SSDPE2KX040T7K Intel P4500 4TB 2.5" PCI-e NVMe TLC DC 3.1 X4 SSD

Main Details of Intel 4TB NVMe SSD

The Intel SSDPE2KX040T7K is a cutting-edge 4TB internal solid-state drive (SSD) engineered for data-intensive enterprise environments. Designed with PCI Express 3.1 x4 and NVMe technology, this 2.5-inch drive delivers exceptional read performance, making it ideal for read-centric workloads in data centers and high-demand server infrastructures.

Manufacturer Details

• Brand: Intel Corporation
• Model Number: SSDPE2KX040T7K
• Device Category: Internal Enterprise SSD

Technical Specifications

Storage Capacity & Physical Design

• Total Storage: 4 Terabytes
• Drive Size: 2.5-Inch Small Form Factor
• Ideal Use: Enterprise servers and data center applications

Interface & Connectivity

• Interface Type: PCIe Gen 3.1 x4
• Protocol: NVMe (Non-Volatile Memory Express)
• Connector: U.2 / SFF-8639 for high-speed data transfer

Flash Memory Technology

• Memory Type: 3D NAND Flash
• Cell Structure: Triple-Level Cell (TLC) architecture

Performance Metrics

• Sequential Read Speed: Up to 3,270 MB/s
• Sequential Write Speed: Up to 1,860 MB/s
• Random Read IOPS (100% span): 645,000
• Random Write IOPS (100% span): 48,000

System Compatibility Requirements

Hardware Prerequisites

• U.2/SFF-8639 Port: Required for physical connection; resembles SATA but with extra pins for PCIe signals
• PCIe x4 Lane Support: Host motherboard or server backplane must support four-lane PCIe via U.2

Software & Driver Support

• NVMe Driver Integration: Operating system must include NVMe protocol drivers
• Supported OS Platforms: Compatible with modern server operating systems such as:
  • Microsoft Windows Server
  • Linux Distributions
  • VMware ESXi

Choose Intel DC P4500 4TB NVMe SSD

• Optimized for read-intensive enterprise workloads
• Superior data throughput with PCIe 3.1 x4 interface
• Reliable 3D TLC NAND for endurance and efficiency
• Ideal for cloud storage, virtualization, and big data analytics

Intel SSDPE2KX040T7K 4TB TLC NVME SFF SSD Overview

The Intel SSDPE2KX040T7K Express 3.1 X4 (NVMe) TLC DC P4500 4TB 2.5-Inch PCI Read Intensive Internal Solid State Drive represents a high-performance storage solution designed specifically for enterprise-grade environments. This solid-state drive is optimized for read-intensive workloads, delivering consistent and reliable performance in data centers, cloud computing infrastructures, and storage arrays where high throughput and low latency are essential.

Advanced NVMe Technology for Enterprise Storage

This Intel DC P4500 SSD leverages the PCIe 3.1 x4 interface combined with the NVMe protocol, providing superior bandwidth and significantly reduced latency compared to traditional SATA SSDs. The NVMe architecture allows multiple queues and parallel command processing, ensuring that large-scale enterprise applications experience minimal bottlenecks. It is particularly suitable for environments that demand high-speed read operations such as data analytics, virtualization, and online transaction processing systems.

Read-Intensive Performance Capabilities

The 4TB capacity Intel SSDPE2KX040T7K is engineered for read-intensive use cases, making it ideal for applications with predominantly read operations. With enhanced endurance and optimized wear-leveling algorithms, this SSD ensures extended reliability over its operational lifetime. Enterprises benefit from predictable performance under sustained workloads, maintaining consistent throughput across critical operations. Read-intensive SSDs like the DC P4500 series are essential in storage configurations where high-speed access to frequently accessed datasets is required.

3D NAND TLC Architecture

Utilizing Intel’s 3D NAND Triple-Level Cell (TLC) technology, the SSD delivers high storage density while maintaining excellent performance characteristics. The 3D NAND structure stacks memory cells vertically, allowing greater storage capacity within the same physical footprint. This architecture provides enhanced endurance and power efficiency, making it ideal for large-scale deployments where space and energy consumption are critical considerations.

Enterprise-Class Reliability and Endurance

Reliability is a key feature of the Intel DC P4500 series. The SSD is designed to withstand rigorous enterprise workloads, incorporating features such as end-to-end data protection, power-loss protection, and advanced error correction mechanisms. These technologies ensure data integrity even under challenging operational conditions. In addition, the drive supports consistent performance metrics, which are critical for mission-critical applications in financial services, healthcare, and cloud storage services.

Scalability and Data Center Integration

Designed for seamless integration into enterprise storage architectures, the Intel DC P4500 series offers excellent scalability. Data centers can deploy multiple SSDs in RAID configurations or software-defined storage systems to maximize capacity and performance. The drive's 2.5-inch form factor allows compatibility with a wide range of server and storage chassis, providing flexibility in high-density storage deployments. Organizations can scale storage solutions without compromising performance or reliability.

Power Efficiency and Thermal Management

Power efficiency is a critical consideration in enterprise storage solutions, and the DC P4500 series delivers optimized energy consumption without compromising performance. The drive employs advanced power management techniques to reduce idle power usage and improve overall energy efficiency. Effective thermal management ensures that the SSD maintains optimal operating temperatures, extending device longevity and maintaining stable performance under continuous workloads.

Compatibility and Deployment Considerations

The Intel SSDPE2KX040T7K 4TB NVMe drive is compatible with a wide range of enterprise server platforms and storage systems. It supports standard NVMe drivers and is recognized by modern operating systems, making deployment straightforward. Storage administrators can easily incorporate the drive into existing data center infrastructure, leveraging its high-capacity, read-intensive design to enhance storage efficiency and overall system performance.

Performance Metrics and Benchmarking

Benchmarks for the Intel DC P4500 series indicate high sequential read speeds and low latency, demonstrating the drive's suitability for demanding enterprise workloads. Consistent IOPS performance ensures that applications relying on rapid access to large datasets can operate efficiently. The combination of NVMe protocol optimization, TLC 3D NAND technology, and enterprise-grade reliability positions this SSD as a top-tier solution for high-performance storage environments.
