Overview of the JL557A#ABA HPE Aruba 2930F Network Switch
- Brand: HPE
- Part Number: JL557A#ABA
- Product Type: Network Switch
Enclosure and Size
- Form Factor: Rack-mountable 1U
- Subtype: Gigabit Ethernet
Power and Performance
- Power Over Ethernet: PoE+ (Power over Ethernet Plus)
- PoE Budget: 740W
- Performance Specifications:
- Throughput: 77.4 Million Packets Per Second (Mpps)
- Switching Capacity: 104 Gbps
- Latency: 3.8 Microseconds (1 Gbps)
Capacity & Table Entries
- Jumbo Frame Size: 9220
- IPv4 Routing Table Entries: 10,000
- IPv6 Routing Table Entries: 5,000
- MAC Address Table Size: 32,000 entries
Routing and Network Protocols
- Routing Protocols Supported:
- OSPF, RIP (including RIP-1, RIP-2), IGMPv2, IGMP, OSPFv2, Static IP Routing
- IPv6 routing protocols: OSPFv3, RIPng, MLD, CIDR
- Remote Management Support: SNMP (v1, v2, v3), Telnet, SSH, CLI
- Encryption and Authentication: MD5, SSL, RADIUS, PAP, CHAP, TACACS+
Traffic Management & Control
- Flow Control: Yes
- Full Duplex Capability: Supported
- Quality of Service (QoS): Available
- VLAN Support: Yes
- Spanning Tree Protocol: STP, MSTP support
- Jumbo Frames: Supported
Network Monitoring & Protection
- Dynamic ARP Protection: Yes
- DHCP Snooping & Relay: Supported
- Link Aggregation Control Protocol (LACP): Supported
- Access Control List (ACL): Yes
- SNMP and Syslog: Available for monitoring
Security Features
- MAC Address Lockout: Supported
- Dynamic VLAN Support (GVRP): Yes
- Virtual Extensible LAN (VXLAN): Supported
- Uni-Directional Link Detection (UDLD): Yes
Compliance and Industry Standards
- Compliant Standards:
- IEEE 802.1D, IEEE 802.1Q, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1p
- IEEE 802.3az, IEEE 802.1ab (LLDP), IEEE 802.1x, IEEE 802.1w
Hardware Specifications
- Processor: ARM Cortex-A9 (1.016 GHz)
- RAM: 1 GB DDR3 SDRAM
- Flash Memory: 4 GB
Connectivity and Expansion
- 48 x 1000Base-T RJ-45 PoE+
- 4 x Gigabit LAN SFP
- 1 x Serial (Console)
Expansion Slots
- 1 expansion slot available (max 4 modules)
Power Requirements
- Power Supply: Internal (459W)
- Voltage Required: AC 120/230V (50/60 Hz)
- Power Consumption (Operational): 48.6W
- Efficiency Certification: 80 Plus Silver
Overview of the JL557A#ABA HPE Aruba 2930F L3 Switch
The JL557A#ABA HPE Aruba 2930F 48G PoE+ 4SFP L3 Managed Rack-Mountable Switch is a high-performance networking solution designed to meet the needs of growing businesses and enterprises. Offering advanced Layer 3 (L3) management features, PoE+ (Power over Ethernet Plus) support, and high-speed SFP connectivity, this managed switch is ideal for high-density environments. With 48 Gigabit Ethernet ports and a power budget of 740 watts, it ensures efficient network operations and seamless connectivity across a variety of devices, including access points, security cameras, and IP phones.
Key Features
- 48 Gigabit Ethernet Ports for high-speed data transfer, ensuring network performance in demanding environments.
- PoE+ Support delivers power to devices such as VoIP phones, wireless access points, and IP cameras directly over Ethernet cables, eliminating the need for separate power supplies.
- Layer 3 Management Capabilities for advanced routing, allowing for more robust network management and segmentation.
- 4 SFP Ports for flexible and high-speed fiber optic connectivity, ideal for long-distance connections and high-bandwidth applications.
- 740W Power Supply provides ample power for all connected devices, ensuring reliability and stability for your network setup.
Benefits
The JL557A#ABA HPE Aruba 2930F is optimized for high-performance networks, offering a range of benefits that can enhance the efficiency and scalability of your network infrastructure. Its support for PoE+ enables centralized power management, reducing the need for additional power outlets and simplifying device installation. The advanced Layer 3 routing capabilities help ensure seamless communication between devices, even across different network segments, while its stackable design makes it easy to expand as your network grows.
Reliable Power Over Ethernet (PoE+)
The PoE+ functionality of the Aruba 2930F allows the switch to deliver both power and data over a single Ethernet cable, significantly simplifying the deployment of connected devices. With a total power budget of 740W, the switch is capable of powering high-power devices such as access points, IP cameras, and VoIP phones, all while maintaining network stability. This capability makes it an ideal choice for environments where there are numerous powered devices, including educational campuses, large offices, and public spaces.
PoE+ for Cost Savings and Efficiency
By eliminating the need for separate power cables and adapters, PoE+ reduces both hardware and installation costs. Additionally, it minimizes cable clutter, resulting in a cleaner, more organized network infrastructure. The centralized power management provided by PoE+ also enhances efficiency and reduces the risk of power disruptions in mission-critical environments.
Layer 3 Management for Advanced Networking
Layer 3 management is a key feature of the Aruba 2930F, offering advanced routing capabilities that are ideal for enterprise environments. With L3 management, the switch can perform dynamic routing, network segmentation, and access control between different network subnets, improving the overall network performance, security, and traffic flow. This is particularly useful in large networks where multiple departments or devices need to communicate efficiently across different IP subnets.
Dynamic Routing and Network Segmentation
With Layer 3 routing, the Aruba 2930F can route traffic between different network segments, ensuring that devices on different subnets can communicate effectively. This allows for improved network efficiency, as traffic is routed in the most efficient manner possible, reducing congestion and optimizing the use of available bandwidth. Additionally, the ability to segment the network helps improve security by isolating different parts of the network and limiting the potential impact of any security breaches.
Improved Network Security
Layer 3 functionality also allows for the implementation of more advanced security features such as access control lists (ACLs) and IP filtering. These features allow administrators to restrict access to certain parts of the network, ensuring that only authorized devices and users can access sensitive information and resources. The result is a more secure network infrastructure that can better withstand external and internal threats.
Scalability and Flexibility for Growing Businesses
As businesses grow, so too does the demand for network resources. The Aruba 2930F series offers a highly scalable solution that can adapt to the evolving needs of a growing organization. Its stackable design allows for the easy expansion of the network by adding additional units without the need for complex reconfiguration. Whether your business is expanding its number of employees, adding more devices, or increasing network traffic, the Aruba 2930F can easily scale to meet these challenges.
Stacking for Seamless Expansion
Aruba's stackable architecture allows multiple Aruba 2930F switches to be managed as a single logical unit, simplifying network administration and enabling seamless scalability. This means that adding additional switches to the network does not require a complete overhaul of the existing infrastructure. Simply add a new unit to the stack, and it will automatically integrate into the network, retaining the same management and configuration settings.
Efficient Management with Aruba Central
For businesses looking to manage their network more efficiently, the Aruba 2930F is fully compatible with Aruba Central, a cloud-based management platform. Aruba Central provides centralized monitoring and management, allowing IT administrators to easily track network performance, troubleshoot issues, and manage configurations from anywhere. This flexibility is essential for businesses with distributed teams or multiple locations, as it enables them to maintain full control of their network infrastructure, regardless of their physical location.
Connectivity Options for Diverse Environments
The Aruba 2930F provides a variety of connectivity options that make it versatile enough for a wide range of network setups. With 48 Gigabit Ethernet ports, it supports high-speed connections to a variety of devices, including computers, servers, and printers. Additionally, the 4 SFP (Small Form-factor Pluggable) ports provide fiber-optic connectivity, allowing for long-distance connections and higher bandwidth for demanding applications such as video streaming or large file transfers.
SFP Ports for High-Bandwidth Applications
The inclusion of 4 SFP ports provides significant flexibility in connecting to distant locations within your network or to the internet. By using fiber optic cables, businesses can achieve much higher speeds over long distances, compared to traditional copper cables. This is particularly useful in large buildings or campuses, where connections between switches may need to span hundreds or even thousands of feet.
High-Speed Fiber Connectivity
With SFP ports, you can use a variety of fiber types such as single-mode and multi-mode fibers to suit your specific network requirements. This makes the Aruba 2930F ideal for high-speed applications that demand low latency and high throughput, such as data centers, video conferencing, and cloud-based applications.
Easy Deployment and Management
Deploying and managing the Aruba 2930F is straightforward thanks to its user-friendly interface and robust management tools. The switch can be easily configured through the command-line interface (CLI), web interface, or Aruba Central, providing flexibility for administrators with different levels of expertise. Additionally, Aruba’s intuitive management features, such as zero-touch provisioning and automated firmware updates, ensure that your network is always up-to-date and performing optimally.
Zero-Touch Provisioning for Simplified Deployment
Zero-touch provisioning (ZTP) allows the Aruba 2930F to automatically download and apply its configuration settings when it is connected to the network for the first time. This eliminates the need for manual configuration, reducing the risk of errors and speeding up the deployment process. Whether you're installing one switch or a stack of switches, ZTP ensures that the deployment process is quick and efficient.
Automated Firmware Updates
The Aruba 2930F can also be configured to automatically check for and install firmware updates, ensuring that the switch is always running the latest software version. This feature helps keep the network secure and ensures that new features and bug fixes are applied without requiring manual intervention from IT staff.
