699-5G133-0510-L00 Nvidia 48GB GDDR6 Pcie Quadro RTX 6000 ADA FH 4.0 X16 Graphic Card

Detailed of Nvidia Quadro 48GB GDDR6

General Product Information

• Manufacturer: Nvidia Corporation
• Model Number: 699-5G133-0510-L00
• Device Category: Professional Graphics Adapter
• Form Factor: Full-Height Dual-Slot

Core Specifications and Architecture

Technical Specifications

• GPU Model: NVIDIA RTX 6000 Ada Generation
• Bus Type: PCI Express 4.0 x16
• CUDA Core Count: 18,176 Parallel Processing Units
• VR Ready: Yes

Display Resolution and Monitor

• Maximum Resolution: 7680 x 4320 @ 60Hz
• DisplayPort Capabilities:
  • 7680 x 4320 @ 60Hz (Dual Displays)
  • 5120 x 2880 @ 60Hz (Four Displays)
  • 4096 x 2160 @ 120Hz (Four Displays)
• Maximum Monitors Supported: 4
• Interface Ports: 4 x DisplayPort 1.4

Supported APIs and Software Features

Graphics and Compute API Compatibility

• OpenCL 3.0
• CUDA 11.6
• DirectCompute
• DirectX 12
• Shader Model 6.6
• OpenGL 4.6
• Vulkan 1.3

Advanced GPU Capabilities

• 568 Third-Gen Tensor Cores
• 142 Second-Gen RT Cores
• Error Correcting Code (ECC) Memory
• Active Cooling System
• NVIDIA CUDA Technology
• Peak Single-Precision Performance: 91.1 TFLOPS
• Ray Tracing Performance: 210.6 TFLOPS
• Tensor Performance: 1457 TFLOPS
• NVIDIA GPUDirect and GPUDirect RDMA
• NVIDIA Mosaic and RTX Experience
• Quadro Sync 2 Compatibility
• AV1 Decode and Encode Support
• HDCP Compliance

Memory Configuration

Video Memory Details

• Installed RAM: 48GB GDDR6 SDRAM
• Memory Bus Width: 384-bit
• Memory Bandwidth: 960 GB/s

System Requirements and Compatibility

Operating System Support

• Linux
• Windows 10

Included Software and Compliance

• NVIDIA RTX Desktop Manager
• DisplayPort 1.4 Standard
• HDCP 2.2 Compliance

Physical Dimensions and Power

Size and Power Consumption

• Height: 11.2 cm
• Depth: 26.7 cm
• Power Usage: 300 Watts
• Power Connector: 1 x 8-pin CPU

The Quadro RTX 6000 ADA GPU

• Exceptional performance for AI, rendering, and simulation workloads
• Massive memory capacity with ECC for mission-critical tasks
• Advanced ray tracing and tensor capabilities for real-time graphics
• Robust multi-display support for professional visualization
• Optimized for enterprise environments with virtualization and remote memory access

Nvidia 699-5G133-0510-L00 Graphics Card Overview

The Nvidia 699-5G133-0510-L00 represents the pinnacle of professional GPU performance, designed for demanding workflows in AI, machine learning, 3D rendering, and high-end visualization. Equipped with a massive 48GB of GDDR6 memory, this PCIe-based Quadro RTX 6000 ADA graphics card delivers unmatched computational power and speed for complex datasets and intricate 3D models. Its PCIe 4.0 x16 interface ensures rapid data transfer rates, supporting bandwidth-intensive tasks without bottlenecks.

Architecture and Performance

Advanced Ada Lovelace Architecture

The Quadro RTX 6000 ADA is built on Nvidia's Ada Lovelace architecture, featuring cutting-edge improvements in ray tracing and AI acceleration. This architecture enables real-time rendering of photorealistic graphics while maintaining high efficiency and lower power consumption. Advanced shader cores and enhanced RT cores provide faster and more accurate ray tracing, making it ideal for simulations, visual effects, and digital content creation.

Memory and Data Handling

With 48GB of ultra-fast GDDR6 memory, this graphics card handles enormous datasets effortlessly. The large memory capacity is crucial for high-resolution textures, massive CAD assemblies, and complex 3D environments. Efficient memory management ensures that data flows seamlessly through the GPU pipeline, allowing professionals to render complex scenes in real-time without lag or slowdown.

Rendering and Visualization Capabilities

Real-Time Ray Tracing

The RTX 6000 ADA excels at real-time ray tracing, allowing visual artists to achieve photorealistic lighting, shadows, and reflections. Its dedicated RT cores accelerate ray tracing calculations, enabling designers and engineers to preview accurate lighting conditions within 3D scenes. This capability is invaluable for architectural visualization, product design, and cinematic rendering workflows.

AI-Enhanced Graphics Processing

Leveraging Tensor cores, the Quadro RTX 6000 ADA offers AI-accelerated features such as denoising, upscaling, and predictive rendering. These AI enhancements reduce rendering times while improving image quality, giving professionals a competitive edge in producing high-fidelity visual content. Machine learning algorithms embedded in the GPU assist in automated image enhancement, simulation acceleration, and optimization of complex visual tasks.

Scientific Computing and Machine Learning

Researchers and engineers benefit from the Quadro RTX 6000 ADA’s computational performance for scientific computing and machine learning workloads. Its architecture supports deep learning frameworks such as TensorFlow, PyTorch, and CUDA-optimized AI libraries, enabling accelerated training of neural networks. Large datasets can be processed in parallel, shortening project timelines and improving predictive accuracy.

Virtual Production and Media Workflows

The GPU's advanced ray tracing and AI features make it suitable for virtual production, real-time compositing, and cinematic visual effects. Video editors and VFX artists can render high-resolution sequences with multiple layers and effects in real-time, reducing post-production bottlenecks. This level of performance is essential for studios creating feature films, advertisements, and immersive VR experiences.

Connectivity and Compatibility

PCIe 4.0 x16 Interface

The Quadro RTX 6000 ADA utilizes the PCIe 4.0 x16 interface, providing high-speed connectivity to host systems. This ensures maximum data throughput for large-scale computations and minimizes latency between CPU and GPU operations. The interface is backward compatible with PCIe 3.0 systems, offering flexible integration into existing workstations.

Reliability, Cooling, and Energy Efficiency

Advanced Thermal Design

Designed for sustained workloads, the Quadro RTX 6000 ADA features an advanced cooling system that efficiently dissipates heat while maintaining quiet operation. This thermal design ensures long-term reliability and prevents throttling during intensive rendering or computational tasks. Users can maintain peak performance even during extended rendering sessions.

Optimized Power Consumption

Despite its high computational capability, the GPU operates efficiently with optimized power consumption. Ada Lovelace architecture reduces energy draw compared to previous generations while providing superior performance. This balance of power and efficiency is critical for professionals running continuous workloads in high-demand workstations.

Software and Driver Ecosystem

Nvidia Studio and Quadro Drivers

The Nvidia 699-5G133-0510-L00 benefits from the robust Quadro driver ecosystem, ensuring stability, compatibility, and performance across professional applications. Certified drivers optimize performance for popular creative, design, and scientific software, providing a seamless experience. Nvidia Studio enhancements further improve rendering, AI processing, and simulation tasks, allowing professionals to maximize productivity.
