S1G79-61001 HPE Aruba AP-754 (RW) Tri Radio 4x4 Wi-Fi 7 External Antennas TAA Campus Access Point

Key Features of HPE S1G79-61001 Aruba Networking AP-754 (RW)

• Tri-radio capabilities supporting simultaneous operations across 2.4GHz, 5GHz, and 6GHz bands
• Advanced 4x4 MIMO configuration for each radio ensuring optimal throughput and range
• External RP-SMA connectors offering flexible antenna deployments for campus environments
• Tailored for indoor use with next-gen Wi-Fi 7 (802.11be) standard for unparalleled speed
• Designed with TAA compliance for government and enterprise-grade security requirements
• Dual USB 2.0 ports enable peripheral expansion and custom integrations
• Two RJ-45 Ethernet interfaces to support high-throughput wired backhaul
• Power-efficient architecture supporting DC and PoE input with USB accessory power allowance

Wi-Fi Capabilities and Radio Technology

Wireless Standards and Performance

Supporting the most modern Wi-Fi protocols, this access point operates with 802.11a/b/g/n/ac/ax and the revolutionary 802.11be (Wi-Fi 7) for top-tier wireless performance. Multiple frequency bands function concurrently to provide seamless roaming and dynamic bandwidth allocation.

The tri-radio architecture delivers reliable connectivity with separate antenna pathways for each frequency: - 2.4 GHz and 5 GHz bands operate through RP-SMA ports A0 to A3 - 6 GHz operates via ports B0 to B3

Each antenna chain benefits from minimized internal signal loss — just 1.1 dB for 2.4 GHz, 1.8 dB for 5 GHz, and 2.8 dB for 6 GHz — enhancing RF output clarity and signal penetration indoors.

Security and Wireless Optimization

• Advanced encryption options including WPA3 Enterprise and CNSA-compliant setups
• Support for WPA, WPA2, Enhanced Open (OWE), and WPA3 Personal (SAE)
• Wi-Fi Multimedia (WMM), WMM-Power Save, and Agile Multiband features included

Interface Options and Expandability

Ethernet and USB Connectivity

• Two gigabit RJ-45 Ethernet ports (E0, E1) ensure dependable wired communication
• Two USB 2.0 Type-A host ports (U0, U1) support peripherals such as storage devices or IoT modules
• Micro-B USB serial console port provides direct access for configuration and diagnostics
• Kensington lock slot included for added physical security

Power Requirements and Consumption Profile

DC and PoE Operation

The access point supports both direct current (DC) and Power over Ethernet (PoE) options, offering installation versatility:

• DC power: 35W max without USB load, up to 46W with full USB utilization
• PoE: 40W base usage, 51W with active USB peripherals
• Idle mode: 14W on DC, 12W on PoE
• Deep-sleep mode efficiency: 2.4W via DC, 3.5W via PoE

Up to 10 watts may be routed to USB devices, enhancing flexibility for additional hardware.

Industry Certifications and Safety Compliance

Wireless and Network Standards

• Wi-Fi Alliance certified across legacy and cutting-edge standards (a/b/g/n/ac/6/7)
• PoE compliance verified by Ethernet Alliance for PD device Class 6
• Bluetooth SIG accreditation for robust short-range connectivity support

Electrical and Safety Approvals

• Meets UL2043 Plenum requirements for installation in air-handling spaces
• Certified to UL/IEC/EN 60950 and IEC/EN 62368-1 safety standards
• Compliant with EN60601-1-1 and EN60601-1-2 for use in medical environments

Regional Regulatory Standards

• FCC and ISED compliant for U.S. and Canadian markets
• CE Marking for conformity with European regulations
• Compliant with EU RED (2014/53/EU), EMC (2014/30/EU), and LVD (2014/35/EU) directives

Deployment and Coverage Capabilities

Radio Design for Dense Environments

Engineered for high-density usage scenarios such as educational institutions, corporate offices, and large facilities, this campus-grade access point ensures uninterrupted, high-speed coverage with simultaneous multi-radio transmissions.

Its 4x4 multi-user MIMO ensures optimized spectral efficiency and robust client handling. The access point's directional antenna configuration boosts range and ensures signal consistency, particularly in partitioned indoor environments.

With tri-radio concurrency across the new 6 GHz spectrum and legacy bands, the device seamlessly integrates into modern and transitional network topologies.

HPE S1G79-61001 Aruba Networking AP-754 (RW) Overview

Tri Radio 4x4 Wi-Fi 7 Performance

The HPE S1G79-61001 Aruba Networking AP-754 (RW) Campus Access Point sets a new standard for high-performance, next-generation wireless connectivity. Designed to deliver blazing-fast speeds and dependable performance, the AP-754 leverages Wi-Fi 7 technology across three radios with 4x4 MU-MIMO, ensuring a robust and seamless user experience even in high-density environments. The AP-754 features external antennas, enabling greater flexibility in directional coverage and signal reach, especially in challenging campus environments where signal propagation is critical for maintaining consistent network availability.

Equipped with the latest IEEE 802.11be (Wi-Fi 7) standards, the AP-754 (RW) offers significant enhancements in throughput, latency, and capacity compared to its Wi-Fi 6E predecessors. Its tri-radio architecture supports simultaneous communication across multiple frequency bands, which include 2.4GHz, 5GHz, and 6GHz. This enables better frequency utilization, minimized congestion, and increased throughput, making it the ideal solution for large campuses, enterprise buildings, and high-demand user scenarios.

TAA Compliance for Secure Deployments

The HPE S1G79-61001 Aruba AP-754 (RW) is TAA (Trade Agreements Act) compliant, which makes it suitable for government institutions and other organizations requiring procurement from approved sources. This ensures not only regulatory compliance but also adherence to strict manufacturing and sourcing guidelines for security-conscious environments. As more organizations implement network infrastructure upgrades, TAA-compliant hardware like the AP-754 becomes essential for achieving both performance and regulatory goals simultaneously.

Enterprise-Grade Design and Features

Modular and Scalable Architecture

Built with scalability in mind, the AP-754 allows IT teams to expand and upgrade wireless infrastructures without reconfiguring the entire network. With flexible power options, external antenna connectors, and modular firmware, this access point integrates smoothly into existing Aruba ESP (Edge Services Platform) environments. Whether supporting a few access points or scaling to hundreds across a distributed campus, the AP-754 offers a consistent management experience through Aruba Central or on-premises solutions.

Advanced RF Management Capabilities

The tri-radio functionality of the AP-754 includes integrated AI-powered RF management. This capability allows the access point to dynamically assess RF conditions and adjust channel assignments, power levels, and bandwidth utilization in real time. As a result, it reduces interference and improves connection quality for users across all service areas. This is particularly valuable in multi-floor buildings, lecture halls, libraries, and open campus zones where RF conditions can vary significantly based on environmental factors.

High-Density User Optimization

The Aruba AP-754 is specifically engineered for high-density deployments, ensuring consistent connectivity even when large numbers of users are connected simultaneously. With 4 spatial streams per radio and enhanced multi-user features, the AP-754 maximizes network efficiency through techniques like OFDMA (Orthogonal Frequency-Division Multiple Access) and MU-MIMO (Multi-User, Multiple Input Multiple Output). These advancements allow the AP to deliver low-latency experiences across applications such as video conferencing, cloud services, and real-time collaboration tools.

Security and Network Intelligence

Integrated Zero Trust and SASE Framework

As part of the Aruba ESP architecture, the AP-754 (RW) supports Zero Trust Security models and integrates seamlessly with Aruba's SASE (Secure Access Service Edge) framework. This ensures granular access control, continuous device and user verification, and the implementation of secure access policies without hindering performance. Network administrators can segment traffic, assign role-based permissions, and isolate threats using Aruba ClearPass Policy Manager, ensuring a secure wireless environment.

Client and Application Visibility

The HPE S1G79-61001 Aruba AP-754 delivers real-time visibility into client behavior, traffic flows, and application usage through Aruba’s AI-powered analytics. By correlating device behavior with network events, administrators can preemptively identify and resolve issues. The access point also supports deep packet inspection (DPI), allowing precise identification of applications in use—an invaluable tool for enforcing Quality of Service (QoS) policies across voice, video, and data traffic.

Advanced Encryption and Secure Boot

Security is deeply embedded into the AP-754 through hardware-anchored secure boot mechanisms and advanced encryption protocols. Support for WPA3, Enhanced Open (OWE), and 192-bit cryptographic standards ensures that sensitive data is always protected, even in open or semi-open network deployments. Additionally, the AP features TPM-based device authentication, securing it against firmware tampering and unauthorized access.

Deployment Flexibility and Use Cases

Outdoor and Indoor Campus Environments

The external antenna design of the AP-754 is ideal for campuses with both indoor and outdoor networking requirements. The flexibility to select high-gain or directional antennas enables administrators to optimize signal propagation for courtyards, sports arenas, and academic walkways while maintaining tight control over indoor coverage. Its ruggedized design also ensures operation in variable weather conditions when installed in protected outdoor enclosures.

Ideal for Education, Government, and Healthcare

Whether deployed across educational institutions, government agencies, or healthcare facilities, the Aruba AP-754 provides the reliability and performance needed for mission-critical applications. In schools and universities, it supports bandwidth-intensive learning platforms, hybrid classroom environments, and IoT-enabled learning tools. In government use, its TAA compliance and secure firmware support ensure adherence to procurement standards. Healthcare facilities benefit from real-time medical data transmission, patient monitoring, and staff communication without service interruption.

IoT Integration and Edge Compute Readiness

As a forward-looking access point, the AP-754 includes native support for Zigbee, Bluetooth 5, and USB-based IoT modules, enabling integration of a broad range of sensors and devices. These capabilities make the AP-754 a valuable component of smart campus initiatives, enabling everything from asset tracking and environmental monitoring to smart lighting and access control. Furthermore, its edge computing readiness allows it to process localized data at the access layer, reducing backhaul congestion and improving response times for critical IoT applications.

Management and Monitoring Features

Aruba Central Cloud Management

Managing the AP-754 through Aruba Central provides an intuitive and centralized cloud management experience. Network administrators can provision, monitor, and troubleshoot access points at scale through a single interface, ensuring high availability and performance across distributed networks. Visual dashboards and AI-powered insights reduce the time needed to identify root causes and provide predictive alerts before service degradation occurs.

On-Premises Mobility Conductor Integration

For enterprises requiring on-premises control, the AP-754 integrates seamlessly with Aruba Mobility Conductor. This centralized controller simplifies the deployment of configuration changes, firmware updates, and access policies across large fleets of access points. Combined with Aruba AirMatch and ClientMatch technologies, the AP-754 ensures optimal client distribution and minimal co-channel interference.

Customizable Alerts and Event Logging

The AP-754 supports detailed event logging and alerting, providing IT teams with real-time network health metrics and actionable event data. Administrators can configure threshold-based alerts for bandwidth usage, rogue device detection, or client onboarding failures. Logs are exportable to SIEM platforms, enabling compliance reporting and long-term auditing in regulated industries.

Technical Specifications

Hardware Highlights

The Aruba AP-754 features three concurrent radios supporting 2.4GHz, 5GHz, and 6GHz bands, each with 4x4:4 MU-MIMO capabilities. Its external antenna connectors allow deployment flexibility across various coverage needs. The AP supports PoE (Power over Ethernet) 802.3bt Class 6 with a maximum power consumption of approximately 30W. Multiple mounting options and compact housing dimensions enable discreet installation in ceilings, walls, or enclosures.

Environmental Specifications

The device operates within a temperature range of 0°C to 50°C and can withstand relative humidity levels from 5% to 95% non-condensing. Shock and vibration resistance ratings make it suitable for deployment in high-traffic or semi-industrial areas, while its external antenna configuration enhances adaptability across harsh environments.

Standards and Compliance

Fully compliant with IEEE 802.11a/b/g/n/ac/ax/be, the AP-754 also supports standards such as WPA3, Enhanced Open, 802.1X, SNMPv3, and IPv6. Its TAA certification confirms adherence to U.S. government procurement guidelines. RoHS, WEEE, and REACH compliance further reinforce its eco-friendly manufacturing and sustainability credentials.

Future-Proofing and Investment Protection

Wi-Fi 7 Readiness

Investing in the HPE S1G79-61001 Aruba AP-754 ensures readiness for future wireless demands. Wi-Fi 7 offers multi-link operation (MLO), enhanced channel widths up to 320 MHz, and deterministic latency improvements critical for real-time applications like augmented reality (AR), virtual reality (VR), and 8K video streaming. Organizations planning long-term network infrastructure strategies can rely on the AP-754 to meet their evolving wireless needs.

Software Updates and Support Lifecycle

Aruba provides robust lifecycle support and frequent firmware enhancements to keep AP-754 units secure and functional. Through Aruba Central or on-premises systems, access points can receive over-the-air updates, ensuring that the latest security patches, performance improvements, and protocol enhancements are always available. Long-term support contracts and global customer service ensure organizations receive maximum return on their networking investments.

Total Cost of Ownership (TCO)

With features like energy-efficient design, centralized management, and AI-driven automation, the Aruba AP-754 reduces total cost of ownership across its operational lifecycle. Simplified deployment, reduced support overhead, and fewer manual configurations lower administrative costs. Combined with its high reliability and extended lifespan, it is an economically sound solution for organizations seeking enterprise-grade wireless networking without recurring operational headaches.
