HPE JL428A#ABA Aruba 3810M 48G PoE+ 4SFP+ 680W Switch

JL428A#ABA
Hover on image to enlarge

Brief Overview of JL428A#ABA

JL428A#ABA HPE Aruba 3810M 48G PoE+ 4SFP+ 680W Managed Rack-Mountable Switch. New Cto With Standard Mfg Warranty

QR Code of HPE JL428A#ABA Aruba 3810M 48G PoE+ 4SFP+ 680W Switch
$3,848.85
$2,801.00
You save: $1,047.85 (27%)
Ask a question
Price in points: 2801 points
+
Quote
SKU/MPNJL428A#ABAAvailability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Product/Item ConditionFactory-Sealed New in Original Box (FSB) ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30
Description

Overview of  HPE JL428A#ABA Aruba 3810M Managed Switch

  • Brand: HPE
  • Model: JL428A#ABA
  • Type: Network Switch

Enclosure and Design

  • Form Factor: Rack-Mountable (1U)
  • Subtype: Gigabit Ethernet
  • Port Configuration: 48 x 10/100/1000 Mbps PoE+ ports
  • Power Over Ethernet: Supports PoE+

Latency and Throughput

  • 1000Base-T Latency: 2.8 μs
  • 10 Gbps Latency: 1.8 μs
  • 40 Gbps Latency: 1.5 μs
  • Packet Throughput: Up to 190.5 Mpps
  • Routing/ Switching Capacity: 320 Gbps
  • Switching Fabric Bandwidth: 338 Gbps

Capacity

  • IPv4 Routing Table: 10,000 entries
  • IPv6 Routing Table: 5,000 entries
  • MAC Address Table: 64K entries
  • Jumbo Frame Support: Enabled

Supported Protocols

  • OSPF, RIP, BGP, VRRP, OSPFv2, OSPFv3
  • Static IPv4 and IPv6 routing
  • RIPng, MLD, BFD (Bidirectional Forwarding Detection)

Remote Management Options

  • SNMP (v1, v2c, v3), RMON (1, 2, 3, 9)
  • Telnet, HTTP, SSH (v2)
  • CLI and XRMON support

Encryption and Authentication

  • Encryption Algorithm: SSL
  • Authentication Methods: RADIUS, TACACS+, SSH2

Supported Features

  • ARP and STP (Spanning Tree Protocol)
  • Access Control Lists (ACL) and Quality of Service (QoS)
  • Dynamic VLAN and Class of Service (CoS)
  • OpenFlow and ICMP support

Interface Options

  • 48 x 1000Base-T RJ-45 PoE+ ports
  • 1 x Serial RJ-45 (console) port
  • 1 x Micro-USB Type B
  • 1 x Management RJ-45

Expansion Slots

  • 1 x Expansion Slot (total and free)
  • 1 x Stacking Module Slot (total and free)

Power Supply

  • Power Device: Internal Hot-Plug Power Supply
  • Installed Quantity: 1 (expandable to 2)
  • Redundancy: Supported (1+1 scheme)
  • Output Power: 680 Watts

Energy Standards

  • Energy Star Certified
  • Voltage Required: DC 54V

Industry Standards

  • IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
  • IEEE 802.1x, IEEE 802.1s, IEEE 802.1v
  • IEEE 802.11n, IEEE 802.1ab (LLDP)

Overview of the HPE JL428A#ABA 48G PoE+ 4SFP+ Switch

The JL428A#ABA HPE Aruba 3810M 48G PoE+ 4SFP+ 680W Managed Rack-Mountable Switch is a high-performance, enterprise-grade networking solution designed to meet the demands of modern business environments. With its robust features and innovative technologies, this switch ensures reliable connectivity, seamless scalability, and enhanced network management capabilities.

High-Performance Connectivity

This switch provides 48 Gigabit Ethernet ports with PoE+ capabilities, delivering both power and data to connected devices. The inclusion of four SFP+ uplink ports supports high-speed data transfer rates of up to 10 Gbps, enabling superior performance for data-intensive applications and workloads.

PoE+ Functionality

With Power over Ethernet Plus (PoE+), the HPE Aruba 3810M can power devices such as IP phones, wireless access points, and security cameras directly through Ethernet cables. Its total PoE budget of 680 watts ensures reliable operation for a wide range of devices, simplifying deployment and reducing infrastructure costs.

Modular Design and Scalability

The modular design of the 3810M series allows businesses to customize their network configurations. Expansion modules provide flexibility for future growth, while support for stacking simplifies management of multiple switches, creating a unified network fabric.

Centralized Management with Aruba Central

HPE Aruba's cloud-based management platform, Aruba Central, offers centralized control and visibility across the entire network. Administrators can monitor performance, troubleshoot issues, and apply updates effortlessly through an intuitive interface.

Comprehensive Security Features

The 3810M switch includes advanced security protocols such as IEEE 802.1X, MACsec encryption, and Access Control Lists (ACLs). These features safeguard sensitive data and prevent unauthorized access, ensuring a secure networking environment.

Dynamic Segmentation

Dynamic Segmentation streamlines policy enforcement across wired and wireless networks. This feature automatically applies user and device-specific policies, enhancing security and simplifying network administration.

Energy-Efficient Ethernet

Designed with energy efficiency in mind, the 3810M switch supports Energy-Efficient Ethernet (EEE), reducing power consumption during periods of low network activity. This feature contributes to lower operational costs and a reduced environmental footprint.

Efficient Cooling and Power Management

The switch features advanced cooling mechanisms and intelligent power management, ensuring optimal performance with minimal energy waste. Its compact, rack-mountable design further maximizes space efficiency in data centers and server rooms.

Enterprise Environments

In corporate settings, the Aruba 3810M supports high-speed connectivity for workstations, servers, and IP telephony systems. Its robust security features and centralized management make it an ideal choice for enterprise IT teams.

Educational Institutions

Educational institutions benefit from the switch's ability to power classroom devices, enable seamless Wi-Fi access, and provide secure data transmission. Its scalability accommodates the growing needs of campuses and learning facilities.

Healthcare Facilities

In healthcare environments, the switch ensures reliable operation of critical applications such as electronic medical records (EMR) systems, video conferencing, and connected medical devices, while maintaining stringent security standards.

Retail and Hospitality

Retailers and hospitality businesses can leverage the 3810M's PoE+ capabilities to power point-of-sale (POS) systems, surveillance cameras, and guest Wi-Fi networks, delivering exceptional customer experiences.

Port Configuration

The HPE Aruba 3810M features 48 10/100/1000 Ethernet ports and 4 SFP+ ports for uplink connectivity. These ports support advanced features such as auto-sensing and auto-negotiation for streamlined deployment.

Switching Capacity

With a switching capacity of up to 176 Gbps, the 3810M ensures smooth data transmission even in high-traffic environments. This capability minimizes latency and maximizes throughput for demanding applications.

Power and Cooling

The switch includes a 680W power supply and redundant power supply options for enhanced reliability. Its advanced cooling design maintains optimal operating temperatures, even under heavy workloads.

Software Features

HPE Aruba's proprietary operating system provides a rich feature set, including VLAN support, spanning tree protocol, and quality of service (QoS) settings. These features enable precise control over network performance and reliability.

VLAN Support

Virtual Local Area Networks (VLANs) allow network segmentation, enhancing security and optimizing bandwidth utilization. The 3810M supports dynamic VLAN assignment and tagging for seamless integration with existing networks.

Quality of Service (QoS)

QoS settings prioritize critical traffic, ensuring optimal performance for applications such as voice, video, and real-time data. This feature is crucial for maintaining service quality in diverse networking scenarios.

Future-Proof Networking

The 3810M is built to adapt to the evolving needs of modern organizations. Its modular design, extensive feature set, and scalability make it a reliable choice for future-proof networking.

Proven Performance

Backed by HPE Aruba's reputation for quality and innovation, the 3810M delivers consistent performance and reliability. Its advanced capabilities meet the demands of businesses across various industries.

Comprehensive Support

HPE Aruba provides extensive technical support and warranty options, ensuring peace of mind for network administrators. Resources such as documentation, community forums, and professional services further enhance the user experience.

Features
Product/Item Condition:
Factory-Sealed New in Original Box (FSB)
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
