IE-3000-8TC Cisco Industrial Ethernet 3000 Series Managed Switch, 8 Ports

Ports

8 Ports for Seamless Connectivity

The Cisco IE-3000-8TC Managed Switch is equipped with 8 ports, providing seamless connectivity for your network infrastructure. These ports allow you to connect multiple devices such as computers, printers, servers, and other networking equipment, enabling effective communication and data transfer within your organization.

Product Details

• Manufacturer: Cisco
• Model Number: IE-3000-8TC
• Product Series: 3000
• Type: Ethernet Switch

Interface and Port Configuration

• Total Network Ports: 10
• RJ-45 Network Ports: 8
• Fast Ethernet Ports: 8
• Gigabit Ethernet Expansion Slots: 2

Performance Specifications

• Ethernet Technology: Gigabit Ethernet
• Network Technology: 10/100Base-TX
• Forwarding Rate: 6.5 Mpps (64-byte packets)

Memory and Addressing

• DRAM: 128 MB
• Compact Flash: 64 MB
• MAC Addresses (Layer 2): Up to 8000
• MAC Addresses (Layer 3): Up to 2000
• IGMP Multicast Groups (Layer 2): Up to 256
• IGMP Groups/Multicast Routes (Layer 3): Up to 1000
• Unicast Routes (Layer 3): Up to 3000

Switching Capabilities

• Ports: 10/100 and 10/100/1000
• Switching Fabric: 16 Gbps

Expansion and Management

• Total Expansion Slots: 6
• Expansion Slot Type: SFP
• SFP Slots: 2

Management Features

• Layer Supported: 2
• Manageable: Yes

Power and Environmental Specifications

• Power Source: Power Supply

Environmental Conditions

• Operating Temperature:
  • -40°C to +75°C
  • -40°C to +70°C (Vented Enclosure – 40 LFM Air Flow)
  • -40°C to +60°C (Sealed Enclosure – 0 LFM Air Flow)
  • -24°C to +75°C (Fan or Blower equipped Enclosure – 200 LFM Air Flow)
  • -40°C to +85°C (IEC 60068-2-2 Environmental Type Testing – 16 hours)
• Storage Temperature: -40°C to +85°C
• Operating Relative Humidity: 10% to 95% (non-condensing)
• Operating Altitude: Up to 13,000 ft (3963 m)
• Storage Altitude: Up to 15,000 ft (4573 m)

Additional Features and Compliance

• Additional Information:
  • 2 dual-purpose uplinks (each port features one 10/100/1000 Ethernet and one SFP-based Gigabit Ethernet port, with one port active)
• Compliant Standards:
  • AS/NZS 3548, BSMI CNS 13438 Class A, CB, CISPR 22, CISPR 24
  • CSA C22.2 No. 60950-1, CSA C22.2 No. 60950-1-03, cUL, EN 50081-2
  • EN 50082-2, EN55022, EN55024, FCC Part 15 A, IEC 60950
  • IEC 60950-1, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5
  • MIC, NOM, UL, UL 508, UL 60950-1, VCCI Class A ITE

Increased Flexibility and Scalability

With its 8 ports, this managed switch offers increased flexibility and scalability for your network. You can easily expand your network by connecting additional devices without the need for extra hardware or complex configurations. This ensures that your network can grow along with your business needs, saving you time and resources.

Efficient Data Transfer

The 8 ports on the Cisco IE-3000-8TC Managed Switch support high-speed data transfer, allowing for efficient communication between connected devices. Whether you are transferring large files, streaming media, or running bandwidth-intensive applications, these ports ensure that data is transmitted quickly and reliably.

Improved Network Performance

By utilizing the 8 ports of this managed switch, you can distribute network traffic more effectively. This helps to prevent bottlenecks and congestion, resulting in improved overall network performance. With each port dedicated to a specific device or segment of your network, you can prioritize critical traffic and ensure smooth operation of your business-critical applications.

Easy Network Management

Managing a network with multiple devices can be challenging, but the Cisco IE-3000-8TC Managed Switch simplifies this task with its 8 ports.

Centralized Control

Having 8 ports allows you to consolidate your network devices into a single manageable unit. Instead of dealing with multiple switches or routers scattered throughout your office, you can connect all your devices to the Cisco IE-3000-8TC Managed Switch, reducing complexity and making it easier to monitor and manage your network.

Streamlined Configuration

The 8 ports on this managed switch make configuration and setup a breeze. With fewer ports to handle, you can quickly assign IP addresses, configure VLANs, set up Quality of Service (QoS) policies, and implement security measures. This saves you valuable time during the initial setup process and simplifies ongoing network maintenance.

Enhanced Network Security

Securing your network is crucial in today's digital landscape, and the Cisco IE-3000-8TC Managed Switch with its 8 ports offers enhanced network security features.

VLAN Support

Virtual Local Area Network (VLAN) support allows you to divide your network into logical segments, isolating traffic and enhancing security. With 8 ports at your disposal, you can create multiple VLANs to separate different departments, guest networks, or critical systems, ensuring that sensitive data remains protected.

Access Control

The Cisco IE-3000-8TC Managed Switch provides advanced access control capabilities. With its 8 ports, you can implement granular access policies, allowing or denying specific devices or users from connecting to your network. This helps to prevent unauthorized access and protects your network from potential threats.

Port Security

Each of the 8 ports on this managed switch supports port security features. You can configure MAC address-based port security to ensure that only authorized devices can connect to specific ports. This prevents unauthorized devices from accessing your network and adds an additional layer of protection against potential security breaches.

Secure Remote Management

The Cisco IE-3000-8TC Managed Switch supports secure remote management through protocols such as Secure Shell (SSH) and Secure Sockets Layer (SSL). These protocols encrypt communication between your management station and the switch, ensuring that sensitive information remains confidential and protected from unauthorized interception.

In conclusion, the Cisco IE-3000-8TC Managed Switch's 8 ports offer numerous benefits and importance for users. They provide seamless connectivity, increased flexibility, efficient data transfer, and improved network performance. The easy network management capabilities simplify configuration and centralize control, while the enhanced network security features protect your organization's valuable data. With its comprehensive range of features, the Cisco IE-3000-8TC Managed Switch is an ideal choice for businesses of all sizes looking to optimize their network infrastructure.
