HPE Proliant DL380P Server 642119-001 2.3GHz 16GB DDR3 Server

SKU: 642119-001

The HPE Proliant DL380P Server Server is a powerful and reliable server that offers exceptional performance for businesses of all sizes. One of its standout features is the Sku, with the specific model number being 642119-001. This SKU is an essential aspect of the server's identity and plays a crucial role in its functionality and compatibility.

Main Information of DL380P

Manufacturer Details

• Brand: Hewlett Packard Enterprise
• Part Number: 642119-001

Product Overview

• Product Name: Proliant DL380p Gen8 - 2-way 2U Rack Mountable Server (Base Model)

Processor & Chipset

Processor Specifications

• Type: Intel Xeon E5-2630
• Base Speed: 2.3 GHz
• Max Turbo Speed: 2.8 GHz
• Cores: 6-core
• Installed Quantity: 1
• Maximum Supported Quantity: 2
• 64-bit Computing: Yes
• Upgradability: Upgradable

Chipset Features

• Chipset Type: Intel C600
• Main Features: Hyper-threading, Intel QuickPath Interconnect, Intel Turbo Boost Technology

Cache Memory

Cache Specifications

• Type: L3 Cache
• Installed Size: 15 MB
• Cache Per Processor: 15 MB

RAM

Memory Details

• Installed Size: 16 GB / 384 GB (max)
• Technology: DDR3 SDRAM
• Effective Memory Speed: 1333 MHz
• Rated Memory Speed: 1333 MHz
• Compliance: PC3-10600
• Form Factor: DIMM 240-pin
• Slots: 24 total (20 free)
• Configuration: 4 x 4 GB
• Supported RAM: PC3-12800 (384 GB Registered), PC3-10600 (768 GB Low Voltage), PC3-12800 (128 GB Unbuffered), PC3-10600 (384 GB Hypercloud)

Storage

Drive Options

• Hard Drive: None
• Optical Drive: None

Storage Controller

Controller Specifications

• Type: Integrated RAID
• Interface: PCIe 3.0 x8
• Controller Name: Smart Array P420i with 1 GB FBWC
• Channel Quantity: 8
• RAID Levels: RAID 0, RAID 1, RAID 10
• Buffer Size: 1 GB

Display & Graphics

Graphics Specifications

• Type: Integrated
• Processor: Matrox G200
• Video Interfaces: VGA

Network & Communication

Networking Features

• Type: Plug-in Card
• Interface Type: PCI Express x4
• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: HP 331FLR
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4
• Features: Wake On LAN (WOL), PXE Support
• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)

Expansions & Connectivity

Expansion Bays

• External Bays: 8 total (all free) x Hot-swap 2.5 SFF

Expansion Slots

• Total Slots: 24 (20 free) x DIMM 240-pin
• CPU Slots: 2 (1 free)
• PCIe Slots:
  • 1 x PCIe 3.0 x16 - Full-length, Full-height (1 free)
  • 1 x PCIe 3.0 x8 - Half-length, Full-height (1 free)
  • 1 x PCIe 2.0 x8 - Half-length, Full-height (x4 Mode) (1 free)
  • 1 x FlexibleLOM (x4 Mode) (1 free)
  • 1 x SD Card (internal) (1 free)

Interfaces & Ports

Port Details

• Serial: 1
• VGA: 2 (1 Front, 1 Rear)
• LAN: 4 x Gigabit Ethernet
• HP iLO: 1
• USB 2.0: 7 (2 Front, 4 Rear, 1 Internal)

Miscellaneous

Included Accessories

• HP Friction Rail Kit
• Cable Management Arm

Additional Features

• Administrator Password
• Power-on Password
• Serial Port I/O Control
• Redundant Fans

Compliance Standards

• ACPI 2.0b
• FCC Class A Certified
• EN 61000-3-2
• EN55022
• ICES-003
• EN 61000-3-3
• EN55024
• CISPR 22
• FCC CFR47 Part 15
• IEC 60950-1
• EN 60950-1
• BSMI CNS 13438

Power Device

Power SpecificationsEnhanced Compatibility

The SKU number, 642119-001, denotes the specific configuration and specifications of the HPE Proliant DL380P Server Server. This ensures that users can easily identify and select the correct model for their needs. By having a unique SKU, HPE ensures that customers can find the exact server they require without any confusion or compatibility issues.

Furthermore, this Sku signifies that the server has undergone rigorous testing and validation to meet industry standards and ensure optimal performance. It guarantees that all components and parts are compatible with each other, reducing the risk of hardware conflicts or software errors.

Seamless Integration

With the Sku 642119-001, the HPE Proliant DL380P Server Server seamlessly integrates into existing IT infrastructures. Whether it's a small business or a large enterprise, this server can effortlessly fit into any environment without requiring extensive modifications or upgrades.

The Sku number acts as a reference point for IT professionals when planning and implementing their server infrastructure. It helps them ensure that the HPE Proliant DL380P Server Server will integrate seamlessly with their existing hardware and software systems, minimizing downtime and disruption during deployment.

Flexibility in Configuration

The Sku 642119-001 for the HPE Proliant DL380P Server Server offers flexibility in terms of configuration options. Users can customize various aspects of the server to meet their specific requirements. This includes selecting the appropriate storage capacity, networking capabilities, and expansion options.

By having a unique SKU, users can easily identify and select the configuration that best suits their needs. Whether they need a server with ample storage for data-intensive applications or one with high-speed networking for demanding workloads, the Sku 642119-001 ensures that the HPE Proliant DL380P Server Server can be tailored to their exact specifications.

Optimized Performance

The Sku 642119-001 represents a configuration of the HPE Proliant DL380P Server Server that is optimized for performance. This server is equipped with powerful components and features that enable it to handle demanding workloads with ease.

The combination of high-performance processors, ample memory, and efficient storage options ensures that users can run resource-intensive applications and processes without experiencing any lag or performance bottlenecks. The Sku 642119-001 guarantees that users can rely on the HPE Proliant DL380P Server Server to deliver exceptional performance and meet their business needs.

Reliability and Scalability

The Sku 642119-001 also signifies that the HPE Proliant DL380P Server Server is designed for reliability and scalability. This server offers redundant components and built-in fault tolerance mechanisms to ensure maximum uptime and minimize the risk of system failures.

Additionally, the Sku 642119-001 allows for easy scalability, enabling businesses to expand their IT infrastructure as their needs grow. Whether it's adding more storage capacity or increasing processing power, this server can accommodate future growth without requiring significant hardware replacements or migrations.

Processor Speed: 2.3GHz

The processor speed is a critical factor in determining the overall performance and responsiveness of a server. In the case of the HPE Proliant DL380P Server Server, the processor speed is an impressive 2.3GHz. This high-speed processing capability offers numerous benefits and is of utmost importance for users looking to maximize their server's performance.

Enhanced Processing Power

The 2.3GHz processor speed of the HPE Proliant DL380P Server Server provides enhanced processing power, allowing for faster execution of tasks and applications. With a higher clock speed, the server can handle complex calculations and data-intensive processes more efficiently, resulting in improved overall performance.

This increased processing power is particularly beneficial for businesses that rely on resource-intensive applications such as virtualization, data analysis, and database management. The 2.3GHz processor speed ensures that these applications can run smoothly and deliver results quickly, enabling businesses to make informed decisions in real-time.

Improved Multi-Tasking Capabilities

The high processor speed of 2.3GHz enables the HPE Proliant DL380P Server Server to handle multiple tasks simultaneously without experiencing any significant slowdowns. This is especially important in today's fast-paced business environments where multitasking is a common requirement.

With the ability to handle multiple tasks concurrently, users can run various applications and processes simultaneously without any noticeable decrease in performance. This enhances productivity and efficiency by reducing the time required to complete complex tasks and ensuring that all critical operations can be executed without delays.

Seamless Virtualization Performance

Virtualization has become an integral part of modern IT infrastructures, allowing businesses to maximize resource utilization and reduce hardware costs. The 2.3GHz processor speed of the HPE Proliant DL380P Server Server ensures seamless virtualization performance, enabling businesses to leverage this technology to its full potential.

Virtualization requires significant processing power as it involves running multiple virtual machines concurrently. The 2.3GHz processor speed allows the server to efficiently allocate resources to each virtual machine, ensuring that they can operate at optimal performance levels. This results in improved resource utilization and enables businesses to consolidate their infrastructure while maintaining high performance.

Efficient Workload Management

The 2.3GHz processor speed also plays a crucial role in efficient workload management. With a faster clock speed, the HPE Proliant DL380P Server Server can handle heavy workloads without experiencing performance bottlenecks.

Whether it's running demanding applications or handling a large number of concurrent users, the server's high processor speed ensures that it can meet the demands of the workload efficiently. This allows businesses to maintain smooth operations even during peak usage periods, preventing any potential disruptions that could impact productivity and customer satisfaction.

Future-Proofing and Investment Protection

Investing in a server with a high processor speed like the HPE Proliant DL380P Server Server's 2.3GHz ensures future-proofing and protects your investment. As technology advances and software becomes more resource-intensive, having a server with ample processing power becomes increasingly essential.

By choosing a server with a high processor speed, businesses can ensure that their IT infrastructure can handle future software upgrades and advancements without requiring immediate hardware replacements. This reduces the overall cost of ownership and allows for long-term scalability and growth.

Ram Size: 16GB

The RAM size is a critical factor in determining a server's ability to handle multiple tasks and applications simultaneously. The HPE Proliant DL380P Server Server boasts an impressive RAM size of 16GB, offering significant benefits for users looking to maximize their server's performance and responsiveness.

Enhanced Multitasking Capability

The 16GB RAM size of the HPE Proliant DL380P Server Server provides enhanced multitasking capability, allowing for seamless execution of multiple tasks simultaneously. With ample RAM, the server can efficiently allocate memory resources to each task, ensuring that all applications and processes can operate at optimal performance levels.

This enhanced multitasking capability is particularly beneficial for businesses that rely on running numerous applications concurrently, such as web servers, databases, and virtualization environments. The 16GB RAM size guarantees that each application receives sufficient memory to operate smoothly, minimizing any potential slowdowns or performance bottlenecks.

Improved System Responsiveness

The large 16GB RAM size significantly improves the system's responsiveness and ensures a smooth user experience. With ample memory available, the HPE Proliant DL380P Server Server can store frequently accessed data and instructions, reducing the need to access slower storage devices.

This improves overall system responsiveness by allowing applications to load quickly and respond promptly to user inputs. Whether it's accessing files, running queries on a database, or interacting with web-based applications, users can expect a fluid and seamless experience with the HPE Proliant DL380P Server Server's 16GB RAM size.

Efficient Virtualization Performance

Virtualization has become an integral part of modern IT infrastructures, enabling businesses to consolidate their servers and maximize resource utilization. The 16GB RAM size of the HPE Proliant DL380P Server Server ensures efficient virtualization performance, allowing businesses to leverage this technology effectively.

Virtualization requires a significant amount of memory to allocate resources to each virtual machine. The 16GB RAM size ensures that the server can handle multiple virtual machines simultaneously without experiencing any significant performance degradation. This enables businesses to optimize their resource utilization and consolidate their infrastructure without compromising performance.

Scalability and Future Growth

The 16GB RAM size also offers scalability and future growth opportunities for businesses. As their needs expand and demand for more memory increases, users can easily upgrade the HPE Proliant DL380P Server Server's RAM to accommodate higher workloads and resource requirements.

By investing in a server with a large RAM size, businesses can ensure that their IT infrastructure can handle future growth without requiring immediate hardware replacements. This provides investment protection and reduces the overall cost of ownership over time.

Reliability and Redundancy

The 16GB RAM size of the HPE Proliant DL380P Server Server also contributes to its reliability and redundancy. With ample memory available, the server can allocate redundant memory resources to critical applications, ensuring that they can continue operating even in the event of a memory failure.

This built-in redundancy minimizes the risk of system failures and ensures maximum uptime for businesses. By investing in a server with a large RAM size like the HPE Proliant DL380P Server Server's 16GB, businesses can rely on its robustness and resilience to keep their operations running smoothly.

Ram Type: DDR3

The RAM type is an essential aspect of a server's performance and compatibility. The HPE Proliant DL380P Server Server features DDR3 RAM, which offers several benefits for users looking to maximize their server's capabilities and ensure seamless operations.

Enhanced Data Transfer Speeds

DDR3 RAM provides enhanced data transfer speeds compared to its predecessors, enabling faster access to stored data and instructions. This translates into improved overall system responsiveness and reduced latency when accessing memory.

The HPE Proliant DL380P Server Server's DDR3 RAM ensures that applications can quickly retrieve data from memory, resulting in faster execution times and improved performance. Whether it's loading large datasets, accessing frequently used files, or running complex algorithms, the DDR3 RAM type contributes to a seamless user experience.

Compatibility and Availability

DDR3 RAM is widely adopted in the industry, making it readily available and compatible with a wide range of hardware and software systems. This ensures that users can easily find compatible RAM modules for the HPE Proliant DL380P Server Server and expand its memory capacity as needed.

The compatibility and availability of DDR3 RAM also offer future-proofing benefits. As technology advances, businesses can upgrade the server's memory by adding more DDR3 modules without requiring immediate hardware replacements. This flexibility allows for long-term scalability and growth without incurring significant costs.

Energy Efficiency

DDR3 RAM is known for its energy efficiency compared to previous RAM types. This is achieved through lower operating voltages, reducing power consumption and heat generation. The HPE Proliant DL380P Server Server's DDR3 RAM contributes to energy savings and helps businesses reduce their overall environmental footprint.

The energy-efficient nature of DDR3 RAM also has implications for cooling requirements. With lower heat generation, servers equipped with DDR3 RAM may require less cooling infrastructure, resulting in reduced operational costs and improved efficiency.

Reliability and Error Correction

DDR3 RAM incorporates advanced error correction features that enhance data integrity and system stability. The HPE Proliant DL380P Server Server's DDR3 RAM is equipped with error correction code (ECC), which detects and corrects single-bit errors in real-time.

This reliability feature ensures that data stored in memory remains accurate and consistent, minimizing the risk of data corruption or system crashes. Businesses can rely on the HPE Proliant DL380P Server Server's DDR3 RAM to maintain data integrity and ensure uninterrupted operations.

Cost-Effective Solution

DDR3 RAM offers a cost-effective solution for businesses looking to maximize their server's capabilities without breaking the bank. Compared to newer RAM types such as DDR4 or DDR5, DDR3 modules are generally more affordable due to their widespread adoption and availability.

The cost-effectiveness of DDR3 RAM enables businesses to allocate their IT budget efficiently and invest in other critical areas. By choosing the HPE Proliant DL380P Server Server with DDR3 RAM, users can achieve a balance between performance, compatibility, and cost-effectiveness.

In conclusion, the HPE Proliant DL380P Server Server with its Sku 642119-001, 2.3GHz processor speed, 16GB RAM size, and DDR3 RAM type offers exceptional performance, reliability, and flexibility for businesses of all sizes. Whether it's enhanced compatibility, seamless integration, or optimized performance, this server is designed to meet the evolving needs of modern IT infrastructures. By investing in the HPE Proliant DL380P Server Server, businesses can ensure a reliable and scalable foundation for their critical applications and workloads.
