HPE 1920-8g-PoE JG921A Rack-Mountable Switch with 8 Ports

Ports

The HPE JG921A Rack-Mountable Switch is equipped with 8 ports, making it an ideal choice for small to medium-sized businesses or home offices that require a reliable and efficient network solution. The number of ports offered by a switch is a crucial factor to consider when selecting the right networking equipment for your organization. In this section, we will explore the benefits and importance of the 8 ports featured in this switch.

Overview of the JG921A Switch

The JG921A is an advanced network switch designed for high performance and flexibility in various network environments. This robust switch is engineered to deliver superior connectivity and management capabilities with its extensive range of features.

Main Specification

• Brand: HPE
• Part Number: JG921A

Device Specifications

• Device Type: 8-Port Layer 3 Managed Switch
• Enclosure Type: Versatile Desktop or Rack-Mountable (1U)
• Subtype: Gigabit Ethernet

Ports and Connectivity

• Ports: 8 x 10/100/1000 (PoE+) & 2 x Gigabit SFP
• Power Over Ethernet (PoE): PoE+
• PoE Budget: 65W

Performance Metrics

• Throughput: 14.8 Mpps
• Routing/Switching Capacity: 20 Gbps
• IPv4 Routing Table Entries: 32
• IPv6 Routing Table Entries: 32
• MAC Address Table Size: 8192 Entries
• Jumbo Frame Support: Up to 10KB

Routing and Protocol Support

• Routing Protocols: Static IPv4 and IPv6 Routing
• Remote Management: SNMP (v1, v2c, v3), RMON, Telnet, HTTP, HTTPS, TFTP, CLI
• Encryption: SSL
• Authentication: Secure Shell (SSH), RADIUS

Advanced Features

• Flow Control
• Layer 2 Switching
• Auto-Negotiation
• ARP Support
• VLAN Support
• Auto-Uplink (Auto MDI/MDI-X)
• IGMP Snooping
• Syslog Support
• Port Mirroring
• Weighted Round Robin (WRR) Queuing
• IPv6 Support
• Spanning Tree Protocol (STP) Support
• Rapid Spanning Tree Protocol (RSTP) Support
• Multiple Spanning Tree Protocol (MSTP) Support
• Access Control List (ACL) Support
• Quality of Service (QoS)
• Jumbo Frames Support
• MLD Snooping
• Cable Diagnostics Function
• STP Root Guard
• DHCP Relay
• Port Security
• DHCP Client
• Dual Firmware Images
• Strict Priority Queuing (SPQ)
• Port Isolation
• Static Routing
• Class of Service (CoS)
• Single IP Management (SIM)

Compliance and Standards

• IEEE 802.3 Series
• IEEE 802.1 Series
• IEEE 802.3af, 802.3at, 802.3az
• IEEE 802.3x
• IEEE 802.3ad (LACP)
• IEEE 802.1x, 802.1w, 802.1s
• IEEE 802.1ab (LLDP)

Hardware Specifications

• Processor: 500 MHz MIPS
• RAM: 128 MB SDRAM
• Flash Memory: 32 MB

Expansion and Connectivity Options

• Interfaces: 8 x 1000BASE-T RJ-45 (PoE+), 2 x 1000BASE-X SFP
• Management Console: 1 x RJ-45

Increased Connectivity

With 8 ports, the HPE JG921A Rack-Mountable Switch provides users with ample connectivity options. Each port acts as a connection point for devices such as computers, printers, servers, and other network-enabled devices. Having multiple ports allows you to connect various devices simultaneously, eliminating the need for additional switches or hubs. This enhances the overall efficiency and productivity of your network by ensuring smooth data transmission between connected devices.

Flexibility in Network Design

The 8 ports offered by this switch provide flexibility in designing your network infrastructure. Whether you have a growing business or a home office with multiple devices, having 8 ports allows you to easily expand your network without the hassle of purchasing additional equipment. It enables you to connect devices across different departments or rooms, ensuring seamless communication and data sharing.

Improved Network Performance

The HPE JG921A Rack-Mountable Switch's 8 ports contribute significantly to improved network performance. Each port operates at high speed, enabling fast data transfer rates and minimizing latency. This is particularly beneficial for bandwidth-intensive applications such as video streaming, online gaming, and large file transfers. With 8 ports at your disposal, you can distribute network traffic evenly across devices, preventing congestion and ensuring optimal network performance.

Simplified Network Management

Managing a network with multiple devices can be complex and time-consuming. However, with the 8 ports provided by this switch, network management becomes more straightforward. Each port can be assigned to a specific device or department, allowing for easy organization and identification of connected devices. This simplifies troubleshooting, as you can quickly identify and isolate any network issues that may arise. Additionally, the switch's intuitive management interface provides a user-friendly experience, further streamlining network administration tasks.

Efficient Resource Utilization

Having 8 ports on the HPE JG921A Rack-Mountable Switch promotes efficient resource utilization within your network infrastructure. Each port acts as a point of access to the network, ensuring that every connected device can make full use of available resources such as internet bandwidth and server resources. This prevents bottlenecks and ensures that every device receives the necessary resources to operate at its maximum potential. By efficiently utilizing resources, you can optimize network performance and enhance user experience.

Scalability for Future Growth

Investing in networking equipment with a sufficient number of ports is essential for accommodating future growth. The 8 ports featured in this switch provide scalability, allowing you to expand your network as your business or home office grows. You can easily connect new devices or add additional switches without disrupting existing network operations. This scalability ensures that your network infrastructure remains adaptable and can support future technological advancements or increased device connectivity demands.

Cost-Effective Solution

The HPE JG921A Rack-Mountable Switch's 8 ports offer a cost-effective solution for small to medium-sized businesses or home offices. By providing multiple ports in a single device, this switch eliminates the need for purchasing multiple switches or hubs to accommodate your network requirements. This reduces upfront costs and ongoing maintenance expenses associated with managing multiple networking devices. Additionally, the switch's energy-efficient design helps lower power consumption, further contributing to cost savings over the long term.

Enhanced Network Security

Having 8 ports on the HPE JG921A Rack-Mountable Switch enhances network security by allowing you to segregate devices and control access to critical resources. You can assign different ports to specific VLANs (Virtual Local Area Networks) or subnets, ensuring that only authorized devices have access to sensitive data or resources. This reduces the risk of unauthorized access, data breaches, and network attacks. With the ability to segment your network effectively, you can implement robust security measures and maintain a secure working environment.

Power Over Ethernet

The HPE JG921A Rack-Mountable Switch features Power Over Ethernet (PoE) functionality on 1 of its ports, providing users with added convenience and flexibility in powering network-connected devices. In this section, we will explore the benefits and importance of this PoE feature.

Simplified Installation

Power Over Ethernet simplifies the installation process by eliminating the need for separate power cables for certain devices. With PoE, you can power compatible devices directly through the Ethernet cable, reducing clutter and minimizing cable management challenges. This is particularly advantageous in scenarios where power outlets may be limited or difficult to access, such as mounting network cameras or wireless access points in remote locations. The PoE capability of the HPE JG921A Rack-Mountable Switch allows you to deploy devices easily without the need for additional power infrastructure.

Flexibility in Device Placement

The PoE feature of this switch enables flexible device placement without being restricted by proximity to power outlets. Powered devices can be located anywhere within the reach of an Ethernet cable, providing greater freedom in designing your network layout. This flexibility is especially beneficial for deploying devices in areas where power outlets are scarce or impractical to install, such as outdoor environments or large open spaces. By leveraging PoE, you can optimize device placement for optimal network coverage and convenience.

Cost Savings

Power Over Ethernet offers significant cost savings by eliminating the need for separate power supplies for compatible devices. This reduces the upfront costs associated with purchasing and installing additional power infrastructure. Additionally, PoE allows for easier scalability, as you can add or relocate devices without the need for extensive rewiring or hiring electricians. The HPE JG921A Rack-Mountable Switch's PoE capability provides a cost-effective solution for powering network-connected devices while minimizing deployment and maintenance expenses.

Centralized Power Management

The PoE feature of this switch enables centralized power management, enhancing control and efficiency in powering connected devices. Through the switch's management interface, you can monitor and manage the power consumption of each PoE-enabled port. This allows you to allocate power resources based on device requirements, ensuring optimal power distribution and preventing power overloads. By centrally managing the power supply, you can also remotely reset or power-cycle devices, simplifying troubleshooting and reducing downtime.

Reliable Power Delivery

The HPE JG921A Rack-Mountable Switch's PoE feature ensures reliable power delivery to connected devices. It supports industry-standard PoE protocols, ensuring compatibility with a wide range of PoE-enabled devices such as IP phones, wireless access points, and security cameras. This reliability is crucial for mission-critical applications that require uninterrupted power supply, such as surveillance systems or VoIP communication. With PoE, you can trust that your network-connected devices will receive consistent and stable power, minimizing the risk of disruptions or device failures.

Enhanced Network Efficiency

By leveraging Power Over Ethernet, the HPE JG921A Rack-Mountable Switch enhances network efficiency by reducing cable clutter and simplifying device management. With fewer cables to manage, you can maintain a clean and organized network environment, minimizing the risk of cable damage or accidental disconnections. Additionally, the switch's PoE capability allows for centralized device management and monitoring, promoting proactive maintenance and efficient use of network resources. This results in improved network uptime and overall performance.

Future-Proofing

Investing in a switch with Power Over Ethernet capabilities future-proofs your network infrastructure. As the demand for PoE-enabled devices continues to grow, having a switch that supports PoE ensures compatibility with a wide range of current and future devices. This eliminates the need for costly upgrades or replacements down the line, saving you both time and money. The HPE JG921A Rack-Mountable Switch's PoE feature positions your network for future expansion and technological advancements, allowing you to stay ahead in today's rapidly evolving digital landscape.
