloads. The registered memory design enhances signal integrity and stability, making it suitable for continuous operation in enterprise environments. As business requirements evolve, organizations can scale memory capacity to support additional virtual machines, larger databases, or more complex analytics workloads.

High-Bandwidth Memory for Data-Intensive Applications

Applications such as databases, enterprise resource planning systems, and analytics platforms rely on fast and consistent memory access. The DDR5 RDIMM architecture ensures that the processor cores are supplied with data efficiently, maximizing overall system performance and responsiveness.

Reliability and Error Correction for Mission-Critical Operations

Enterprise memory reliability is essential for maintaining uptime and data integrity. The registered DDR5 memory in this category includes advanced error detection and correction capabilities, reducing the risk of data corruption and system instability. These features help organizations maintain service continuity and reduce unplanned downtime.

Flexible Storage Architecture with 8SFF Design

The storage subsystem of the HPE ProLiant ML350 Gen11 category is designed to accommodate a wide range of enterprise storage requirements. Featuring an 8SFF configuration, this category supports small form factor drives that offer high performance, efficient power usage, and flexible capacity options. This design enables organizations to deploy fast solid-state storage, high-capacity drives, or a combination of both to match workload requirements.

The modular storage architecture allows for incremental expansion, enabling businesses to start with essential capacity and scale as data volumes grow. This flexibility makes the ML350 Gen11 category suitable for file servers, application storage, virtualization datastores, and database systems that require reliable and scalable storage performance.

Dual 960GB Solid-State Drives for Performance and Reliability

The inclusion of two 960GB drives provides a solid foundation for operating systems, applications, and frequently accessed data. Solid-state storage delivers low latency and high IOPS performance, ensuring fast system boot times and responsive application behavior. This configuration supports redundancy and performance optimization, enhancing overall system reliability.

Scalable Storage for Growing Business Data

As data requirements increase, the 8SFF design allows additional drives to be integrated without major infrastructure changes. This scalability protects initial investments and enables organizations to adapt their storage architecture over time.

HPE MR408i-o Storage Controller for Data Protection and Performance

The HPE MR408i-o storage controller plays a critical role in managing storage performance and data protection within this server category. Designed to support enterprise RAID configurations, this controller enables efficient data management, redundancy, and performance optimization. By offloading storage management tasks from the main processor, it ensures consistent performance even under heavy I/O workloads.

The controller supports advanced RAID levels that protect against drive failures while maintaining high availability. This capability is essential for businesses that rely on continuous access to data and cannot afford extended downtime. The MR408i-o controller also enhances storage flexibility, allowing organizations to tailor configurations to specific performance and resilience requirements.

Enterprise RAID Support for Business Continuity

RAID functionality ensures that data remains accessible even in the event of a drive failure. This is particularly important for mission-critical applications and databases where data integrity and uptime are paramount.

Power Efficiency and Reliability with 800W Power Supply

Power delivery is a key consideration in server design, and the HPE ProLiant ML350 Gen11 category incorporates an 800W power supply engineered for efficiency and reliability. This power supply supports the server’s high-performance components while maintaining stable power delivery under varying load conditions. Efficient power usage helps reduce operational costs and supports sustainable IT initiatives.

The power supply design also contributes to system stability, ensuring consistent operation during peak workloads. This reliability is essential for businesses that depend on continuous access to applications and data. The power architecture supports future expansion, allowing additional components to be added without compromising power stability.

Energy-Efficient Operation for Lower Operating

Efficient power utilization reduces energy consumption and cooling requirements, contributing to a lower total cost of ownership. This makes the ML350 Gen11 category an attractive option for organizations focused on long-term operational efficiency.

Stable Power Delivery for Mission-Critical Workloads

Consistent power delivery ensures that sensitive components operate within optimal parameters, reducing the risk of hardware failure and data loss.

Versatile Deployment Scenarios Across Industries

The HPE ProLiant ML350 Gen11 server category is versatile enough to support a wide range of deployment scenarios. Its tower form factor makes it suitable for office environments, while its rack-convertible design allows integration into data centers as needs evolve. This flexibility supports businesses at different stages of growth and across various industries.

Manufacturing organizations use this category for production management and analytics systems. Healthcare providers rely on its reliability and performance for patient data management and clinical applications. Retail and e-commerce businesses benefit from its ability to support transactional systems and inventory management platforms.

Future-Ready Platform for Evolving Business Needs

The HPE ProLiant ML350 Gen11 category is designed with future growth in mind. Support for next-generation memory, storage, and management technologies ensures that the platform remains relevant as workloads evolve. This forward-looking design enables organizations to adopt new applications, expand capacity, and enhance performance without disruptive infrastructure changes.The combination of robust compute power, scalable memory, flexible storage, and enterprise-grade reliability makes this category a strong foundation for digital transformation initiatives. Businesses can confidently deploy this server knowing it will support both current and future operational demands.
