HPE S1G50-61001 Aruba Networking AP-634-US External Antennas Campus AP

Product Details Of HPE S1G50-61001

• The HPE S1G50-61001 Aruba AP-634 is an advanced wireless access point that delivers exceptional performance and reliability for campus networks. Designed for seamless Wi-Fi 6 connectivity, it supports multiple frequency bands, including 2.4 GHz, 5 GHz, and 6 GHz, ensuring a robust and high-speed network experience for a variety of devices and IoT applications.

General Information

• Brand: HPE
• Part Number: S1G50-61001
• Type: Wireless Access Point

Key Product Highlights

• Installation: Wall or Ceiling Mountable
• Wi-Fi 6 (802.11ax) with support for Wi-Fi 6E
• Optimized for Campus Networks
• Advanced connectivity features with Bluetooth and Zigbee

Wireless Network Capabilities

• This model provides high-speed connectivity through various advanced technologies. With a data transfer rate of up to 3.9 Gbps, users can expect minimal latency and reliable performance even in high-traffic environments.

Wireless Standards Supported

• IEEE 802.11b/g/n/ac/ax
• Bluetooth 5.0
• Zigbee
• Wi-Fi 6E support for faster, more efficient wireless communication

Performance Features

• Offering a range of frequency bands and data rate optimizations, this access point ensures exceptional network performance for various use cases, from basic internet browsing to high-demand applications.

Maximum Data Rates

• 2.4 GHz: 287 Mbps
• 5 GHz: 1.2 Gbps
• 6 GHz: 2.4 Gbps

Aggregate Bandwidth

• With an aggregate bandwidth of 3.9 Gbps, the HPE S1G50-61001 Aruba AP-634 is designed to handle substantial traffic loads and deliver superior performance across devices connected to the network.

Capacity and Scalability

• Supports up to 512 wireless clients per Wi-Fi radio
• 8 OFDMA units for enhanced traffic management
• 16 BSSIDs per radio for flexibility in network configurations

Advanced Wireless Features

• OFDMA for efficient resource allocation
• MU-MIMO (2x2:2) for simultaneous data transmission
• Packet aggregation to improve overall throughput
• Dynamic Frequency Selection (DFS) for optimal channel use

Security Features

• Support for WPA, WPA2, WPA3 Enterprise, and OWE encryption
• Opportunistic Wireless Encryption (OWE) for enhanced security
• Simultaneous Authentication of Equals (SAE) for stronger protection

Antenna and Connectivity

• Equipped with external omni-directional antennas, this device ensures a wide coverage area, with a gain level of 7 dBi, allowing for strong signal strength across your network's range.

Expansion and Connectivity Ports

• 2 x 100/1000/2500Base-T RJ-45 Ethernet ports
• 1 x USB 2.0 Type A port for additional devices
• 1 x Console Micro-USB port for management and configuration

IoT Compatibility

Designed to support the Internet of Things (IoT), this access point is compatible with Bluetooth Low Energy (LE) and Zigbee, making it ideal for smart devices and connected environments.

Power Management

• Supports Power over Ethernet (PoE) for easy deployment
• Efficient power management for cost-effective operation

Overview of HPE S1G50-61001 Aruba Networking AP-634-US Tri-radio 2x2:2 Wi-Fi 6E External Antennas Campus AP

The HPE S1G50-61001 Aruba Networking AP-634-US Tri-radio 2x2:2 Wi-Fi 6E External Antennas Campus Access Point (AP) is a cutting-edge networking device designed to provide high-performance wireless connectivity in large campus environments. With its advanced features, including support for the latest Wi-Fi 6E technology, external antennas, and robust radio configurations, this access point is ideal for enterprises looking to enhance their wireless infrastructure.

Key Features

• Support for Wi-Fi 6E for high-speed and low-latency wireless communication
• Tri-radio setup with 2x2:2 MIMO configuration for improved performance
• External antennas for greater flexibility and coverage
• Efficient power management with reduced interference
• Enterprise-grade security features for secure access and data transmission

High-Speed Wi-Fi 6E Connectivity

As the demand for faster wireless networks increases, Wi-Fi 6E emerges as a revolutionary solution to meet these needs. The HPE S1G50-61001 supports Wi-Fi 6E, which utilizes the newly opened 6 GHz spectrum to provide more bandwidth and faster speeds than traditional Wi-Fi technologies. This enables businesses to handle more devices, offer better user experiences, and support bandwidth-heavy applications like video conferencing, virtual reality, and IoT devices.

Benefits of Wi-Fi 6E

• Increased capacity with access to the 6 GHz band
• Lower latency for real-time applications
• Enhanced spectrum efficiency for handling more devices simultaneously
• Improved performance in dense environments such as offices and stadiums

Tri-Radio Design for Optimal Coverage

The AP-634 features a tri-radio design with 2x2:2 MIMO (Multiple Input Multiple Output) configuration, which significantly improves network efficiency by simultaneously transmitting and receiving data over multiple antennas. This allows the access point to maintain a stable and fast connection even in areas with high interference or many connected devices.

How Tri-Radio and 2x2:2 MIMO Work

The three radios allow for concurrent communication across different frequency bands (2.4 GHz, 5 GHz, and 6 GHz). The 2x2:2 MIMO configuration uses two transmit and two receive antennas, boosting data throughput and reducing signal congestion. With this setup, the AP-634 can manage more devices without sacrificing performance.

Maximizing Network Efficiency with MIMO Technology

MIMO technology maximizes the efficiency of wireless networks by increasing the number of data paths. By sending multiple signals at once, MIMO enables devices to communicate more efficiently and maintain higher speeds even when multiple devices are using the network at the same time.

Security Features

Enterprise-Grade Security

Security is a critical concern for any organization, especially when dealing with sensitive data and critical operations. The HPE S1G50-61001 Aruba AP-634-US comes with a suite of advanced security features to protect wireless networks from unauthorized access, data breaches, and cyberattacks.

Advanced Security Protocols

• Support for WPA3 encryption for enhanced protection of wireless networks
• 802.1X authentication for secure user access
• Role-based access control for granular security management
• Automatic security updates to ensure ongoing protection against emerging threats

Benefits of WPA3 Encryption

WPA3 is the latest Wi-Fi security protocol, offering stronger encryption than previous versions. It protects users' data with 256-bit encryption and improves the security of open networks, such as public Wi-Fi hotspots. By using WPA3, the AP-634 ensures that sensitive information transmitted across the network remains protected from hackers and eavesdroppers.

Reducing Vulnerabilities with Advanced Authentication

With 802.1X authentication, organizations can implement stricter access control policies. This ensures that only authorized devices or users can connect to the network, protecting against unauthorized access and reducing the likelihood of network breaches.

Energy Efficiency and Environmental Considerations

Efficient Power Consumption

The HPE S1G50-61001 Aruba AP-634-US is designed with power efficiency in mind. It features intelligent power management to minimize energy consumption without compromising performance. This is especially important for large-scale deployments where numerous access points are used, as it can lead to significant energy savings over time.

Energy-Efficient Design

• Power over Ethernet (PoE) support for simplified power management
• Dynamic power adjustments to match demand and optimize efficiency
• Low energy consumption modes during periods of inactivity

Environmental Sustainability

Hewlett Packard Enterprise (HPE) places a strong emphasis on environmental sustainability. The AP-634 complies with global environmental standards and certifications, including RoHS (Restriction of Hazardous Substances) and WEEE (Waste Electrical and Electronic Equipment). These certifications ensure that the product is manufactured and disposed of in an environmentally responsible manner.

Minimizing E-Waste

By adhering to sustainability practices, HPE helps reduce e-waste and minimize the environmental impact of its products. This is achieved through eco-friendly materials and a design focused on longevity, which ensures that the device can be used for an extended period before it reaches the end of its life cycle.

Deployment and Management

Simple Installation and Configuration

The Aruba AP-634 is designed for easy deployment in both small and large networks. With a user-friendly interface and support for various network management solutions, configuring and managing the access point is a seamless experience. HPE provides multiple options for managing the AP, including cloud-based and on-premises solutions, allowing administrators to choose the best option for their specific needs.

Cloud-Based Management

With HPE Aruba Central, administrators can manage the AP-634 from anywhere in the world. Aruba Central is a cloud-based platform that simplifies network management by offering centralized control, real-time analytics, and automated troubleshooting. This allows IT teams to manage large networks without being physically present at each location.

Streamlined Firmware Updates

Cloud-based management also streamlines the process of updating firmware. With Aruba Central, the AP-634 automatically receives the latest firmware updates, ensuring that the access point remains secure and up to date without requiring manual intervention.

Support for Scalability

The HPE AP-634 is designed to scale with the growth of the organization. Whether you are expanding a small office network or deploying wireless connectivity across multiple campuses, the AP-634 can easily integrate into larger systems. The access point supports seamless integration with other Aruba devices, ensuring a cohesive network architecture that can grow as your needs evolve.

Integration with Aruba’s Unified Network Solution

The AP-634 is part of Aruba's unified network solution, which includes switches, routers, and security appliances. This integration simplifies network management and ensures that all devices within the system are optimized to work together. This provides businesses with a reliable, secure, and high-performance network that can adapt to changing requirements.
