Intel Xeon Platinum 3.00 GHz SRK59 225W 24 Core Server CPU 8360H

The SRK59 Intel Xeon Platinum 8360H Processor

The SRK59 Intel Xeon Platinum 8360H Processor is a high-performance server CPU designed to meet the demanding needs of modern data centers and enterprise environments. Operating at a base clock speed of 3.00 GHz with 24 cores, this processor is engineered to deliver exceptional computational power and reliability for a wide range of applications.

Intel Xeon Platinum 8360H Processor

General Information

• Part Number: SRK59
• Code Name: Previously Cooper Lake
• Segment: Server
• Processor Model: 8360H
• Manufacturing Process: 14 nm

Performance Specifications

Core and Frequency Details

• Total Cores: 24
• Total Threads: 48
• Base Clock Frequency: 3.00 GHz
• Max Turbo Frequency: 4.20 GHz
• Cache Size: 33 MB
• Number of UPI Links: 6
• Thermal Design Power (TDP): 225 W

Memory and Expansion

Memory Specifications

• Maximum Memory Size: 1.12 TB (dependent on memory type)
• Supported Memory Types: DDR4 RDIMM
• Maximum Memory Speed: 3200 MHz
• Number of Memory Channels: 6
• Intel® Optane™ Persistent Memory: Supported
• ECC Memory Support: Yes

Expansion and Connectivity

• Scalability: S8S
• PCI Express Revision: 3.0
• Number of PCI Express Lanes: 48

Package and Physical Attributes

• Socket Type: FCLGA4189
• Package Dimensions: 77.5 x 56.5 mm

Advanced Technologies

Technology and Features

• Intel® Volume Management Device (VMD): Yes
• Intel® Deep Learning Boost (DL Boost): Yes
• Intel® Resource Director Technology (RDT): Yes
• Intel® Optane™ Memory Support: Yes
• Intel® Speed Shift Technology: Yes
• Intel® Hyper-Threading Technology: Yes
• Intel® Transactional Synchronization Extensions: Yes
• Intel® 64: Yes
• Instruction Set Extensions: SSE4.2, AVX, AVX2, AVX-512
• Number of AVX-512 FMA Units: 2
• Enhanced Intel SpeedStep® Technology: Yes

Security and Reliability Features

• Intel® AES New Instructions: Yes
• Execute Disable Bit: Yes
• Intel® Run Sure Technology: Yes
• Mode-based Execute Control (MBEC): Yes
• Intel® Virtualization Technology (VT-x): Yes
• Intel® Virtualization Technology for Directed I/O (VT-d): Yes
• Intel® VT-x with Extended Page Tables (EPT): Yes

Clock Speed and Core Architecture

The Intel Xeon Platinum 8360H operates at a base clock speed of 3.00 GHz, providing robust performance for both single-threaded and multi-threaded applications. With 24 cores, this processor is designed for high levels of parallel processing, making it well-suited for tasks that require significant computational resources, such as large-scale data analysis and virtualization.

Thermal Design Power (TDP)

Featuring a Thermal Design Power (TDP) of 225 watts, the Xeon Platinum 8360H is capable of handling demanding workloads while maintaining thermal efficiency. The TDP rating indicates the maximum heat output the processor can generate under full load, requiring adequate cooling solutions to ensure optimal performance and system stability. Efficient cooling is essential to prevent overheating and maintain the processor's reliability.

Advanced Architectural Features

The Xeon Platinum 8360H incorporates several advanced architectural features that enhance its performance and efficiency:

• Intel Turbo Boost Technology: Boosts the processor's clock speed dynamically during high-demand scenarios to improve performance.
• Intel Hyper-Threading Technology: Allows each core to handle two threads simultaneously, improving multitasking and parallel processing capabilities.
• Intel AVX-512: Provides enhanced vector processing capabilities, accelerating data-intensive computations.
• Intel Speed Shift Technology: Enables rapid adjustments to processor performance levels based on current workload demands.

Applications and Use Cases

Enterprise Data Centers

The SRK59 Intel Xeon Platinum 8360H is ideally suited for enterprise data centers, where its high core count and robust performance capabilities enable efficient management of large-scale data processing, cloud computing, and virtualization tasks. The processor’s ability to handle multiple concurrent workloads makes it a valuable asset in high-demand environments that require reliable and scalable computing solutions.

High-Performance Computing (HPC)

In high-performance computing environments, the Xeon Platinum 8360H delivers the computational power needed for complex simulations, scientific research, and large-scale data analysis. Its 24-core architecture and high clock speed provide the necessary performance to tackle demanding computational tasks efficiently and effectively.

Virtualization and Cloud Computing

The Xeon Platinum 8360H excels in virtualization and cloud computing applications. Its support for advanced virtualization technologies enables the efficient creation and management of multiple virtual machines, optimizing resource allocation and improving overall performance. This capability is crucial for businesses that rely on virtualization to maximize their IT infrastructure and enhance operational flexibility.

Enterprise Applications

For enterprise applications, the Xeon Platinum 8360H offers the processing power required to support complex business systems, such as enterprise resource planning (ERP) and customer relationship management (CRM) tools. The processor’s high performance ensures that these applications run smoothly and efficiently, contributing to increased productivity and operational effectiveness.

Memory Support and Compatibility

The Intel Xeon Platinum 8360H supports a range of memory configurations, allowing for the use of high-capacity and high-speed memory modules. This support enhances the processor's performance in memory-intensive applications and ensures efficient handling of large data sets. When integrating the processor into your system, ensure compatibility with your server motherboard and other hardware components to achieve optimal performance.

Security Features

The Xeon Platinum 8360H includes several advanced security features to protect sensitive data and ensure system integrity:

• Intel Total Memory Encryption (TME): Provides hardware-based encryption of all memory to safeguard against unauthorized access.
• Intel Software Guard Extensions (SGX): Creates secure enclaves within the processor to protect sensitive data and applications from potential threats.
• Intel Data Protection Technology: Offers various security features to enhance data protection and prevent breaches.

Benefits of the SRK59 Intel Xeon Platinum 8360H Processor

Enhanced Performance and Efficiency

Upgrading to the SRK59 Intel Xeon Platinum 8360H Processor provides significant improvements in performance and efficiency. The processor's high clock speed and 24-core design deliver fast data processing and enhanced multitasking capabilities. This upgrade is particularly advantageous for applications that require intensive computational resources and high-speed processing.

Increased Reliability and Stability

The Xeon Platinum 8360H is designed to offer increased reliability and stability. Its robust architecture, combined with advanced memory technologies and security features, ensures that the processor can handle demanding workloads with consistent performance. This reliability is crucial for mission-critical applications and enterprise environments where system uptime is essential.

Scalability and Future-Proofing

Investing in the Xeon Platinum 8360H helps future-proof your server infrastructure by providing a powerful and scalable solution. The processor’s advanced features and high performance ensure that your IT infrastructure remains competitive and capable of adapting to future technological advancements and increasing workload demands.

Efficient Resource Utilization

The Xeon Platinum 8360H’s high core count and support for virtualization technologies enable efficient resource utilization. This optimization is particularly valuable for businesses that need to maximize their IT resources and improve the performance of virtualized applications and services. By effectively managing resources, businesses can achieve better performance and cost-efficiency.

Advanced Cooling Solutions

Given the processor’s high TDP, implementing effective cooling solutions is essential to maintain optimal performance and system stability. Advanced cooling technologies help manage the heat generated by the Xeon Platinum 8360H, preventing overheating and potential performance degradation. Proper cooling also helps extend the lifespan of the processor and associated hardware components.
