HPE Proliant BL460C G7 603569-B21 1x Intel Xeon E5640 2.66 GHz 6 GB Ram SAS/SATA 2 X 10 Gigabit Ethernet 2 Way Blade Server

Processor

The HPE BL460C G7 Blade Server is equipped with a powerful 1x Intel Xeon E5640 Hc 2.66 GHz processor. This feature is one of the key components that make this blade server a standout option for users in need of high-performance computing.

Product Overview of BL460C G7

Discover the Hewlett Packard Enterprise Proliant BL460c G7, a versatile 2-way blade server designed for high performance and efficiency. Part number 603569-B21 offers a robust solution tailored to meet demanding computing needs.

Manufacturer Details

• Manufacturer: Hewlett Packard Enterprise
• Product Name: Proliant BL460c G7 2-Way Blade Server
• Manufacturer Part Number: 603569-B21

Processor and Chipset Specifications

• Processor Type: Intel Xeon E5640
• Clock Speed: 2.66 GHz
• Cache Memory: 12 MB L3 Cache
• Core Count: Quad-core
• 64-bit Computing: Yes
• Installed Quantity: 1
• Upgradability: Upgradable

Chipset Information

• Chipset Type: Intel 5520
• Key Features: Hyper-Threading, Intel Turbo Boost Technology

Cache Memory Details

• Cache Type: L3 Cache
• Installed Size: 12 MB
• Cache per Processor: 12 MB

Memory Specifications

• Installed Size: 6 GB
• Maximum Supported Size: 192 GB
• Memory Technology: DDR3 SDRAM
• Memory Speed: 1333 MHz
• Memory Specification Compliance: PC3-10600
• Form Factor: DIMM 240-pin
• Features: Registered

Memory Configuration Options

• PC3-8500: Up to 192 GB (Registered)
• PC3-10600: Up to 48 GB (Unbuffered)
• PC3-10600: Up to 96 GB (Registered)

Memory Protection Features

• Advanced ECC
• Mirrored Memory
• Memory Lock Step Mode
• Online Spare

Storage and Controller Information

• Hard Drive: None
• Optical Drive: None
• Internal Storage: Two Hot Plug SFF Drive Bays

Storage Controller

• Controller Type: RAID - Plug-in Card - PCI Express X4
• Controller Interface: Serial ATA-300 / SAS 2.0
• Controller Name: Smart Array P410i
• Supported RAID Levels: RAID 0, RAID 1

Display and Graphics

• Graphics Controller Type: Integrated
• Graphics Processor: Matrox MGA G200
• Supported Resolutions:
  • 1600 x 1200 (64k, 256, 16)
  • 1280 x 1024 (16.7m, 64k, 256, 16)
  • 1024 x 768 (16.7m, 64k, 256, 16)
  • 800 x 600 (16.7m, 64k, 256, 16)
  • 640 x 480 (16.7m, 64k, 256, 16)

Networking Features

• Network Adapter: Integrated
• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: HP NC532i
• Data Link Protocol: Gigabit Ethernet, 10 Gigabit Ethernet
• Remote Management: Integrated Lights-Out 3
• Additional Features: Wake On LAN (WoL)
• Compliant Standards:
  • IEEE 802.1Q, IEEE 802.1P, IEEE 802.3X
  • IEEE 802.3AD (LACP), IEEE 802.3AP

Expansion and Connectivity

• Total Expansion Bays: 2 (Hot-swap, 2.5 in SFF)

Expansion Slots

• Processor Slot: 1 (Available)
• Memory Slots: 12 (9 Available for DIMM 240-pin)
• Expansion Slot: 1 x (x8 Mode, Available)

Interfaces

• Management Interface: HP iLO - RJ-45
• Network Interfaces: 2 x Ethernet 10GBASE-KR

Dimensions and Weight

• Height: 7.2 inches
• Width: 2.19 inches
• Depth: 20.6 inches
• Weight: 16.5 lbs

Enhanced Performance

With the 1x Intel Xeon E5640 Hc 2.66 GHz processor, users can experience enhanced performance and improved efficiency. The processor boasts four cores, eight threads, and a clock speed of 2.66 GHz, allowing for faster data processing and execution of complex tasks.

Increased Speed and Productivity

The high clock speed ensures that tasks are completed quickly, enabling users to accomplish more within a shorter timeframe. This is particularly beneficial for businesses that rely on time-sensitive operations or require real-time data processing, such as financial institutions or scientific research organizations.

Efficient Multitasking

The presence of four cores and eight threads enables efficient multitasking capabilities. Users can run multiple applications simultaneously without experiencing significant lag or performance degradation. This is especially useful for virtualization purposes, where different virtual machines can run concurrently without compromising overall performance.

Scalability and Future-Proofing

The HPE BL460C G7 Blade Server's processor also provides scalability, allowing users to expand their system's capabilities as their needs grow. With support for hyper-threading technology, the processor can handle increased workloads without sacrificing efficiency. This ensures that the server remains relevant and capable of meeting evolving demands well into the future.

Improved Energy Efficiency

The 1x Intel Xeon E5640 Hc 2.66 GHz processor is designed to deliver optimal performance while minimizing power consumption. This energy-efficient design helps reduce operational costs and environmental impact, making it an ideal choice for organizations aiming to achieve sustainability goals.

RAM

The HPE BL460C G7 Blade Server comes equipped with a substantial 6 GB RAM. The generous memory allocation enhances the server's performance and enables it to handle demanding workloads with ease.

Seamless Multitasking

With 6 GB of RAM, users can run multiple applications or virtual machines concurrently without experiencing performance bottlenecks. The ample memory ensures smooth multitasking capabilities, allowing users to switch between tasks effortlessly and maximize productivity.

Improved System Responsiveness

The large RAM capacity enables the server to store frequently accessed data, reducing the need for constant retrieval from slower storage devices. This results in improved system responsiveness and reduced latency, enhancing the overall user experience.

Enhanced Data Processing

The ample RAM facilitates faster data processing by providing sufficient space for temporary storage of data during computation-intensive tasks. This allows for quicker data access and manipulation, enabling users to complete complex operations more efficiently.

Efficient Virtualization

Virtualization requires a significant amount of memory to allocate resources to different virtual machines effectively. With 6 GB of RAM, the HPE BL460C G7 Blade Server can efficiently support multiple virtual machines without compromising performance or stability.

Future-Proofing

The 6 GB RAM capacity provides room for future expansion and scalability. As businesses grow and their computing needs increase, having additional memory capacity allows for seamless upgrades and ensures the server can adapt to changing requirements.

Storage

The HPE BL460C G7 Blade Server offers versatile storage options, supporting both SAS (Serial Attached SCSI) and SATA (Serial ATA) drives. This flexibility provides users with various storage configurations to suit their specific needs.

High Performance

The SAS drives supported by the server offer superior performance compared to traditional SATA drives. They provide faster data transfer rates, lower latency, and improved reliability, making them ideal for applications that require high-speed data access and processing, such as databases or virtualization environments.

Scalability and Flexibility

The ability to support both SAS and SATA drives allows users to choose the storage solution that best fits their requirements. SAS drives are commonly used for mission-critical applications that demand high performance and reliability, while SATA drives are suitable for less demanding workloads, offering a more cost-effective storage solution.

Increased Storage Capacity

The HPE BL460C G7 Blade Server's storage capabilities can be expanded to accommodate growing data storage needs. With support for multiple drives, users can easily add additional storage capacity as their data requirements increase. This scalability ensures that the server can adapt to changing storage demands without the need for significant hardware upgrades.

Data Redundancy and Protection

By utilizing SAS or SATA drives in a RAID (Redundant Array of Independent Disks) configuration, users can achieve data redundancy and protection against drive failures. RAID configurations distribute data across multiple drives, ensuring that if one drive fails, the data can be reconstructed from the remaining drives. This safeguards critical data and minimizes the risk of data loss.

Cost-Effectiveness

The support for both SAS and SATA drives provides users with cost-effective storage options. SATA drives are generally more affordable than SAS drives, making them an attractive choice for businesses with budget constraints or non-mission-critical applications that prioritize cost efficiency.

Networking

The HPE BL460C G7 Blade Server features 2 x 10 Gigabit Ethernet ports, offering high-speed networking capabilities. This networking feature is crucial for organizations that require fast and reliable data transfer between servers, as well as seamless connectivity to their network infrastructure.

High Bandwidth

The 10 Gigabit Ethernet ports provide significantly higher bandwidth compared to standard Gigabit Ethernet ports. This allows for faster data transmission and reduced network congestion, enabling efficient communication between servers and facilitating the smooth operation of bandwidth-intensive applications.

Improved Network Performance

The high-speed networking capabilities of the HPE BL460C G7 Blade Server enhance overall network performance. Organizations can experience reduced latency, faster response times, and improved data transfer rates, resulting in more efficient communication and collaboration across their network infrastructure.

Enhanced Virtualization

The 2 x 10 Gigabit Ethernet ports enable seamless integration with virtualization platforms. Virtualized environments often require high-speed networking to support the communication between virtual machines and ensure optimal performance. The HPE BL460C G7 Blade Server's networking capabilities provide the necessary bandwidth to facilitate efficient virtualization operations.

Scalability and Future-Proofing

The inclusion of multiple 10 Gigabit Ethernet ports ensures scalability and future-proofing. As network demands increase, organizations can easily expand their infrastructure by adding additional servers or networking devices without worrying about network limitations. This flexibility allows businesses to adapt to evolving networking requirements and supports their growth trajectory.

Reliability and Redundancy

The dual 10 Gigabit Ethernet ports offer redundancy and failover capabilities. In the event of a port failure or network disruption, traffic can seamlessly be redirected through the secondary port, ensuring uninterrupted network connectivity and minimizing downtime.

Architecture

The HPE BL460C G7 Blade Server features a 2-way architecture, which provides users with enhanced processing power and scalability options. This architectural design is well-suited for organizations that require robust computing capabilities and the ability to adapt to changing workloads.

Enhanced Processing Power

The 2-way architecture of the server enables the utilization of multiple processors, significantly increasing processing power. With two processors working in tandem, users can execute computationally intensive tasks more efficiently and achieve faster results. This is particularly beneficial for applications such as database management, virtualization, or high-performance computing.

Improved Workload Distribution

The dual processor configuration allows for workload distribution across multiple cores, ensuring that each core handles a portion of the overall workload. This distribution optimizes resource utilization and improves system performance by minimizing bottlenecks and maximizing throughput.

Scalability and Flexibility

The 2-way architecture offers scalability and flexibility, allowing users to expand their server's capabilities as needed. Additional processors can be easily added to accommodate growing workloads or address increasing demands for computational power. This scalability ensures that the server can adapt to changing requirements without the need for significant hardware upgrades.

Reliability and Fault Tolerance

The dual processor setup enhances server reliability and fault tolerance. In the event of a processor failure, the system can continue to operate using the remaining processor, ensuring minimal disruption to critical operations. This redundancy feature provides added peace of mind for organizations that rely on continuous server availability.

Optimal Virtualization Performance

The 2-way architecture is particularly well-suited for virtualization environments. Virtual machines can be distributed across multiple processors, enabling efficient resource allocation and ensuring optimal performance for each virtual instance. This facilitates smoother operation of virtualized applications and enhances overall virtualization performance.

In conclusion, the HPE BL460C G7 Blade Server offers an impressive array of features that cater to the needs of users seeking high-performance computing solutions. From its powerful Intel Xeon processor to ample RAM, versatile storage options, high-speed networking capabilities, and scalable architecture, this blade server provides the performance, flexibility, and reliability required for demanding workloads. Whether it's for businesses requiring efficient data processing, virtualization environments, or organizations in need of robust networking capabilities, the HPE BL460C G7 Blade Server proves to be a reliable and versatile solution.
