Intel SRN59 Xeon Platinum 48-Core CPU 2.3GHz 300mb Smart Cache

Intel Xeon Platinum 8568Y Processor Overview

The Intel Xeon Platinum 8568Y+ processor is a powerful, scalable 5th Generation CPU designed for data-driven environments requiring maximum performance and versatility. With 48 cores, up to 4.0 GHz Turbo frequency, and advanced Speed Select Technology, this processor is engineered to optimize server workloads and support complex applications.

Specifications and Key Features

General Product Information

• Model: Intel Xeon Platinum 8568Y+
• Part Number: SRN59
• Series: 5th Gen Intel Xeon Scalable, Platinum 8500 Series
• Core Architecture: Emerald Rapids
• Socket Type: FCLGA4677
• Note: Processor only; no heatsink, accessories, or tools included

Performance and Processing Power

Core Specifications

• Base Clock Speed: 2.3 GHz
• Maximum Turbo Frequency: 4.0 GHz
• Total Cores: 48
• Total Threads: 96
• Cache Memory: 300 MB
• Intel UPI Speed: 20 GT/s
• UPI Links Supported: 4

Thermal and Power Requirements

• Thermal Design Power (TDP): 350W
• Intel Lithography: Intel 7nm

Intel Speed Select Technology (SST-PP) - Performance Profiles

The Intel Speed Select Technology Performance Profile (SST-PP) allows dynamic configuration for optimized performance:

• Config 0: 48 cores, 2.3 GHz, 350W
• Config 1: 40 cores, 2.2 GHz, 300W
• Config 2: 36 cores, 2.3 GHz, 300W

Memory and Expansion Capabilities

Memory Specifications

• Max Memory Capacity: Up to 4 TB (4000 GB), depending on memory type
• Supported Memory Types: DDR5
• Max Memory Speeds: Up to 5600 MHz (1DPC)
• Error Correction Code (ECC): Supported
• Memory Channels: 8

Expansion Options

• Scalability: Supports 2-socket configurations
• PCIe Revision: 5.0
• Max PCIe Lanes: 80

Advanced Intel Technologies

Core Technologies and Enhancements

• Intel On Demand Activation: Enabled
• Intel QuickAssist Technology (QAT): Supported with 1 default device
• Intel Data Streaming Accelerator (DSA): Enabled
• Intel Advanced Matrix Extensions (AMX): Supported
• Intel Deep Learning Boost (DL Boost): Enabled for AI workloads

Performance Optimization

• Intel Speed Shift Technology: Base, Turbo, and Core Power configurations
• High Priority Cores: 16, with frequency at 2.5 GHz
• Low Priority Cores: 32, with frequency at 2.1 GHz
• Intel Resource Director Technology (RDT): Supported
• Intel Turbo Boost Technology 2.0: Yes

Security and Reliability Features

Security Enhancements

• Intel Trust Domain Extensions (TDX): Supported
• Intel Crypto Acceleration: Enabled
• Intel Platform Firmware Resilience: Yes
• Intel Control Flow Enforcement Technology (CET): Yes
• Intel Total Memory Encryption - Multi-Key: Supported

Reliability and Integrity

• Intel Software Guard Extensions (SGX): With SPS, 512GB EPC size
• Intel OS Guard: Yes
• Intel Trusted Execution Technology (TXT): Enabled
• Intel Execute Disable Bit: Yes
• Intel Boot Guard: Yes

Virtualization Support

• Intel Virtualization Technology (VT-x): Yes
• Intel Virtualization Technology for Directed I/O (VT-d): Supported
• Extended Page Tables (EPT): Enabled

Clock Speed: 2.3GHz

Enhanced Performance and Speed

The Intel Xeon Platinum 48-Core CPU is equipped with a clock speed of 2.3GHz, providing users with exceptional performance and speed. This clock speed is a crucial aspect of the CPU's capabilities, allowing it to execute instructions and complete tasks at a remarkable rate. Let's delve into the benefits and importance of this feature.

1. Lightning-Fast Processing

With a clock speed of 2.3GHz, the Intel Xeon Platinum CPU ensures lightning-fast processing. The higher the clock speed, the more instructions a CPU can execute per second. This means that tasks such as data crunching, complex calculations, and rendering graphics can be completed in significantly less time compared to CPUs with lower clock speeds. Whether you are a professional video editor, an engineer running simulations, or a gamer seeking high frame rates, this CPU's clock speed guarantees an exceptional experience.

2. Seamless Multitasking

Multitasking has become an integral part of our daily computing needs, whether it's running multiple applications simultaneously or handling resource-intensive workloads. The 2.3GHz clock speed of the Intel Xeon Platinum CPU ensures smooth multitasking without any noticeable lag or slowdowns. You can effortlessly switch between demanding software applications, run virtual machines, or handle large datasets without compromising performance.

3. Real-Time Responsiveness

In today's fast-paced digital world, real-time responsiveness is crucial for various applications and industries. The 2.3GHz clock speed enables the Intel Xeon Platinum CPU to deliver instantaneous responses to user input, ensuring a seamless and fluid user experience. From gaming to financial trading platforms, this feature guarantees that every action you take receives an immediate response from your system.

4. Improved Work Efficiency

For professionals who rely heavily on their computing devices to get work done, time is of the essence. The 2.3GHz clock speed of the Intel Xeon Platinum CPU significantly improves work efficiency by reducing processing times. Tasks that used to take hours can now be completed in a fraction of the time, enabling professionals to accomplish more within their deadlines. This increased efficiency translates into higher productivity and a competitive edge in today's fast-paced business environment.

5. Future-Proofing

Investing in a high clock speed CPU like the Intel Xeon Platinum 48-Core ensures future-proofing your system. As software and applications become more demanding and resource-intensive, a powerful CPU with a higher clock speed will be better equipped to handle the evolving technology landscape. By opting for a CPU with a clock speed of 2.3GHz, you can be confident that your system will remain capable and relevant for years to come.

Smart Cache: 300MB

Enhanced Performance and Efficiency

The Intel Xeon Platinum 48-Core CPU comes with a generous 300MB smart cache, offering enhanced performance and efficiency for users. The smart cache feature plays a crucial role in optimizing data access and retrieval, resulting in improved overall system performance. Let's explore the benefits and importance of this feature in more detail.

1. Faster Data Access

With a smart cache of 300MB, the Intel Xeon Platinum CPU ensures faster data access for your applications and processes. The smart cache acts as a high-speed memory bank that stores frequently accessed data closer to the CPU cores, reducing the time required to fetch data from main memory or external storage devices. This results in faster application response times, reduced latency, and improved overall system performance.

2. Efficient Data Retrieval

The smart cache feature efficiently retrieves data by predicting the data needed by the CPU cores in advance. When a core requests data, the smart cache intelligently analyzes the data access patterns and preloads relevant data into its cache. This predictive mechanism minimizes the time spent waiting for data to be fetched, enabling the CPU to execute instructions more efficiently. Whether you are running complex algorithms or processing large datasets, this feature ensures smooth and uninterrupted performance.

3. Reduced Memory Bottlenecks

Memory bottlenecks can significantly impact system performance, especially when dealing with large datasets or memory-intensive applications. The 300MB smart cache of the Intel Xeon Platinum CPU helps alleviate memory bottlenecks by storing frequently accessed data within the cache. This reduces the reliance on slower main memory, resulting in faster data retrieval and improved overall system responsiveness. Users can experience seamless multitasking and resource-intensive computing without being hindered by memory constraints.

4. Accelerated Workloads

The generous 300MB smart cache enables the Intel Xeon Platinum CPU to handle heavy workloads with ease. Whether you are running virtual machines, performing complex simulations, or processing massive amounts of data, this feature ensures efficient execution of workloads without compromising performance. The smart cache optimizes data access and retrieval, allowing the CPU to quickly access the necessary information and process it swiftly. This translates into reduced processing times, increased productivity, and smoother workflow.

5. Energy Efficiency

Efficiency is a crucial aspect of any modern computing system, both in terms of performance and power consumption. The smart cache feature plays a role in energy efficiency by reducing the need to access external memory frequently. By storing frequently accessed data within the cache, the CPU can minimize memory accesses that consume more power. This results in optimized power consumption, reduced heat generation, and ultimately a more energy-efficient system.
