Intel Xeon Gold 6328H Processor 16 Cores 32 CD8070604481201

Intel CD8070604481201 Xeon 2.8GHz Processor

Introduction to the Intel Xeon Gold 6328H Processor

• The Intel Xeon Gold 6328H is a high-performance processor designed for advanced server environments.
• Part of the 3rd Generation Intel Xeon Scalable family, it leverages the Cooper Lake architecture.
• This processor is engineered for data-centric tasks, providing efficiency and enhanced computing power.
• It offers robust capabilities with 16 cores and 32 threads, making it ideal for multi-threaded workloads.
• With a base clock speed of 2.80 GHz and a maximum turbo speed of 4.30 GHz, it delivers outstanding performance for demanding applications.

Main Specifications of Intel Xeon Gold 6328H Processor

Processor Overview

• Device Type: High-performance server processor
• Processor Number: 6328H
• Clock Speed: Base frequency of 2.80GHz
• Max Turbo Speed: Capable of reaching up to 4.30GHz
• Core Count: 16 cores for powerful multitasking
• Thread Count: 32 threads for efficient parallel processing
• QPI/UPI Links: Features 6 UPI links for high-speed interconnectivity
• Processor Family: 3rd Generation Intel Xeon Scalable Processor
• Codename: Based on Cooper Lake architecture
• Vertical Segment: Optimized for server environments

Performance Features

Advanced Processor Specifications

• Cache Size: Equipped with 22MB of cache for rapid data access
• Thermal Design Power (TDP): Operates at 165W, ensuring reliable performance

Memory Capabilities

• Max Memory Size: Supports up to 1.12TB of memory, based on configuration
• Memory Type: Compatible with DDR4 RDIMM modules
• Maximum Memory Speed: Operates at speeds up to 2933MHz
• Memory Channels: Utilizes 6 channels for enhanced memory bandwidth
• Intel Optane DC Persistent Memory: Fully supported, enhancing performance in demanding workloads

Expansion and Scalability

Scalability Options

• Supported Configurations: Supports scalability up to 4-socket systems for improved performance
• PCI Express Revision: PCIe 3.0 for robust connectivity
• PCI Express Lanes: Provides up to 48 lanes for extensive I/O capabilities

Package Specifications

• Socket Type: Compatible with FCLGA4189 socket
• Package Size: Compact design with a package size of 77.5mm x 56.5mm
• Package Type: Available as an OEM tray processor

Advanced Technologies and Features

Innovative Technology Integration

• Intel Speed Select Technology: Offers advanced power and performance management with core power and turbo frequency adjustments
• Intel Deep Learning Boost (DL Boost): Enhances AI and machine learning capabilities for faster inference
• Intel Resource Director Technology (RDT): Optimizes resource allocation to improve workload efficiency
• Intel Speed Shift Technology: Enables quicker transitions between power states for responsive computing
• Intel Hyper-Threading Technology: Improves parallel processing with simultaneous multi-threading

Virtualization and Security Enhancements

• Intel Virtualization Technology (VT-x): Supports hardware-assisted virtualization for better VM performance
• Intel Virtualization for Directed I/O (VT-d): Improves I/O device security in virtualized environments
• Intel Transactional Synchronization Extensions (TSX): Boosts transactional memory capabilities for multithreaded applications
• Instruction Set Extensions: Includes Intel SSE4.2, AVX, AVX2, and AVX-512 for enhanced processing power
• AVX-512 FMA Units: Equipped with 2 units for high throughput in floating-point operations
• Enhanced Intel SpeedStep Technology: Balances power and performance based on workload needs

Optimized for Diverse Workloads

Enterprise-Level Performance

• Ideal for mission-critical applications in data centers and enterprise servers
• Handles complex workloads with ease, thanks to its 16-core and 32-thread configuration

Virtualization and AI Applications

• Perfectly suited for virtualized environments, offering optimal performance for multiple virtual machines
• Enhances AI performance through integrated deep learning boosts and advanced AVX-512 instruction sets

Workstation and High-Performance Computing

• Provides reliable performance for scientific research, engineering simulations, and financial modeling
• Supports high memory bandwidth and large memory capacity for demanding workstation tasks

Performance and Efficiency

Core Features and Specifications

• Core Count: 16 cores designed to handle complex, multi-threaded tasks with ease.
• Thread Count: 32 threads, enabling superior multitasking and parallel processing capabilities.
• Base Clock Speed: Operating at 2.80 GHz for consistent and reliable performance across workloads.
• Turbo Boost: Reaches up to 4.30 GHz, allowing for bursts of speed during peak processing requirements.
• Cache Size: 22 MB of L3 cache, ensuring fast access to frequently used data, improving overall efficiency.

Thermal and Power Management

• Thermal Design Power (TDP): Rated at 165W, providing a balance between performance and energy consumption.
• Optimized power usage reduces operational costs, contributing to a lower Total Cost of Ownership (TCO).
• Enhanced thermal management features ensure stable operation even under high loads, safeguarding against overheating.

Advanced Technologies

Intel Deep Learning Boost

• Incorporates Intel Deep Learning Boost, enhancing AI performance by accelerating inference workloads.
• Supports bfloat16, a new numerical format that improves AI training efficiency and reduces memory bandwidth requirements.
• These technologies make the Xeon Gold 6328H an excellent choice for AI-driven applications, machine learning, and data analytics.

Security and Reliability Enhancements

• Includes Intel’s security technologies such as Intel AES New Instructions, enhancing encryption and protecting data integrity.
• Features Intel Run Sure Technology, which ensures maximum system uptime and reliability, critical for enterprise environments.
• Execute Disable Bit helps prevent buffer overflow attacks, adding an extra layer of security against common threats.

Expansion Options

• Scalability: Designed for 4-socket configurations, allowing businesses to scale performance as needed.
• PCI Express Revision: PCIe 3.0, providing robust connectivity options for additional hardware and peripherals.
• PCI Express Lanes: Up to 48 lanes available, enabling extensive I/O flexibility and scalability.

Applications and Use Cases

Data-Centric Workloads

• The Xeon Gold 6328H excels in environments where data processing and management are critical, such as cloud computing and big data analytics.
• Its advanced multi-core architecture makes it ideal for handling large datasets, running complex algorithms, and processing real-time information.

Artificial Intelligence and Machine Learning

• Perfectly suited for AI and ML applications, thanks to Intel Deep Learning Boost and support for bfloat16.
• These features accelerate neural network performance, reducing training times and increasing inference accuracy.
• The processor’s high core and thread count provide the parallel processing power necessary for AI model development and deployment.

Enterprise Servers and Virtualization

• Engineered for enterprise server environments, offering the power and scalability needed for large-scale deployments.
• Supports advanced virtualization technologies, making it an excellent choice for virtualized server farms and cloud infrastructure.
• The high thread count ensures optimal performance for multiple virtual machines, enhancing server consolidation efforts.

Cooling and Thermal Management

• Given its 165W TDP, it is crucial to use an efficient cooling solution to maintain performance and prevent thermal throttling.
• Recommended cooling solutions include high-performance heatsinks and liquid cooling systems, especially in dense server environments.

Power Supply Considerations

• Ensure that the server’s power supply can handle the processor’s demands, especially when using multiple processors or other power-hungry components.
• Power supply units with high efficiency ratings are recommended to reduce operational costs and improve overall energy management.

Industry-Leading Reliability

Intel Run Sure Technology

• Enhances reliability by providing built-in features for error detection and correction, ensuring data integrity during critical operations.
• Run Sure Technology minimizes downtime, making the Xeon Gold 6328H ideal for mission-critical applications where continuous operation is required.

Support for Error-Correcting Code (ECC) Memory

• Supports ECC memory, which automatically detects and corrects data corruption, enhancing overall system stability.
• This feature is essential in server and workstation environments where data accuracy is paramount.

Cost Efficiency and Total Cost of Ownership (TCO)

Energy-Efficient Performance

• Designed to deliver high performance with lower power consumption, reducing operational expenses over time.
• The optimized power and thermal management features contribute to a lower TCO, making the Xeon Gold 6328H a cost-effective solution for businesses.

Scalable Performance

• Allows enterprises to scale their computing power as needed, avoiding the high costs of frequent hardware upgrades.
• The processor’s scalability makes it suitable for growing businesses, adapting to increased workloads without significant additional investment.

Advanced Instruction Set and Processing Capabilities

Intel AVX-512 and Other Instruction Sets

• Supports Intel AVX-512, providing enhanced processing power for complex mathematical computations and scientific simulations.
• Includes a range of instruction sets, including SSE4.2, AVX, and AVX2, expanding the processor’s versatility across different applications.

Enhanced Performance for Specific Workloads

• Intel AVX-512 allows for simultaneous processing of multiple data points, greatly improving performance in applications such as encryption, data compression, and high-performance computing (HPC).
• This makes the Xeon Gold 6328H particularly valuable in fields requiring heavy computational power, such as finance, scientific research, and media production.

Built for the Data-Centric Era

Empowering Digital Transformation

• The Intel Xeon Gold 6328H is engineered to support the shift towards data-driven decision-making and analytics.
• Its robust performance and advanced feature set empower organizations to innovate and compete in the digital age.
• From powering cloud services to supporting AI and ML workloads, this processor is at the heart of the data-centric era.
