SRJXQ Intel Xeon Platinum 8380H 28-Core 2.90GHz 38.5MB L3 Cache Socket FCLGA4189 Processor

SRJXQ Intel Xeon Platinum 8380H Processor Overview

The SRJXQ Intel Xeon Platinum 8380H is a high-performance server processor designed to meet the demands of enterprise-level computing. With 28 cores, a base clock speed of 2.90GHz, and a massive 38.5MB L3 cache, this processor delivers exceptional performance for a wide range of applications. Its support for 6.00GT/s UPI (Ultra Path Interconnect) ensures fast and efficient communication between processors, while the Socket FCLGA4189 compatibility provides flexibility in server configurations. Ideal for data centers, cloud computing, and high-performance computing (HPC) environments, the Xeon Platinum 8380H offers advanced features and reliability for demanding workloads.

Core Specifications and Performance

• Manufacturer: Intel
• Part Number: SRJXQ
• Processor Series: 3rd Generation Intel Xeon Scalable (Platinum 8300 Series)
• Processor Code Name: Cooper Lake
• Supported Socket Type: FCLGA4189
• Frequency: Base 2.90 GHz, with a Max Turbo Frequency of up to 4.30 GHz
• Core Count: 28 cores for high multitasking efficiency
• Threads: 56 threads for enhanced parallel processing
• Cache Size: 38.5 MB for fast data retrieval
• UPI Links: 6 for improved inter-processor communication
• Lithography: 10nm for advanced chip technology
• Thermal Design Power (TDP): 250W
• Note: Does not include heatsink, accessories, or tools

Memory and Storage Specifications

• Maximum Memory Capacity: Supports up to 1.12TB (1,120GB), depending on memory type
• Supported Memory Types: DDR4 RDIMM
• Maximum Memory Speed: 3200 MHz for high-speed data access
• Memory Channels: 6 channels for efficient data flow
• ECC Memory Support: Yes, for enhanced data integrity
• Intel Optane DC Persistent Memory: Supported for additional performance

Expansion and Scalability Options

• Scalability: S8S for flexible system configurations
• PCI Express Revision: 3.0
• Maximum PCI Lanes: 64 for extensive expansion capabilities

Advanced Technologies and Features

• Intel Deep Learning Boost (DL Boost): Yes, for optimized AI performance
• Intel Resource Director Technology (RDT): Yes, for enhanced resource management
• Intel Optane Memory Support: Yes, for improved data handling
• Intel Speed Shift Technology: Yes, for faster responsiveness
• Intel Hyper-Threading Technology: Yes, for increased processing efficiency
• Intel Virtualization Technologies: VT-x, VT-d, and Extended Page Tables (EPT) supported
• Intel TSX-NI: Yes, for advanced transactional synchronization
• Instruction Set Extensions: Intel AVX-512 with 2 FMA units for enhanced computational performance
• Intel Volume Management Device (VMD): Yes, for improved storage management

Security and Reliability Features

• Intel Advanced Encryption Standard (AES) New Instructions: Yes, for enhanced data security
• Execute Disable Bit: Yes, for additional protection against malicious attacks
• Intel Run Sure Technology: Yes, ensuring high reliability
• Mode-Based Execute Control (MBE): Yes, for security against certain exploits

Key Features of the Intel Xeon Platinum 8380H Processor

28 Cores and 56 Threads for Superior Multithreaded Performance

The Intel Xeon Platinum 8380H is equipped with 28 cores and 56 threads, providing robust multitasking capabilities for handling complex computational tasks. This high core and thread count is ideal for applications requiring extensive parallel processing, such as large-scale simulations, data analytics, and virtualization. The processor’s architecture ensures that multiple threads are managed efficiently, delivering high performance for both single-threaded and multi-threaded workloads.

Base Clock Speed of 2.90GHz with Intel Turbo Boost Technology

Featuring a base clock speed of 2.90GHz, the Xeon Platinum 8380H offers a solid foundation for high-speed data processing. Intel Turbo Boost Technology enhances this by dynamically increasing the processor’s clock speed during peak workloads. This capability ensures optimal performance for resource-intensive applications, improving responsiveness and efficiency in high-demand scenarios.

38.5MB L3 Cache for Faster Data Access

The processor’s 38.5MB L3 cache significantly reduces data access latency by storing frequently used data close to the cores. This large cache size improves overall system performance, particularly in data-intensive applications such as real-time analytics, database management, and high-performance computing tasks. Faster data retrieval helps accelerate application response times and enhances overall processing efficiency.

6.00GT/s UPI for Efficient Inter-Processor Communication

Intel’s Ultra Path Interconnect (UPI) with a speed of 6.00GT/s facilitates rapid and efficient communication between processors. This high-speed interconnect technology is crucial for multi-socket server configurations, allowing for quick data transfer and improved overall system performance. UPI ensures that multiple processors work cohesively, reducing bottlenecks and enhancing computational throughput.

Socket FCLGA4189 Compatibility for Flexible Server Configurations

The SRJXQ Intel Xeon Platinum 8380H is compatible with the Socket FCLGA4189, offering flexibility in server design and configuration. This socket type supports a range of server motherboards, making it easier to integrate the processor into existing server infrastructures or new builds. The compatibility allows for scalable solutions and efficient upgrades, catering to diverse enterprise needs.

Performance and Efficiency of the Intel Xeon Platinum 8380H

Optimized for Data Centers and Cloud Computing

The Xeon Platinum 8380H is designed to excel in data center environments, where scalability, reliability, and performance are critical. Its high core count and advanced features make it an excellent choice for cloud computing, where efficient resource management and rapid processing are essential. The processor’s capabilities ensure smooth operation of virtualized environments and enhanced performance for cloud-based applications.

Advanced Intel Technologies for Enhanced Processing Power

The processor incorporates several advanced Intel technologies that contribute to its high performance and efficiency. These include:

Intel Deep Learning Boost (DL Boost)

DL Boost accelerates AI inference and training tasks, providing significant performance improvements for artificial intelligence and machine learning applications. This technology enables faster processing of AI models and data, enhancing overall computational efficiency.

Intel Speed Select Technology

Intel Speed Select Technology allows for granular control of performance and power consumption, optimizing the processor’s capabilities based on workload requirements. This feature enables efficient performance tuning and workload management, ensuring that resources are allocated effectively.

Intel Hyper-Threading Technology

Intel Hyper-Threading Technology enhances parallel processing by enabling each core to handle two threads simultaneously. This capability improves multitasking efficiency and overall system performance, making it suitable for environments that require high levels of concurrent processing.

Compatibility and Integration Capabilities

Scalable Multi-Socket Configurations

The Xeon Platinum 8380H supports multi-socket configurations, allowing for the deployment of systems with multiple processors. This scalability is crucial for high-performance servers and data centers that require substantial computing power. Multi-socket configurations enable businesses to scale their IT infrastructure as needed, accommodating growing workloads and increasing demands.

Support for Intel Optane Persistent Memory

The processor’s compatibility with Intel Optane Persistent Memory offers a unique combination of memory and storage. This technology provides increased memory capacity and faster data access, benefiting applications that require high throughput and low latency. Optane Persistent Memory enhances performance for in-memory databases, real-time analytics, and other data-intensive tasks.

Applications and Use Cases for the Intel Xeon Platinum 8380H

Data Centers and Cloud Environments

The Xeon Platinum 8380H is well-suited for data center operations and cloud computing environments. Its high core count, advanced technologies, and scalability make it an ideal choice for managing virtualized workloads, optimizing cloud infrastructure, and supporting large-scale data processing.

High-Performance Computing (HPC)

In high-performance computing scenarios, the Xeon Platinum 8380H delivers exceptional processing power for scientific simulations, complex calculations, and large-scale modeling. Its performance capabilities are designed to handle demanding HPC tasks with efficiency, providing the computational resources required for advanced research and development projects.

Artificial Intelligence and Machine Learning

The processor’s support for Intel Deep Learning Boost (DL Boost) accelerates AI and machine learning workloads, enabling faster training and inference for AI models. This technology enhances performance for applications involving data analysis, predictive modeling, and real-time decision-making.

Enterprise Resource Planning (ERP) and Database Management

For ERP systems and database management applications, the Xeon Platinum 8380H provides robust performance and reliability. Its high core count and large cache size improve transaction processing, query performance, and overall system efficiency, making it a valuable asset for businesses relying on complex database solutions.

Power Efficiency and Thermal Management

Dynamic Power Management Features

Intel’s dynamic power management technologies enable the Xeon Platinum 8380H to adjust its power consumption based on workload demands. This adaptive power management helps to optimize energy use, reduce operational costs, and enhance overall system efficiency without sacrificing performance.

Advanced Thermal Management

The Xeon Platinum 8380H includes advanced thermal management features that ensure the processor operates within safe temperature limits. Effective heat dissipation and cooling solutions are crucial for maintaining consistent performance, especially in high-density server environments where heat management is essential.

Compatibility with Advanced Cooling Solutions

For environments with stringent cooling requirements, the Xeon Platinum 8380H is compatible with advanced cooling systems such as liquid cooling. These systems provide superior heat management, enabling the processor to perform efficiently even under high loads and in challenging thermal conditions.

Reliability, Availability, and Serviceability (RAS) Features

Intel Run Sure Technology for Enhanced Reliability

Intel Run Sure Technology provides advanced reliability features, including predictive failure analysis and extensive diagnostics. These features help to ensure maximum uptime and system stability, making the Xeon Platinum 8380H a dependable choice for mission-critical applications and enterprise environments.

Error-Correcting Code (ECC) Memory Support

The processor’s support for ECC memory enhances data integrity by detecting and correcting memory errors. This capability is essential for applications requiring high levels of accuracy and reliability, such as financial transactions, scientific research, and healthcare data management.

Self-Healing Capabilities and Error Detection

Built-in self-healing mechanisms and advanced error detection contribute to the overall reliability of the Xeon Platinum 8380H
