SonicWall 02-SSC-8382 SWS14-48 10GB 176Gbps SFP+ Managed Rack Mount Switch
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
SONICWALL 02-SSC-8382 Managed Switch Specifications
Product Overview
- Manufacturer: SonicWall
- Part Number: 02-SSC-8382
- Device Type: Managed Switch, 52 Ports
- Form Factor: Rack-mountable, 1U
- Network Type: 10 Gigabit Ethernet
- Port Configuration: 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
- Power Over Ethernet (PoE): PoE+ (Power over Ethernet)
- PoE Power Budget: 740 Watts
Performance & Capacity
- Switching Capacity: 176 Gbps
- VLAN Support: 4096 Virtual Interfaces
- MAC Address Table: 32,000 Entries
- Routing Protocol: Static IP Routing
- Remote Management: SNMP (v1, v2c, v3), HTTPS, SSH, CLI
- Authentication: Radius
Key Features
- Automatic Flow Control & Auto-Negotiation
- Support for VLANs and Auto-Uplink (Auto MDI/MDI-X)
- IGMP Snooping, Syslog, and Port Mirroring
- Upgradeable Firmware
- Supports Rapid Spanning Tree Protocol (RSTP) & Multiple Spanning Tree Protocol (MSTP)
- DHCP Snooping and Access Control Lists (ACL) Support
- Enhanced Quality of Service (QoS) and Jumbo Frame Support
- Radius Support & STP Root Guard
- Link Aggregation Control Protocol (LACP) & DHCP Client
- Energy-Efficient Ethernet (EEE)
- VLAN Tagging, Daisy-Chaining, and Zero-Touch Configuration
Compliant Standards
- IEEE 802.1p
- IEEE 802.3af, IEEE 802.1x, IEEE 802.1ab (LLDP)
- IEEE 802.3at
Memory & Storage
- RAM: 512 MB
- Flash Memory: 128 MB
- Status Indicators: PoE, LAN
Connectivity & Expansion
- 48 x 1000BASE-T RJ-45 PoE+ Ports
- 4 x 10GBASE-X SFP+ Ports
- 1 x Console RJ-45 Port
Power Specifications
- Power Supply: Internal Power Supply
- Power Output: 900 Watts
- Required Voltage: AC 120/230V (50/60Hz)
- Operational Power Consumption: 530 Watts
Ports
The SonicWall 02-SSC-8382 Networking Switch is equipped with a remarkable 52 ports, making it an ideal choice for businesses and organizations that require extensive connectivity options. These ports allow users to connect multiple devices simultaneously, creating a robust and efficient network infrastructure.
Enhanced Connectivity
With 52 ports available, the SonicWall Networking Switch offers enhanced connectivity options for users. This means that businesses can connect a wide range of devices, including computers, servers, printers, and other networking equipment, without the need for additional switches or routers. The abundance of ports ensures that there is ample room for expansion and future growth, making it a cost-effective solution for businesses of all sizes.
Efficient Network Management
The abundance of ports provided by the SonicWall Networking Switch allows for efficient network management. Each port can be assigned to a specific device or department, enabling network administrators to easily monitor and control network traffic. This level of control ensures that bandwidth is allocated appropriately, preventing congestion and optimizing network performance.
Flexibility and Scalability
The 52 ports offered by the SonicWall Networking Switch provide users with the flexibility to accommodate their evolving network needs. As businesses grow and add more devices to their network, having additional ports readily available eliminates the need to invest in new networking equipment. This scalability allows businesses to adapt to changing requirements without incurring significant costs.
Redundancy and High Availability
The SonicWall Networking Switch's 52 ports also enable redundancy and high availability in network infrastructures. By connecting devices to multiple ports, businesses can ensure continuous operation even in the event of a port failure. This redundancy feature minimizes downtime and guarantees uninterrupted connectivity for critical systems and applications.
Data Transfer Rate
When it comes to data transfer rate, the SonicWall Networking Switch stands out with its impressive 10 GB speed. This high-speed capability enhances network performance and enables users to transfer large files and data-intensive applications quickly and efficiently.
Fast Data Transfer
The 10 GB data transfer rate of the SonicWall Networking Switch allows for lightning-fast data transfer between devices connected to the network. This is especially beneficial for businesses that rely on data-intensive applications such as video editing, graphic design, and scientific research. With this high-speed capability, users can experience minimal latency, ensuring smooth and uninterrupted workflow.
Improved Productivity
The fast data transfer rate offered by the SonicWall Networking Switch significantly improves productivity in the workplace. With the ability to transfer large files quickly, employees can save valuable time waiting for data transfers to complete. This increased efficiency translates into higher productivity levels and enables businesses to accomplish more in less time.
Seamless Multimedia Streaming
The 10 GB data transfer rate is crucial for businesses that heavily rely on multimedia streaming. Whether it's video conferencing, live streaming, or accessing media-rich content, a faster data transfer rate ensures smooth playback and prevents buffering or lagging issues. This is particularly important for industries such as media production, where seamless streaming is essential for delivering high-quality content to clients and consumers.
Future-Proofing
Investing in a networking switch with a 10 GB data transfer rate is a future-proofing strategy. As technology advances and data requirements continue to grow, having a switch capable of handling higher data transfer speeds ensures that businesses can keep up with evolving demands. By investing in the SonicWall Networking Switch, users can be confident that their network infrastructure will be able to handle future data-intensive applications.
Total Bandwidth
The SonicWall Networking Switch boasts an impressive total bandwidth of 176 Gbps. This high bandwidth capacity plays a crucial role in ensuring smooth and uninterrupted network performance, even under heavy traffic loads.
Seamless Network Performance
With a total bandwidth of 176 Gbps, the SonicWall Networking Switch can handle high volumes of data traffic without experiencing congestion or slowdowns. This ensures smooth network performance, allowing users to transfer data, access resources, and communicate without any interruptions. Businesses can rely on this switch to maintain optimal network performance even during peak usage periods.
Support for Bandwidth-Intensive Applications
The high total bandwidth provided by the SonicWall Networking Switch is particularly beneficial for businesses that utilize bandwidth-intensive applications. Applications such as video conferencing, cloud-based services, and virtualization require significant bandwidth to operate seamlessly. By investing in a switch with a high total bandwidth like the SonicWall Networking Switch, businesses can ensure that these applications perform at their best without experiencing bottlenecks or slowdowns.
Scalability and Future Growth
The 176 Gbps total bandwidth capacity of the SonicWall Networking Switch allows for scalability and future growth. As businesses expand and add more devices to their network, the switch can accommodate increased traffic demands without compromising performance. This scalability ensures that the network infrastructure can support the evolving needs of the organization, saving costs associated with upgrading equipment in the future.
Form Factor
The SonicWall Networking Switch features a rack-mountable form factor, making it an ideal choice for businesses looking to optimize their physical space and streamline their network infrastructure.
Space Efficiency
The rack-mountable form factor of the SonicWall Networking Switch allows for efficient utilization of physical space. By fitting into standard server racks or cabinets, businesses can maximize their available space and reduce clutter caused by standalone switches or routers. This form factor is particularly advantageous for businesses with limited office space or those looking to create a centralized and organized network environment.
Improved Cable Management
The rack-mountable design of the SonicWall Networking Switch facilitates improved cable management. With the switch installed in a server rack, cables can be neatly organized and routed, reducing the risk of tangling or accidental disconnections. This not only improves the overall aesthetics of the network infrastructure but also simplifies troubleshooting and maintenance tasks.
Centralized Network Infrastructure
The rack-mountable form factor promotes a centralized network infrastructure. By consolidating networking equipment into a server rack, businesses can easily manage and maintain their network components. This centralization simplifies troubleshooting, allows for efficient cable management, and provides a clear overview of the entire network infrastructure, resulting in streamlined operations and reduced downtime.
Additional Info
The SonicWall Networking Switch offers additional features that further enhance its capabilities, including being managed and equipped with SFP+ ports.
Enhanced Network Control
The managed feature of the SonicWall Networking Switch provides users with enhanced network control and security. With management capabilities, network administrators can monitor and configure the switch remotely, ensuring optimal performance and security. This level of control allows for fine-tuning of network settings, implementation of security measures, and identification of potential issues before they impact the network.
Network Segmentation
The managed feature enables network segmentation, which is crucial for businesses that require strict separation between different departments or user groups. By creating virtual LANs (VLANs), sensitive data or resources can be isolated from other parts of the network, enhancing security and preventing unauthorized access. This segmentation feature is particularly important for industries such as finance, healthcare, and government where data privacy and compliance are critical.
Advanced Security Measures
The managed feature of the SonicWall Networking Switch allows for the implementation of advanced security measures. Network administrators can configure access control lists (ACLs), enabling them to control the flow of network traffic based on predefined rules. This ensures that only authorized devices and users can access specific resources, protecting the network from potential threats and unauthorized access attempts.
SFP+ Ports for High-Speed Connectivity
The SonicWall Networking Switch is equipped with SFP+ ports, which provide high-speed connectivity options. These ports support fiber optic connections, allowing for faster data transfer rates over longer distances. The inclusion of SFP+ ports expands the versatility of the switch, enabling businesses to connect to fiber optic networks or utilize high-speed connections between switches.
Flexible Network Architecture
The SFP+ ports offer flexibility in network architecture. Users can choose between copper or fiber optic connections based on their specific requirements. This flexibility allows businesses to adapt their network infrastructure to different environments, whether it's connecting devices within a data center or extending the network over long distances.
Future-Proofing with Fiber Optic Technology
Investing in a switch with SFP+ ports future-proofs the network infrastructure by leveraging fiber optic technology. Fiber optic cables have higher bandwidth capabilities, better resistance to electromagnetic interference, and longer transmission distances compared to traditional copper cables. By utilizing SFP+ ports and fiber optic connections, businesses can ensure that their network infrastructure can handle future bandwidth-intensive applications and evolving connectivity needs.
In conclusion, the SonicWall 02-SSC-8382 Networking Switch offers an impressive range of features that cater to the connectivity, bandwidth, and management needs of businesses. With 52 ports, a 10 GB data transfer rate, a total bandwidth of 176 Gbps, a rack-mountable form factor, and additional managed and SFP+ port capabilities, this switch provides users with enhanced connectivity options, improved network performance, scalability, and flexibility. Whether it's for small businesses or large enterprises, the SonicWall Networking Switch is a reliable and efficient solution for building a robust and future-proof network infrastructure.
