Intel PK8071305074601 Xeon Platinum 8454H Processor 2.10GHz 32 Cores

Intel PK8071305074601 Xeon Platinum 8454H Processor

The Intel PK8071305074601 Xeon Platinum 8454H Processor represents the pinnacle of Intel’s server-grade performance, designed to meet the demands of modern data centers, enterprise applications, and high-performance computing environments. With 32 cores and 64 threads, a base frequency of 2.10GHz, and a thermal design power (TDP) of 270W, this processor delivers exceptional processing power and efficiency for a wide range of computational tasks. The Xeon Platinum 8454H combines cutting-edge technology with advanced features to offer unparalleled performance, scalability, and reliability.

Intel Xeon PK8071305074601 Processor

Manufacturer and Product Information

General Overview

• Socket Type: FCLGA4677
• Part Number: PK8071305074601
• Note: The package does not include a heatsink, accessories, or tools.

Performance Metrics

Clock Speeds

• Base Clock Speed: 2.10 GHz
• Maximum Turbo Frequency: 3.40 GHz

Core and Thread Count

• Total Cores: 32
• Total Threads: 64

Cache and Thermal Design

• Cache Size: 82.5 MB
• Thermal Design Power (TDP): 270 W

Intel UPI Specifications

• Intel UPI Speed: 16 GT/s
• Maximum Number of UPI Links: 4

Memory Capabilities

Supported Memory Types and Capacities

• Maximum Memory Size: 4 TB (4,000 GB), depending on memory type
• Supported Memory Types:
  • DDR5 up to 4800 MT/s (1DPC)
  • DDR5 up to 4400 MT/s (2DPC)
• Maximum Number of Memory Channels: 8
• Error Correction Code (ECC) Support: Yes

Expansion and Connectivity

Scalability and PCI Express Details

• Scalability: S8S
• PCI Express Revision: 5.0
• Maximum Number of PCI Express Lanes: 80

Advanced Technologies

Intel Innovations and Features

• Intel On-Demand Feature Activation: Yes
• Intel QuickAssist Technology (QAT): 4 Default Devices
• Intel Dynamic Load Balancer (DLB): 4 Default Devices
• Intel Data Streaming Accelerator (DSA): 4 Default Devices
• Intel In-Memory Analytics Accelerator (IAA): 4 Default Devices
• Intel Advanced Matrix Extensions (AMX): Yes
• Intel Speed Select Technology - Core Power: Yes
• Intel Speed Select Technology - Turbo Frequency: Yes
• Intel Deep Learning Boost (Intel DL Boost): Yes
• Intel Speed Select Technology - Base Frequency: Yes
• High Priority Cores: 12
• High Priority Core Frequency: 2.20 GHz
• Low Priority Cores: 20
• Low Priority Core Frequency: 1.80 GHz
• Intel Resource Director Technology (RDT): Yes
• Intel Speed Shift Technology: Yes
• Intel Turbo Boost Technology: 2.0
• Intel Hyper-Threading Technology: Yes
• Intel Transactional Synchronization Extensions (TSX): Yes
• Intel 64: Yes
• Instruction Set Extensions: Intel AMX, Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512
• Number of AVX-512 FMA Units: 2

Security and Reliability Features

Comprehensive Security Technologies

• Intel Crypto Acceleration: Yes
• Intel QuickAssist Software Acceleration: Yes
• Intel Platform Firmware Resilience Support: Yes
• Intel Control Flow Enforcement Technology: Yes
• Intel Total Memory Encryption: Yes
• Intel Advanced Encryption Standard AES New Instructions: Yes
• Intel Software Guard Extensions (SGX): Yes (with Intel SPS)
• Maximum Enclave Page Cache (EPC) Size for Intel SGX: 512 GB
• Intel OS Guard: Yes
• Intel Trusted Execution Technology: Yes
• Execute Disable Bit: Yes
• Intel Boot Guard: Yes
• Intel Run Sure Technology: Yes
• Mode-Based Execute Control (MBEC): Yes
• Intel Virtualization Technology (VT-x): Yes
• Intel Virtualization Technology for Directed I/O (VT-d): Yes
• Intel VT-x with Extended Page Tables (EPT): Yes

High Core Count and Threading Capabilities

The Intel Xeon Platinum 8454H is equipped with 32 cores and 64 threads, providing robust multi-threaded performance. This high core count is particularly advantageous for applications that require significant parallel processing capabilities, such as virtualization, cloud computing, and large-scale data analytics. The ability to handle multiple threads per core ensures efficient execution of complex tasks and improved overall system responsiveness.

Enhanced Multithreading for Optimal Performance

With its 64 threads, the Xeon Platinum 8454H is capable of managing multiple simultaneous processes, making it ideal for environments where high parallelism is required. This feature enhances performance in multi-threaded applications and workloads that involve extensive data processing and high concurrency.

Clock Speed and Turbo Boost Technology

The processor operates at a base frequency of 2.10GHz, providing a stable performance foundation. Intel Turbo Boost Technology further enhances performance by dynamically increasing the processor’s clock speed during high-demand scenarios. This technology allows the Xeon Platinum 8454H to deliver higher processing speeds when needed, improving performance for bursty workloads and applications that require rapid data access.

Dynamic Frequency Scaling

Turbo Boost Technology intelligently adjusts the clock speed based on workload requirements and thermal conditions. This dynamic frequency scaling ensures that the processor delivers optimal performance while balancing power consumption and thermal output, making it suitable for a wide range of applications and usage scenarios.

Cache and Memory Support

The Xeon Platinum 8454H features a substantial 48 MB Intel Smart Cache, which enhances data access speeds and reduces latency. This large cache size is crucial for applications that handle large datasets or require frequent data retrieval. The processor also supports up to 8 channels of DDR5 memory, providing high memory bandwidth and capacity for demanding applications.

Memory Bandwidth and Capacity

Support for DDR5 memory allows the Xeon Platinum 8454H to take advantage of increased memory bandwidth and higher data transfer rates. This capability is essential for applications that require large amounts of memory and fast data access, such as in-memory databases and high-performance computing tasks.

Intel Optane Persistent Memory

The Xeon Platinum 8454H is compatible with Intel Optane Persistent Memory, which offers additional memory capacity and faster data access compared to traditional DRAM. This technology provides a balance between memory speed and persistence, making it suitable for applications that handle large-scale data and require high performance, such as big data analytics and enterprise applications.

Thermal Design Power (TDP) and Power Efficiency

With a TDP of 270W, the Xeon Platinum 8454H is designed to deliver high performance while managing power consumption efficiently. The processor’s thermal management features ensure that it operates within safe temperature ranges even during intensive workloads. This high TDP rating indicates that the processor can sustain peak performance levels, making it suitable for demanding applications and environments.

Advanced Power Management Technologies

Intel’s power management technologies help optimize power usage based on workload demands. These features include dynamic voltage and frequency scaling, which adjust the processor’s power consumption and performance based on real-time conditions. Efficient power management reduces overall energy costs and helps maintain system stability and longevity.

Core and Thread Configuration

The Xeon Platinum 8454H boasts 32 cores and 64 threads, making it well-suited for applications that require high parallel processing capabilities. This configuration enables the processor to handle multiple tasks simultaneously, enhancing performance for data-intensive applications and complex computational tasks.

Clock Speed and Turbo Boost Capabilities

Operating at a base clock speed of 2.10GHz, the Xeon Platinum 8454H delivers reliable performance across a range of workloads. Turbo Boost Technology further enhances performance by increasing the processor’s clock speed during high-demand periods, providing additional processing power when needed for bursty tasks and high-speed computations.

Cache Size and Memory Support

The processor’s 48 MB Intel Smart Cache improves data retrieval times and reduces latency, benefiting applications that require frequent data access. The support for up to 8 channels of DDR5 memory ensures high bandwidth and capacity, making the Xeon Platinum 8454H suitable for memory-intensive applications and large-scale deployments.

Thermal Design Power (TDP)

The Xeon Platinum 8454H’s 270W TDP indicates its capability to handle demanding workloads while managing power consumption effectively. This high TDP rating reflects the processor’s ability to maintain peak performance levels and manage heat dissipation efficiently, ensuring reliable operation even under heavy loads.

Applications and Use Cases

Data Centers and Cloud Computing

The Xeon Platinum 8454H is ideally suited for data centers and cloud computing environments, where its high core count and scalability provide significant advantages. The processor supports virtualization, allowing multiple virtual machines to run concurrently and efficiently, making it an excellent choice for cloud service providers and enterprise IT environments.

High-Performance Computing (HPC)

In high-performance computing scenarios, the Xeon Platinum 8454H excels due to its high core count and advanced architecture. It is ideal for scientific research, financial modeling, and simulations that require substantial processing power and efficient parallel execution. The processor’s performance capabilities enable faster computations and improved efficiency for complex tasks.

Artificial Intelligence and Machine Learning

The Xeon Platinum 8454H’s support for Intel Deep Learning Boost (DL Boost) and AVX-512 makes it well-suited for AI and machine learning applications. The processor accelerates deep learning training and inferencing tasks, improving model accuracy and deployment speed. It is particularly effective for applications in natural language processing, image recognition, and real-time data analysis.

Enterprise Resource Planning (ERP) and Large Databases

For enterprise resource planning (ERP) systems and large database management, the Xeon Platinum 8454H provides the necessary performance and scalability. Its large cache size and high memory support ensure efficient data retrieval and processing, making it suitable for managing complex business operations and large-scale datasets.

Architectural Innovations and Technologies

4th Generation Intel Xeon Scalable Architecture

The Xeon Platinum 8454H is built on Intel’s 4th Generation Xeon Scalable architecture, which introduces significant advancements in performance, security, and scalability. This architecture features improved core designs, faster interconnects, and support for next-generation memory technologies, ensuring that the processor meets the demands of contemporary computing environments.

Intel Deep Learning Boost (DL Boost)

Intel DL Boost technology enhances the performance of AI and machine learning applications by optimizing processor instructions for deep learning tasks. The Xeon Platinum 8454H’s integration with DL Boost accelerates neural network processing, reducing training times and improving inferencing capabilities for AI models.

Vector Neural Network Instructions (VNNI)

VNNI is a key component of Intel DL Boost that improves the execution of convolutional neural networks (CNNs). By optimizing these operations, VNNI accelerates AI tasks such as image recognition and natural language processing, providing faster and more accurate results for AI-driven applications.

Intel Advanced Vector Extensions 512 (AVX-512)

The Xeon Platinum 8454H supports AVX-512, which enhances the processor’s ability to handle complex vector and floating-point calculations. This support is beneficial for applications that require intensive numerical computations, such as scientific simulations, financial modeling, and high-performance analytics.

Security Features: Intel SGX and TME

Intel SGX (Software Guard Extensions) and TME (Total Memory Encryption) provide robust security features for the Xeon Platinum 8454H. SGX creates secure enclaves within the processor to protect sensitive data, while TME ensures that all memory data is encrypted, safeguarding against unauthorized access and physical attacks.

Intel Software Guard Extensions (SGX)

SGX enables secure enclaves that protect code and data from unauthorized access, ensuring that sensitive information remains confidential. This technology is essential for applications that handle highly confidential data, such as financial transactions and private business information.

Total Memory Encryption (TME)

TME provides encryption for all memory contents, offering additional protection against data breaches and physical attacks. This feature enhances data confidentiality and integrity, making it suitable for high-security environments where data protection is critical.

Energy Efficiency and Operational Cost Management

Optimized Energy Efficiency

The Xeon Platinum 8454H balances high performance with energy efficiency. Its advanced power management features help optimize energy consumption based on workload demands, reducing overall power usage and minimizing operational costs. Efficient energy use is crucial for data centers looking to lower energy expenditures while maintaining high performance.

Effective Thermal Management

Effective thermal management is a key aspect of the Xeon Platinum 8454H’s design. The processor incorporates advanced cooling technologies to manage heat dissipation, ensuring reliable operation even under heavy workloads. Proper thermal management helps extend the hardware’s lifespan and reduces maintenance requirements.

Dynamic Power and Thermal Management

Dynamic power and thermal management features adjust processor performance and power consumption in real-time based on workload and temperature conditions. This capability helps to optimize energy use, improve system stability, and maintain consistent performance across various applications.

Market Adoption and Competitive Advantages

Adoption in Enterprise and Cloud Environments

The Xeon Platinum 8454H is widely adopted in enterprise IT environments and cloud computing platforms due to its high performance, scalability, and efficiency. Organizations leverage this processor to support a wide range of applications, from cloud services to virtualization, benefiting from its ability to handle diverse and demanding workloads.

Comparison with Competitors

When compared to competitors, the Xeon Platinum 8454H offers a unique combination of core count, performance, and advanced features. Its support for next-generation technologies, high-speed processing, and security enhancements make it a strong contender in the high-performance processor market, providing a competitive edge for organizations seeking top-tier computing power.

Long-Term Value and Return on Investment

The Xeon Platinum 8454H delivers long-term value through its high performance, efficiency, and advanced features. Its ability to handle a wide range of applications and workloads ensures a strong return on investment, reducing the need for frequent upgrades and lowering the total cost of ownership (TCO). Organizations investing in this processor can expect sustained performance and reliability, contributing to long-term operational success.
