HPE JL557-61001 Aruba 2930F 48G PoE+ Switch Overview
- Brand: HPE
- Model: JL557-61001
- Product Type: Network Switch
- Form Factor: Rack-mountable (1U)
- Port Configuration: 48 x 10/100/1000 Mbps PoE+ ports and 4 x Gigabit SFP uplinks
- Power Supply: Internal power supply delivering up to 740W PoE budget
Performance Highlights
- Throughput: 77.4 Mpps
- Switching Capacity: 104 Gbps
- Latency: 3.8 µs at 1 Gbps
- MAC Address Table: Up to 32,000 entries
Routing and Protocols
- Supports IPv4 and IPv6 with up to 10,000 and 5,000 routing table entries, respectively
- Routing Protocols: OSPF, RIP, RIPng, IGMP (v2/v3), and static routing
Management and Monitoring
- Remote protocols: SNMP (v1/v2c/v3), RMON, Telnet, CLI, and SSH (v1/v2)
- Comprehensive VLAN, DHCP, and ARP support for seamless network configuration
Encryption and Authentication
- Encryption algorithms: SSL and MD5
- Authentication protocols: RADIUS, TACACS+, PAP, and CHAP
Resilience Features
- Spanning Tree Protocol (STP), Multiple STP (MSTP), and Root Guard
- Dynamic ARP Protection and DHCP protection mechanisms
- Link Aggregation Control Protocol (LACP) and UDLD
Comprehensive Features
- Jumbo frame support: up to 9220 bytes
- Quality of Service (QoS) for traffic prioritization
- Dynamic VLAN and multiple VLAN registration protocols
- SNTP, sFlow, and DiffServ for enhanced network efficiency
Energy Efficiency
- 80 PLUS Silver-certified power efficiency
- Operational power consumption as low as 48.6W
Processor and Memory
- Processor: 1 GHz ARM Cortex-A9
- RAM: 1 GB DDR3 SDRAM
- Storage: 4 GB flash memory
Interface and Expansion
- 48 x RJ-45 Gigabit Ethernet (PoE+), 4 x Gigabit SFP uplink ports
- 1 x Serial console interface
- 1 expansion slot (installed: 0, maximum: 4)
Compliance and Standards
- Conforms to IEEE standards: 802.3af, 802.3at, 802.3ad, 802.1d, 802.1q, and more
- Supports LLDP and OpenFlow for advanced networking environments
Overview of JL557-61001 HPE 48G PoE+ 4SFP Switch
The JL557-61001 HPE Aruba 2930F 48G PoE+ 4SFP Switch is a highly advanced and reliable solution designed for medium to large enterprises, offering robust performance, scalability, and security. This Layer 3 managed switch combines cutting-edge features like Power over Ethernet Plus (PoE+), SFP uplinks, and rack-mountable design, catering to a diverse range of networking needs.
Key Features
This model boasts an extensive range of features tailored for optimized networking, ensuring seamless operations and efficient resource management.
Power Over Ethernet Plus (PoE+)
The JL557-61001 supports PoE+ on all 48 Gigabit Ethernet ports, providing up to 30 watts of power per port. This capability makes it ideal for powering advanced devices like IP cameras, VoIP phones, and wireless access points without requiring separate power sources.
High-Speed Connectivity with 4 SFP Ports
Equipped with 4 dedicated SFP uplink ports, the switch offers high-speed fiber connectivity, ensuring smooth data transmission across long distances. This feature is particularly beneficial for enterprises requiring reliable inter-switch connections or links to servers and storage devices.
Layer 3 Routing Capabilities
The switch supports static, RIP, and Access OSPF routing protocols, enabling efficient network segmentation and optimized traffic flow. These Layer 3 features make it an excellent choice for businesses looking to manage complex network topologies with ease.
Performance and Scalability
The Aruba 2930F switch is engineered to deliver exceptional performance, catering to the evolving demands of modern enterprises.
Fast Packet Processing
With its advanced ASIC architecture, the switch offers low-latency and high-throughput performance, ensuring smooth operations even in high-traffic environments. The built-in Quality of Service (QoS) capabilities prioritize critical applications, further enhancing network efficiency.
Expandable Power Budget
The 740W power supply provides ample power for connected devices, with scalability options available for future expansions. This makes the switch a forward-thinking investment for growing organizations.
Intelligent Traffic Management
Features like Adaptive Network Intelligence (ANI) enable the switch to optimize traffic dynamically, ensuring maximum efficiency and reduced downtime. This intelligent management is particularly valuable for high-density environments like offices and data centers.
Advanced Security Features
Security is a critical aspect of any network infrastructure, and the JL557-61001 excels in safeguarding data and connected devices.
Comprehensive Access Controls
The switch supports robust access control mechanisms, including 802.1X authentication, MAC address filtering, and VLAN segmentation. These features ensure that only authorized users and devices can access network resources.
Built-In Firewall Capabilities
With integrated firewall features, the Aruba 2930F switch can detect and block malicious traffic, providing an added layer of security against cyber threats.
Encrypted Management Interfaces
Secure management interfaces, such as SSH, SNMPv3, and HTTPS, ensure that network administrators can configure and monitor the switch without risking data exposure.
Energy Efficiency and Eco-Friendly Design
The Aruba 2930F switch is designed with sustainability in mind, offering energy-efficient features that reduce operational costs and environmental impact.
Energy-Efficient Ethernet (EEE)
The switch supports EEE standards, automatically adjusting power consumption based on network traffic. This results in significant energy savings during periods of low activity.
Intelligent Fan Control
The fan system dynamically adjusts speeds based on temperature and workload, minimizing noise and power usage. This feature enhances the switch's overall energy efficiency.
Compliance with Green Standards
Aruba 2930F meets various eco-friendly certifications, including RoHS and WEEE compliance, reflecting its commitment to sustainable technology.
Deployment Scenarios
The JL557-61001 HPE Aruba 2930F 48G PoE+ switch is versatile enough to meet the needs of various industries and applications.
Enterprise Networks
This switch is ideal for enterprise networks, offering robust connectivity, scalability, and advanced management features. It supports complex deployments, ensuring seamless communication across departments and offices.
Educational Institutions
Schools and universities benefit from the switch's PoE+ capabilities, enabling the deployment of IP-based surveillance systems, interactive whiteboards, and Wi-Fi access points in classrooms and campuses.
Retail and Hospitality
Retail stores and hospitality venues can leverage the switch's high-speed connectivity to support point-of-sale systems, guest Wi-Fi networks, and IoT devices, enhancing the overall customer experience.
Management and Monitoring Tools
The JL557-61001 is equipped with user-friendly management tools, simplifying network administration and monitoring.
Cloud-Based Management
The Aruba Central platform offers cloud-based management capabilities, allowing administrators to configure and monitor the switch remotely. This feature is invaluable for multi-site deployments.
Web and Command-Line Interfaces
Administrators can choose between an intuitive web interface or a powerful command-line interface (CLI) for managing the switch, catering to both novice and experienced users.
Real-Time Analytics
Built-in analytics tools provide insights into network performance and usage patterns, helping administrators identify and resolve issues proactively.
Technical Specifications
Understanding the technical details of the JL557-61001 switch is essential for determining its suitability for your network.
Physical Dimensions and Design
The switch features a compact, rack-mountable design with dimensions of 44.25 cm x 27.94 cm x 4.39 cm, ensuring easy installation in standard server racks.
Port Configuration
It includes 48 Gigabit Ethernet ports with PoE+ support and 4 SFP uplink ports, offering a total of 52 ports for versatile connectivity.
Power and Environmental Specifications
With a power supply of 740W, the switch supports demanding workloads while operating within a temperature range of 0°C to 45°C.
Memory and Processing Power
The switch is equipped with 2 GB of DDR3 memory and a powerful processor, ensuring fast and reliable performance.
Choose the JL557-61001 HPE Aruba 2930F
The JL557-61001 switch stands out for its combination of performance, security, and scalability, making it a top choice for modern networking needs.
Proven Reliability
Aruba's reputation for quality and innovation ensures that the 2930F switch delivers consistent performance, backed by comprehensive support and warranty options.
Ease of Use
From straightforward installation to intuitive management tools, the switch simplifies network deployment and maintenance, saving time and resources.
Future-Ready Design
With its scalable architecture and support for advanced networking standards, the JL557-61001 is a future-ready solution that adapts to evolving technological demands.
