HPE Proliant DL380 Gen10 6230 2.1GHz 20-Core 800W RPS Server P02466-B21
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Same product also available in:
SKU/MPN | Warranty | Price | Condition | You save |
---|---|---|---|---|
P02466-B21 | Six-Month (180 Days) | $1,680.00 | Excellent Refurbished | You save: $588.00 (26%) |
P02466-B21 | Six-Month (180 Days) | $3,650.00 | New (System) Pull | You save: $2,236.00 (38%) |
Processor
The HPE Proliant DL380 Gen10 6230 Server is equipped with a powerful processor that sets it apart from other servers in its class. With a 2.1GHz 20-core processor, this server offers exceptional performance and reliability for demanding workloads.
Product Overview of P02466-B21
- Brand: Hewlett Packard Enterprise (HPE)
- Part Number: P02466-B21
- Product Type: 2U Rack Mountable Server
Processor & Chipset Specifications
- CPU Model: Intel Xeon Gold 6230 with a base clock of 2.1 GHz
- Maximum Turbo Speed: 3.9 GHz
- Core Count: 20 Cores
- Processor Upgrade Options: Supports up to 2 CPUs
- Key Processor Features: Hyper-Threading, Intel Turbo Boost 2.0
- CPU Socket: FCLGA3647
- Chipset Type: Intel C621
Cache Memory Details
- L3 Cache Size: 27.5 MB per processor
Memory Specifications
- Installed RAM: 64 GB DDR4 SDRAM
- Maximum Supported RAM: 1 TB (with Registered RAM), 2 TB (with Load-Reduced RAM)
- Memory Speed: 2933 MHz
- Memory Slots: 12 slots total, 10 available (up to 24 slots with dual-processor configuration)
- Features: HPE SmartMemory, Dual Rank, Registered
Storage Controllers & RAID
- Controller Type: HPE Smart Array P816i-a
- Interface Type: SATA 6 Gb/s, SAS 12 Gb/s
- Supported RAID Levels: RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
- Controller Cache: 4 GB Buffer
Graphics Controller
- Video Memory: 16 MB
- Interface: VGA
Networking & Connectivity
- Ethernet Ports: 4x Gigabit Ethernet (RJ-45)
- Data Protocols Supported: Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management: iLO 5 with support for SNMP 3, IPMI 2.0, SMASH CLP
- Special Features: Wake-on-LAN (WOL), PXE Support
Expansion & Connectivity Options
- Drive Bays: 8x Hot-swap 2.5" SFF bays (all free)
- PCIe Slots:
- 1x PCIe 3.0 x16
- 2x PCIe 3.0 x8
- 1x FlexibleLOM
- 1x Internal MicroSD Card slot
- USB Ports: 5x USB 3.0 (1 front, 2 rear, 2 internal)
Power Supply & Efficiency
- Type: Hot-plug Power Supply
- Installed Power Supply: 2x 800W units
- Redundancy: Optional 1+1 power redundancy
- Voltage Support: 120/230V AC (50/60Hz)
- Certification: 80 PLUS Platinum
Physical Dimensions & Weight
- Width: 17.5 inches
- Depth: 26.7 inches
- Height: 3.4 inches
- Weight: 32.85 lbs
Compliance & Standards
- AES, FIPS 140-2, IPv6 Ready, PCI DSS, TLS v1.2
- ASHRAE Class A3 and A4
- WEEE 2002/95/EC, ACPI 6.1 compliant
Included Accessories
- Cable Management Arm
- 4x Standard Cooling Fans
- SFF Easy Install Rails
Benefits of a 2.1GHz 20-Core Processor
A processor is the brain of any server, and having a high-performance processor like the one in the HPE Proliant DL380 Gen10 6230 Server brings several benefits to users.
1. Enhanced Processing Power
The 2.1GHz clock speed combined with the 20 cores allows for rapid data processing and execution of complex tasks. This enhanced processing power enables faster response times, improved productivity, and efficient multitasking capabilities.
2. Increased Efficiency
The 20 cores in the processor enable parallel processing, which means multiple tasks can be executed simultaneously. This leads to increased efficiency as more work can be completed in less time. Users can run multiple applications without experiencing performance bottlenecks or slowdowns.
3. Scalability
The HPE Proliant DL380 Gen10 6230 Server's processor is designed to handle demanding workloads and can be easily scaled up as business needs grow. Whether it's running resource-intensive applications or handling heavy data workloads, this server can handle the task with ease.
4. Improved Virtualization Performance
Virtualization is a critical aspect of modern IT infrastructure. The 2.1GHz 20-core processor in this server enhances virtualization performance by enabling efficient allocation of resources to virtual machines. It allows for the smooth operation of multiple virtual machines, ensuring optimal performance and minimizing downtime.
Importance of a Powerful Processor
Having a powerful processor is crucial for businesses that rely heavily on data processing, virtualization, and resource-intensive applications. The HPE Proliant DL380 Gen10 6230 Server's 2.1GHz 20-core processor offers the necessary performance and reliability to meet these demands.
Conclusion
In conclusion, the HPE Proliant DL380 Gen10 6230 Server's 2.1GHz 20-Core processor is a key feature that sets it apart from other servers. The enhanced processing power, increased efficiency, scalability, and improved virtualization performance make it an excellent choice for businesses that require a high-performing server.
Power Supply
The power supply is a critical component of any server, and the HPE Proliant DL380 Gen10 6230 Server comes equipped with an 800W RPS (Redundant Power Supply). This feature ensures reliable and uninterrupted power delivery to the server, even in the event of a power failure.
Benefits of an 800W RPS
A reliable power supply is essential for maintaining server uptime and protecting critical data. The HPE Proliant DL380 Gen10 6230 Server's 800W RPS offers several benefits to users.
1. Redundancy and Fault Tolerance
Redundancy is crucial in server environments to ensure continuous operation and prevent downtime. With an 800W RPS, the server has redundant power supplies that can automatically take over if one power supply fails. This provides fault tolerance and ensures uninterrupted power supply to critical applications and data.
2. High-Efficiency Power Delivery
The 800W RPS in the HPE Proliant DL380 Gen10 6230 Server is designed to deliver power efficiently. It has a high-efficiency rating, which means it converts more of the incoming power into usable energy, reducing energy waste and lowering electricity costs. This feature is particularly important for businesses aiming to minimize their environmental footprint and reduce energy expenses.
3. Flexible Configuration Options
The 800W RPS allows for flexible configuration options. It supports hot-plugging, which means power supplies can be added or replaced while the server is running, without causing any disruption. This feature enables businesses to expand or upgrade their server infrastructure without downtime, ensuring continuous operations.
4. Enhanced System Reliability
The redundant power supply in the HPE Proliant DL380 Gen10 6230 Server improves system reliability. Power fluctuations or failures can lead to data corruption, hardware damage, and system crashes. With an 800W RPS, the server remains protected from such issues, minimizing the risk of downtime and data loss.
Importance of a Reliable Power Supply
A reliable power supply is crucial for maintaining server uptime, protecting critical data, and ensuring uninterrupted operations. The HPE Proliant DL380 Gen10 6230 Server's 800W RPS provides the necessary redundancy, high-efficiency power delivery, flexible configuration options, and enhanced system reliability.
Conclusion
In conclusion, the HPE Proliant DL380 Gen10 6230 Server's 800W RPS is an essential feature that ensures reliable power delivery and protects critical infrastructure. The redundancy, high-efficiency power delivery, flexibility, and enhanced system reliability make it an ideal choice for businesses that require uninterrupted operations.
Part Number
The part number is a unique identifier assigned to a specific product or component. In the case of the HPE Proliant DL380 Gen10 6230 Server, its part number is P02466-B21. Understanding the importance and benefits of the part number can help users in various ways.
Benefits of Part Number P02466-B21
The part number P02466-B21 brings several benefits to users of the HPE Proliant DL380 Gen10 6230 Server.
1. Easy Identification and Documentation
The part number serves as a unique identifier for the server model. It allows for easy identification and documentation of the specific configuration and components of the server. This is particularly useful for IT administrators and technicians who need to keep track of multiple servers or document their inventory.
2. Compatibility Assurance
Each part number corresponds to a specific configuration, ensuring compatibility between components. By referencing the part number, users can be confident that the server and its components are designed to work together seamlessly. This eliminates compatibility issues and minimizes the risk of performance or functionality problems.
3. Efficient Ordering and Replacement
When ordering additional components or replacement parts for the HPE Proliant DL380 Gen10 6230 Server, knowing the part number is crucial. It ensures accurate ordering and helps prevent errors or delays in receiving the correct components. With the part number P02466-B21, users can efficiently source and replace components, minimizing downtime.
4. Technical Support and Documentation Access
Part numbers are often used as references when seeking technical support or accessing product documentation. By providing the part number P02466-B21, users can easily communicate with support personnel and access relevant documentation specific to their server model. This streamlines troubleshooting and ensures access to accurate information.
Importance of Knowing the Part Number
Knowing part number P02466-B21 is essential for efficient server management, compatibility assurance, ordering/replacement accuracy, and accessing technical support and documentation.
