HPE ML350 Intel Xeon Silver 64GB DDR5 SDRAM Tower Server P69310-005.

Processor

The HPE Proliant Ml350 Gen11 Base Model Tower Server is equipped with a powerful Xeon Silver 4410y processor. This processor is designed to deliver exceptional performance and efficiency, making it an ideal choice for businesses that require high computing power.

General Overview of P69310-005

The HPE Proliant ML350 Gen11 Server is engineered for optimal performance and scalability. Designed by Hewlett Packard Enterprise, this 4U rack-mountable server is ideal for demanding workloads and scalable operations.

Manufacturer Details

• Brand: Hewlett Packard Enterprise
• Part Number: P69310-005

Product Specifications

• Form Factor: Rack-mountable, 4U
• Height (Rack Units): 4U
• Scalability: 2-way
• Hot-swap Bays: 8
• Model Name: HPE Proliant ML350 Gen11 4410y 12-core 1P 64GB-R MR408i-O 8SFF 2x480GB SSD 2x800W RPS AMS Server (Base Model)

Processor and Chipset

• Processor: Intel Xeon Silver 4410Y
• Base Clock Speed: 2.0 GHz
• Max Turbo Speed: 3.9 GHz
• Core Count: 12 cores
• Quantity: 1 (Max 2)
• Upgradability: Yes
• Main Features: Hyper-Threading, Intel Turbo Boost Technology 2
• Socket: LGA4677 Socket-E
• Chipset: Intel C741

Cache Memory

• Installed Size: 30 MB L3 Cache
• Cache Per Processor: 30 MB

RAM Configuration

• Total Installed Size: 64 GB (expandable to 8 TB)
• Type: DDR5 SDRAM with Advanced ECC
• Effective Memory Speed: 4400 MHz
• Rated Memory Speed: 4800 MHz
• Form Factor: DIMM 288-pin
• Slots: 32 total (30 available)
• Features: Registered, Online Spare, Dual Rank, HPE SmartMemory
• Configuration: 2 x 32 GB

Internal Storage

• Type: SSD
• Capacity: 2 x 480 GB
• Interface: SATA 6 Gb/s

Optical Drive

• No Optical Drive Included

Storage Controller

• Type: 1 x RAID - OCP
• Interface Type: SATA-600, SAS 3.0, PCI Express (NVMe)
• Controller Name: HPE MR408i-O Gen11 SPDM
• Channels: 8
• RAID Levels: RAID 0, 1, 5, 6, 10, 50, 60
• Buffer Size: 4 GB

Graphics and Networking

• Video Memory: 16 MB
• Video Interfaces: VGA

Networking Features

• Interface Type: Open Compute Project Mezzanine (OCP) 3.0
• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: Broadcom BCM5719
• Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Protocols: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 6
• Features: Wake On LAN (WOL), PXE Support

Expansion and Connectivity

• Hot-swap Bays: 8 total (6 free) x 2.5 SFF
• PCIe Slots: 4 total (all free) x PCIe 5.0 x16 (x8 Mode)

Interfaces

• VGA: 1
• DisplayPort 1.1a: 1 (Front)
• HPE iLO - Type A: 1 (Front, service port)
• HPE iLO - RJ-45: 1 (Rear, management port)
• LAN (Gigabit Ethernet) - RJ-45: 4 (Rear)
• USB 3.2 Gen 1: 4 (1 Front, 2 Rear, 1 Internal)
• USB 2.0: 1 Internal

Miscellaneous Details

• Included Accessories: Standard CPU heatsink, 3 standard fans
• Theft/Intrusion Protection: Security lock slot (cable lock sold separately), padlock eye
• Security Slot Type: Kensington Security Slot
• Compliance Standards: TLS V1.2, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, Redfish API, SMBIOS 3.1, FIPS 140-3, ERP LOT 9, UEFI 2.7, Active Directory V1.0
• Manufacturer Selling Program: HPE Express Buy

Power Specifications

• Device Type: Hot-plug Power Supply
• Redundancy: Yes, 1+1 scheme
• Installed Qty: 2
• Max Supported Qty: 2
• Voltage Required: AC 100-120/200-240 V (50/60 Hz)
• Power Provided: 800 Watt
• 80 Plus Certification: 80 Plus Platinum

Operating System and Software

• Operating System: None Included
• Software: HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (available as free download)

Sustainability and Environmental Information

• Energy Star Certified: Yes
• Operating Temperature Range: 50 °F to 95 °F
• Humidity Range: 8 - 90% RH (non-condensing)

Dimensions and Weight

• Width: 6.9 inches
• Depth: 28 inches
• Height: 18.2 inches
• Weight: 54.52 lbs

Enhanced Performance

The Xeon Silver 4410y processor is built on Intel's advanced architecture, incorporating multiple cores and threads. This allows the processor to handle multiple tasks simultaneously, resulting in improved performance and faster response times. Whether you're running resource-intensive applications or handling complex workloads, this processor ensures smooth operation and minimal lag.

Efficient Power Consumption

Energy efficiency is a crucial consideration for businesses looking to minimize their operational costs and reduce their carbon footprint. The Xeon Silver 4410y processor is designed to deliver high performance while consuming less power compared to previous generations. This not only helps businesses save on their electricity bills but also contributes to sustainability efforts.

Optimized Virtualization

Virtualization has become a key technology for businesses, enabling them to maximize the utilization of their server resources. The Xeon Silver 4410y processor features advanced virtualization capabilities, allowing businesses to create and manage multiple virtual machines efficiently. This means that you can consolidate your applications and workloads onto a single server, reducing hardware costs and simplifying management.

Reliable Security Features

With the increasing threats to data security, it is crucial for businesses to have robust security measures in place. The Xeon Silver 4410y processor incorporates advanced security features that help protect your data from unauthorized access and malicious attacks. These features include hardware-enhanced encryption, secure boot, and memory protection technologies. By choosing a server with this processor, you can ensure the security of your sensitive business data.

Memory

The HPE Proliant Ml350 Gen11 Base Model Tower Server comes with a generous 64GB DDR5 memory capacity. This high-performance memory is designed to meet the demands of modern business applications and workloads.

Improved Application Performance

The large memory capacity of 64GB DDR5 enables the server to handle memory-intensive applications with ease. Whether you're running database systems, virtual machines, or data analytics software, this memory capacity ensures smooth and efficient performance. It eliminates the need for frequent disk access, reducing latency and improving overall application responsiveness.

Scalability and Future-Proofing

As businesses grow and their needs evolve, it is important to have a server that can scale alongside them. The 64GB DDR5 memory capacity of this server provides ample room for expansion and future upgrades. You can easily add more memory modules as your workload demands increase, ensuring that your server can accommodate your evolving requirements.

Reliability and Data Integrity

Data integrity is of utmost importance for businesses, especially when dealing with critical applications and sensitive information. The 64GB DDR5 memory in this server incorporates error-correcting code (ECC) technology, which detects and corrects memory errors in real-time. This ensures that your data remains intact and protected from potential corruption or loss.

Enhanced Virtualization Performance

Virtualization relies heavily on memory resources to efficiently allocate and manage virtual machines. The spacious 64GB DDR5 memory capacity of this server enables you to run multiple virtual machines simultaneously without compromising performance. It allows you to maximize the utilization of your server resources and achieve higher virtual machine density.

Drive Bays

The HPE Proliant Ml350 Gen11 Base Model Tower Server features 8SFF (Small Form Factor) drive bays. These drive bays provide the flexibility and scalability needed to accommodate various storage requirements.

Flexible Storage Options

With 8SFF drive bays, this server allows you to configure your storage system according to your specific needs. You can choose between different types of storage drives, such as solid-state drives (SSDs) for high-performance applications or hard disk drives (HDDs) for cost-effective mass storage. This flexibility ensures that you can optimize your storage solution based on your workload requirements and budget constraints.

Increased Storage Capacity

The 8SFF drive bays offer ample space for expanding your server's storage capacity. You can install multiple drives in these bays, allowing you to store large amounts of data and accommodate growing storage demands. Whether you need to store critical business data, multimedia files, or backups, these drive bays provide the necessary capacity.

Hot-Swap Capability

The 8SFF drive bays in this server support hot-swapping, which means you can replace or add drives while the server is running without interrupting its operation. This feature is particularly beneficial for businesses with demanding uptime requirements, as it minimizes downtime during maintenance or drive replacement. It ensures continuous access to data and avoids disruptions to critical business operations.

Improved Data Protection

Data protection is crucial for businesses to safeguard their sensitive information and ensure business continuity. The 8SFF drive bays support various RAID configurations, including RAID 0, RAID 1, RAID 5, and RAID 10. These RAID levels provide different levels of redundancy and data protection, allowing you to choose the one that best suits your needs. By implementing a RAID configuration, you can protect your data against drive failures and ensure its availability even in case of hardware issues.

Storage

The HPE Proliant Ml350 Gen11 Base Model Tower Server offers an array of storage options to meet the diverse needs of businesses. Whether you need high-performance storage or cost-effective mass storage, this server has you covered.

Storage Performance

The storage array in this server is designed to deliver exceptional performance, enabling faster data access and transfer speeds. Whether you're running databases, virtual machines, or data-intensive applications, this storage solution ensures that your operations are smooth and responsive. It minimizes latency and bottlenecks, allowing your applications to perform at their best.

Flexible Storage Configuration

The array storage configuration provides flexibility in terms of capacity and performance. You can choose between different types of storage drives, such as solid-state drives (SSDs) for high-speed performance or hard disk drives (HDDs) for cost-effective mass storage. Additionally, you have the option to configure the storage array with various RAID levels, providing different levels of redundancy and data protection.

High Availability and Fault Tolerance

Businesses cannot afford to lose access to their critical data due to hardware failures or system crashes. The storage array in this server incorporates fault-tolerant features to ensure high availability and data integrity. By implementing RAID configurations, redundant power supplies, and hot-swappable drives, this server minimizes the risk of data loss and downtime. It provides businesses with the peace of mind that their data is protected and accessible at all times.

Scalability for Growing Needs

As businesses grow and their storage needs increase, it is essential to have a server that can scale alongside them. The storage array in this server offers scalability options that allow you to expand your storage capacity as your business demands grow. You can add more drives or upgrade existing ones without disrupting your operations, ensuring that your server can accommodate your evolving storage requirements.

Power Supply

The HPE Proliant Ml350 Gen11 Base Model Tower Server features an array of power supply options to ensure reliable and uninterrupted operation. With its robust power supply configuration, this server offers businesses the peace of mind that their critical operations will not be affected by power-related issues.

Redundant Power Supply

This server is equipped with redundant power supplies, which means that even if one power supply fails, the other will seamlessly take over, ensuring uninterrupted operation. This redundant configuration eliminates the risk of downtime and keeps your business running smoothly, even in the event of a power supply failure.

High Efficiency and Energy Savings

Power efficiency is a key consideration for businesses looking to reduce their operational costs and environmental impact. The power supplies in this server are designed to deliver high efficiency, minimizing wasted energy and reducing electricity bills. By choosing a server with efficient power supplies, you can contribute to sustainability efforts while enjoying cost savings.

Hot-Plug Capability

The power supplies in this server support hot-plug capability, allowing you to replace or add power supplies while the server is running without interrupting its operation. This feature is particularly beneficial for businesses with demanding uptime requirements, as it minimizes downtime during maintenance or power supply replacement. It ensures continuous power supply and avoids disruptions to critical business operations.

Intelligent Power Management

The power supply array in this server incorporates intelligent power management features to optimize power usage and ensure reliable performance. These features include load balancing, power capping, and real-time monitoring. By intelligently managing power consumption, this server reduces the risk of power-related issues and maximizes the efficiency of your infrastructure.

In conclusion, the HPE Proliant Ml350 Gen11 Base Model Tower Server offers a range of impressive features that cater to the diverse needs of businesses. With its powerful Xeon Silver 4410y processor, generous 64GB DDR5 memory capacity, flexible drive bays, versatile storage array, and reliable power supply options, this server provides businesses with the performance, scalability, and reliability they need to support their critical operations. Whether you're running resource-intensive applications, managing virtualized environments, or storing vast amounts of data, this server is a valuable asset that helps businesses achieve their goals efficiently and effectively.
