Intel PK8071305501400 Xeon 24Core 48T 2.7GHz 67.5MB Processor

Product Overview

Overview

High-Performance Computing

• Processor Type: INTEL® Xeon® W Processor (W7-3545)
• Core Count: 24 performance cores
• Max Turbo Frequency: 4.8 GHz
• Base Frequency: 2.7 GHz
• Thread Count: 48 threads
• Cache: 67.5 MB INTEL® Smart Cache
• Power Efficiency: 310W base power, up to 372W maximum turbo power

Memory Specifications

Supported Memory and Capacity

• Max Memory Capacity: 4 TB
• Memory Type: DDR5-4800 (MT/s)
• Memory Channels: 8 channels
• ECC Memory Support: Yes

Advanced Processor Technologies

Intel® Technologies for Enhanced Performance

• Intel® Turbo Boost Max Technology 3.0: For dynamic performance scaling
• Intel® Hyper-Threading Technology: Increases multitasking efficiency
• Intel® Deep Learning Boost: Optimized for AI and machine learning workloads
• PCI Express 5.0 Support: 112 lanes for faster data throughput

Package Details

Processor Socket and Size

• Socket Type: FCLGA4677
• Package Dimensions: 77.5mm x 56.5mm

Security Features

Intel® Security Technologies

• Intel® vPro® Enterprise Compatibility: Enhanced security and manageability
• Intel® Trusted Execution Technology: Protects against threats and unauthorized access
• Enhanced Memory Encryption: Provides additional protection for sensitive data

Overview of Intel PK8071305501400 Xeon W7-3545 2.7GHz 24-Core Processor

The Intel PK8071305501400 Xeon W7-3545 Processor is a high-performance computing powerhouse, designed to meet the demanding requirements of enterprise workloads and professional applications. With 24 cores and 48 threads, this processor is engineered to handle even the most intensive multi-threaded applications with remarkable speed and efficiency. Clocked at a base frequency of 2.7GHz and equipped with a substantial 67.5MB of cache, the Xeon W7-3545 delivers superior performance across various industries, including data centers, cloud computing, and high-performance computing (HPC). Its reliability, scalability, and advanced architecture make it ideal for business-critical applications, real-time analytics, virtualization, and more.

Key Features of the Intel Xeon W7-3545 Processor

• 24 Cores and 48 Threads: With 24 cores and 48 threads, the Xeon W7-3545 excels in parallel processing, allowing it to efficiently manage multiple concurrent workloads. This configuration provides optimal performance for multi-threaded applications, such as virtualization, cloud services, and data analytics.
• Base Clock Speed of 2.7GHz: The processor operates at a base clock speed of 2.7GHz, offering fast processing speeds for demanding applications. The base clock can scale dynamically with Intel's Turbo Boost technology to higher frequencies when additional processing power is needed.
• 67.5MB Intel Smart Cache: The Xeon W7-3545 features 67.5MB of Intel Smart Cache, enabling fast data retrieval and improved performance in data-intensive workloads, reducing latency and accelerating task completion times.
• Enhanced Scalability: The processor supports Intel's advanced features, such as Intel AVX-512, Intel Hyper-Threading, and Intel Turbo Boost, providing scalability and flexibility to meet the ever-evolving demands of enterprise-level computing and large-scale deployments.
• High Performance and Efficiency: With its robust architecture, the Xeon W7-3545 strikes a balance between exceptional performance and energy efficiency, enabling businesses to run complex applications without compromising on power consumption.

Performance and Efficiency

The Intel Xeon W7-3545 processor delivers superior performance while maintaining energy efficiency, making it ideal for enterprises seeking to optimize both computational power and operational costs. This balance between power and efficiency makes it suitable for a variety of demanding workloads, from large-scale virtualization to high-performance computing (HPC).

Optimized for Parallel Computing

The 24-core and 48-thread configuration of the Xeon W7-3545 enables exceptional performance in parallel computing environments. Applications that require simultaneous processing of multiple tasks, such as virtualized environments, data analytics, and scientific simulations, can benefit from the processor’s robust multi-threading capabilities. The processor’s ability to manage several tasks concurrently reduces processing times and enhances overall system throughput.

Multi-Threading Performance

With Intel Hyper-Threading Technology, the Xeon W7-3545 doubles the number of logical processors, enabling the efficient handling of multi-threaded workloads. This results in improved throughput and a smoother user experience in data-intensive applications such as video rendering, machine learning, and large-scale enterprise databases.

High-Performance Computing (HPC)

For high-performance computing (HPC) applications, the Xeon W7-3545 processor provides the necessary horsepower to run simulations, data analysis, and scientific computations. Its massive core count ensures that even the most complex and resource-demanding tasks can be processed efficiently, supporting industries such as bioinformatics, financial modeling, and engineering simulations.

Intel Turbo Boost Technology

Intel Turbo Boost Technology enhances the Xeon W7-3545’s performance by automatically increasing the processor’s clock speed during demanding workloads. The processor can dynamically scale from its base clock speed of 2.7GHz to higher frequencies, delivering superior performance when needed for tasks like real-time data processing, analytics, and transaction-heavy applications.

Dynamic Performance Scaling

Turbo Boost dynamically adjusts the processor’s frequency based on current workloads and thermal conditions. This feature allows for optimal performance during periods of heavy processing, while also conserving energy during lighter workloads, ensuring that the Xeon W7-3545 operates efficiently under various conditions.

Energy Efficiency

Despite its exceptional performance capabilities, the Xeon W7-3545 maintains high energy efficiency. Intel’s power management technologies, combined with the processor’s efficient architecture, minimize power consumption while delivering consistent performance. This is crucial for enterprises that require optimal performance without incurring high energy costs or excessive heat output.

Applications and Use Cases

The Intel Xeon W7-3545 processor is built for versatility, excelling in numerous enterprise and professional environments where high performance and scalability are essential. Its robust core architecture, combined with advanced features, makes it a perfect fit for cloud services, data centers, virtualization, AI/ML, and high-performance computing tasks.

Virtualization and Cloud Computing

One of the standout features of the Xeon W7-3545 is its ability to handle virtualized environments. With 24 cores and 48 threads, the processor is designed to run multiple virtual machines (VMs) simultaneously without compromising performance. This is particularly beneficial for cloud computing platforms and enterprise data centers where resource allocation and virtualization are essential for scalability and efficiency.

Server Consolidation

The Xeon W7-3545 allows for efficient server consolidation, enabling businesses to run more virtualized workloads on fewer physical servers. This results in reduced hardware and energy costs, making it an ideal solution for modern enterprise IT infrastructures seeking to optimize resource allocation while maintaining high levels of service and performance.

High-Density Virtual Environments

For cloud providers and enterprises operating large-scale virtual environments, the Xeon W7-3545 offers the necessary performance to support high-density workloads, ensuring that multiple virtualized applications can run concurrently without performance degradation. The processor’s ability to handle several virtual machines makes it ideal for private and hybrid cloud environments where efficiency and scalability are paramount.

Artificial Intelligence (AI) and Machine Learning (ML)

As AI and machine learning (ML) continue to evolve, so does the demand for high-performance processors that can handle complex computations and large datasets. The Xeon W7-3545 processor excels in AI/ML workloads, offering the processing power needed to run training models, process real-time data, and support inference tasks for AI applications.

AI Training

Training machine learning models requires processing vast amounts of data to build algorithms that can make predictions or decisions. The 24 cores and 48 threads of the Xeon W7-3545 are perfectly suited for running these computationally heavy training tasks, reducing the time required to process large datasets and enabling faster model development.

AI Inference and Real-Time Processing

The Xeon W7-3545 can also handle real-time inference tasks, where AI models are deployed to make decisions based on incoming data. Its high clock speed and multi-core architecture ensure that real-time applications, such as speech recognition, video analysis, and autonomous vehicles, can function smoothly and efficiently.

High-Performance Computing (HPC)

High-performance computing (HPC) environments require processors that can handle large-scale simulations, data processing, and scientific computing. The Xeon W7-3545’s combination of core density, clock speed, and memory bandwidth makes it ideal for industries like research and development, engineering, and financial modeling that rely on computationally intensive tasks.

Scientific Simulations

For industries involved in scientific research, including physics, chemistry, and biology, the Xeon W7-3545 can accelerate simulations that model complex systems. The processor’s ability to handle large-scale parallel computations means that simulations are completed faster, enabling researchers to gain insights and results more quickly.

Engineering and Design Simulations

Engineering fields, particularly those involved in designing complex systems such as automotive, aerospace, and manufacturing, benefit from the Xeon W7-3545’s processing power. It enables high-fidelity simulations for fluid dynamics, mechanical stress testing, and more, reducing design time and improving accuracy.

Technical Specifications

The Intel Xeon W7-3545 processor is engineered to provide the highest levels of performance, scalability, and reliability for professional applications. Below are its key technical specifications.

Core Configuration

With 24 cores and 48 threads, the Xeon W7-3545 is built for heavy multi-threaded workloads, delivering impressive parallel processing capabilities that are essential for
