Hynix HFS3T8G32FEH-BA10A 3.84TB SATA-6GBPS Tlc 2.5inch SSD

KPM6XVUG12T8 Kioxia 12.8TB SAS 24GBPS Solid State Drive Overview

The KPM6XVUG12T8 Kioxia 12.8TB SAS 24GBPS Solid State Drive (SSD) from the PM6-V Series is an advanced data storage solution designed for high-performance and mixed-use environments. Featuring a compact 2.5-inch form factor, BiCS Flash TLC NAND technology, and the robust U.2 interface, this SSD delivers exceptional reliability, scalability, and speed for enterprise applications.

Technical Specifications of the Kioxia PM6-V Series

• Capacity: 12.8TB
• Interface: SAS 24Gbps
• Form Factor: 2.5-inch
• NAND Flash: BiCS Flash Triple-Level Cell (TLC)
• Endurance: Optimized for mixed-use workloads
• Interface Protocol: U.2

Form Factor and Physical Design

The 2.5-inch form factor of the Kioxia PM6-V Series SSD makes it an ideal choice for compact server setups and enterprise storage arrays. With dimensions adhering to industry standards, the drive is compatible with most server chassis and storage enclosures, ensuring easy integration and deployment.

Performance Features of the Kioxia 12.8TB SAS SSD

The Kioxia PM6-V Series SSD is engineered for top-tier performance. Its SAS 24Gbps interface allows for ultra-fast data transfer rates, making it ideal for environments that demand high-speed I/O operations. Below are the key performance metrics:

Sequential and Random Data Speeds

• Sequential Read: Up to 4,300 MB/s
• Sequential Write: Up to 3,800 MB/s
• Random Read: 1,400,000 IOPS
• Random Write: 350,000 IOPS

Enhanced Data Transfer Rates with SAS 24Gbps

The SAS 24Gbps interface is a significant upgrade from its predecessors, offering double the bandwidth and ensuring minimal latency. This feature makes the Kioxia PM6-V Series SSD ideal for use in databases, virtualization environments, and high-frequency trading platforms.

Optimized for Mixed-Use Workloads

With its balance of read and write performance, this SSD supports mixed-use workloads such as online transaction processing (OLTP), virtual desktop infrastructure (VDI), and data analytics. The endurance of the BiCS Flash TLC NAND further enhances reliability under intensive usage.

Advanced BiCS Flash Technology

What is BiCS Flash TLC?

BiCS Flash, or Bit Cost Scalable Flash, is Kioxia's proprietary NAND technology that stacks memory cells vertically to increase density and performance. The Triple-Level Cell (TLC) architecture allows each cell to store three bits of data, balancing performance, capacity, and endurance.

Benefits of BiCS Flash in Enterprise Environments

• Higher Storage Density: Maximizes capacity in small form factors
• Improved Data Integrity: Reduces error rates through advanced error-correction algorithms
• Enhanced Reliability: Suitable for enterprise-grade, mission-critical applications

Power Efficiency and Thermal Management

Low Power Consumption

The Kioxia PM6-V Series SSD is designed to operate efficiently, consuming minimal power even under heavy workloads. Key power consumption metrics include:

• Active Read: 8.0W
• Active Write: 9.0W
• Idle Power: 4.5W

Thermal Management Features

Equipped with advanced thermal sensors, the drive monitors and manages its temperature during operation. This ensures consistent performance and prevents overheating, which is critical for maintaining data integrity and extending drive longevity.

Reliability and Endurance

Enterprise-Class Durability

Built to withstand the demands of continuous operation, the Kioxia PM6-V Series SSD offers enterprise-class endurance with a robust Mean Time Between Failures (MTBF) rating of 2.5 million hours. It also supports Power Loss Protection (PLP) to safeguard data during unexpected power outages.

Write Endurance for Mixed-Use Applications

The drive's write endurance is rated at 1 Drive Write Per Day (DWPD), making it suitable for workloads that balance read and write operations. This level of endurance ensures reliability for tasks such as transaction logging, data caching, and dynamic data processing.

Key Applications for the Kioxia 12.8TB SAS SSD

Enterprise Data Centers

With its high capacity, speed, and endurance, the Kioxia PM6-V Series SSD is an excellent choice for enterprise data centers. It supports critical applications such as:

• Cloud computing
• Virtualization
• Database management
• High-performance computing (HPC)

High-Performance Workloads

The drive is optimized for environments requiring rapid data access and processing, including:

• Real-time analytics
• Content delivery networks (CDNs)
• AI and machine learning applications

Expansion and Connectivity Options

The U.2 interface ensures seamless connectivity with modern server and storage infrastructures. The backward compatibility of the SAS interface with 12Gbps and 6Gbps standards further enhances versatility in mixed environments.

Compatibility with Storage Arrays

This SSD is compatible with a wide range of enterprise storage arrays, providing flexibility for IT administrators to optimize storage resources and scale infrastructure efficiently.

Security Features

Data Encryption and Protection

The Kioxia PM6-V Series SSD includes advanced security features, such as Self-Encrypting Drive (SED) technology and TCG Enterprise SSC compliance. These features protect sensitive data from unauthorized access and ensure regulatory compliance.

Data Integrity and Error Correction

The drive leverages advanced ECC (Error Correction Code) and end-to-end data protection mechanisms to prevent data corruption. This ensures the accuracy and reliability of stored information, even in high-stress environments.

Summary of Key Advantages

Why Choose the Kioxia 12.8TB SAS SSD?

The Kioxia KPM6XVUG12T8 12.8TB SAS SSD offers a compelling mix of performance, reliability, and advanced features. Its ability to handle mixed-use workloads, combined with its energy efficiency and robust security, makes it a valuable asset for enterprises aiming to modernize their storage infrastructure.

• Exceptional speed and performance for data-intensive tasks
• Robust endurance for continuous operation
• Compact form factor for easy integration
• Enterprise-grade security and data protection
