Mellanox MCX545A-CCUN ConnectX-5 EN 100GbE 1-port QSFP28 PCI-E NIC

Overview of Mellanox MCX545A-CCUN 100GbE NIC

The MELLANOX MCX545A-CCUN ConnectX-5 EN is a high-performance OCP 2.0 Type 2 network adapter engineered for enterprise-grade networking, cloud infrastructure, hyperscale data centers, and high-bandwidth virtualization environments. Featuring a single-port QSFP28 interface and PCIe Gen3 x16 connectivity, this advanced Ethernet NIC delivers ultra-fast throughput with low latency and optimized power efficiency.

General Specifications

• Brand: Mellanox
• Part Number: MCX545A-CCUN
• Product Series: ConnectX-5 EN
• Product Type: Network Interface Card

Technical Specification

• Single-port QSFP28 Ethernet interface
• Supports copper and optical connectivity
• 100GbE ultra-high-speed data transmission
• Designed for OCP 2.0 Type 2 platforms
• UEFI enabled architecture
• PCI Express Gen3 x16 host interface
• No bracket design for specialized deployments

PCIe Gen3 High-Speed Interface

• PCIe Gen3 SERDES at 8.0GT/s
• 16-lane interface configuration
• Backward compatibility with PCIe 2.0 and 1.1
• Enhanced packet processing performance
• Reduced network bottlenecks

Broad Ethernet Protocol Compatibility

Supported Ethernet Standards

• 100GBASE-CR4
• 100GBASE-KR4
• 100GBASE-SR4
• 50GBASE-R2 and 50GBASE-R4
• 40GBASE-CR4, KR4, SR4
• 40GBASE-LR4 and ER4
• 25GBASE-R
• 20GBASE-KR2
• 10GBASE-LR, ER, CX4, CR, KR, and SR
• SGMII support
• 1000BASE-CX and 1000BASE-KX

Supported Data Rates

• 1 Gb/s
• 10 Gb/s
• 25 Gb/s
• 40 Gb/s
• 50 Gb/s
• 100 Gb/s

Power Specifications

• Typical power usage: 14.48W with passive cables
• Maximum power consumption: 17.57W using passive cables
• Up to 21.07W with 1.5W active cables
• QSFP28 port power availability up to 3.5W
• Supports 3.3Vaux, 5Vaux, and 12V power inputs

Hardware Dimensions

• Card size: 3.07 inches x 4.33 inches
• Dimensions: 78.00mm x 110.05mm
• Single QSFP28 connector configuration
• Supports passive and active cable deployments

Environmental Specifications

• Operational temperature range: 0°C to 55°C
• Storage temperature range: -40°C to 70°C
• Supports up to 90% relative humidity
• Operational altitude support up to 3050 meters

 Ideal Applications

• Cloud computing infrastructure
• Enterprise virtualization
• High-frequency trading networks
• AI and machine learning workloads
• Hyper-converged environments
• Data center networking
• Storage area networking
• High-performance computing clusters
