AOC-MTG-I4TM Supermicro 4 Ports 10GB SIOM Adapter

Supermicro AOC-MTG-I4TM Quad Port 10GbE Network Adapter

The Supermicro AOC-MTG-I4TM is a high-performance networking solution engineered for enterprise environments and modern data centers. Powered by the Intel® X550 chipset, this adapter provides advanced virtualization capabilities, reliable connectivity, and optimized network traffic management, making it an ideal choice for IT professionals seeking to enhance infrastructure performance.

Technical Specifications Overview

• Brand: Supermicro
• Model: AOC-MTG-I4TM
• Product Type: Quad-Port 10GbE Network Adapter
• Controller: Intel® X550 dual 10GbE MAC + PHY
• Dimensions: 92mm (W) x 87.1mm (D)

Primary Features & Capabilities

• Quad RJ-45 10GBASE-T ports supporting high-speed data transfer
• Compact Super I/O Module (SIOM) form factor for space-efficient integration
• Integrated Intel® X550 controller for seamless virtualization and scalable I/O
• Low latency operation with support for MSI/MSI-X interrupts
• Comprehensive checksum offloading for IPv4 and IPv6 protocols

Virtualization-Optimized Networking

This adapter comes equipped with a comprehensive set of virtualization enhancements, providing superior flexibility and multi-tenant support in virtualized infrastructures:

• Supports advanced network virtualization protocols such as VXLAN and NVGRE
• 64 transmit and receive queues per port for improved data throughput
• PCI-SIG SR-IOV (Single Root I/O Virtualization) compliant
• 802.1Q VLAN tagging for secure and segmented network environments
• Flexible Port Partitioning (FPP) with up to 64 virtual functions per port

Enhanced Storage Connectivity Features

Optimize storage networking operations with built-in support for:

• iSCSI remote boot capability for streamlined diskless server deployment
• Preboot Execution Environment (PXE) enabling network-based system booting
• Simple Network Management Protocol (SNMP) and Remote Network Monitoring (RMON) for robust performance analysis

Reliable Remote Management & Monitoring

The adapter includes powerful remote management features ideal for enterprise system administrators:

• IEEE 1588 precision time protocol for synchronized network timing
• Support for NC-SI (Network Controller Sideband Interface) for out-of-band management
• Comprehensive asset management support on Supermicro server platforms

Cabling and Compatibility Details

• RJ-45 Cat-6 cables supported up to 55 meters, Cat-6A up to 100 meters
• Fully compatible with Supermicro motherboards and systems equipped with Super I/O Module slots

Operating Conditions and Environmental Tolerance

• Operational temperature range: 0°C to 55°C (32°F to 131°F)
• Storage temperature: -40°C to 70°C (-40°F to 158°F)
• Storage humidity: 90% non-condensing at 35°C

Advanced I/O Functions

• Multiple Queue technology with 64 transmit and receive queues per port
• TCP segmentation offload for efficient large packet handling
• Receive and Transmit Side Scaling for balanced CPU load distribution
• Stateless offloading for VXLAN, NVGRE, TCP/UDP checksums

Key Advantages for Enterprise Networks

• Highly scalable and efficient networking adapter for growing infrastructures
• Energy-efficient design reducing operational power consumption
• Superior performance in virtualized and high-demand environments
• Broad compatibility with Supermicro’s server product lines

Supermicro AOC-MTG-I4TM 4 Ports SFP+ 10GB x710 Super I/O Module (SIOM) Network Adapter Overview

The Supermicro AOC-MTG-I4TM 4 Ports SFP+ 10GB x710 Super I/O Module (SIOM) network adapter represents a highly scalable and high-performance networking solution designed for enterprise data centers, cloud infrastructure, virtualization, and high-density server environments. Powered by the advanced Intel X710 Ethernet controller, this adapter ensures low-latency, high-throughput, and efficient connectivity for mission-critical applications. As a member of Supermicro's SIOM family, the AOC-MTG-I4TM leverages the flexible and innovative SIOM form factor, providing a streamlined approach to networking within high-performance server deployments.

Key Features of the Supermicro AOC-MTG-I4TM Network Adapter

Advanced Intel X710 Ethernet Controller

At the core of the Supermicro AOC-MTG-I4TM lies the Intel X710 Ethernet controller, which delivers a comprehensive set of networking technologies for both traditional and virtualized server environments. This controller provides four 10 Gigabit SFP+ ports, supporting high-speed data transfer, advanced packet filtering, and hardware offloads that enhance server performance and reduce CPU overhead.

SIOM (Super I/O Module) Form Factor

The SIOM form factor offers a modular and hot-swappable solution, allowing for high-speed networking without occupying valuable PCIe slots within the server chassis. This design facilitates seamless integration with Supermicro's wide range of servers and optimizes airflow within densely populated racks. The SIOM architecture ensures future-proofing and adaptability, making it ideal for rapidly evolving data center environments.

Flexible and Scalable Connectivity

With four SFP+ ports supporting 10 Gigabit Ethernet connections, the AOC-MTG-I4TM is ideal for scenarios requiring high-speed, low-latency network performance. These ports support a variety of fiber optic and Direct Attach Copper (DAC) cables, providing versatility in network design and deployment. This flexibility allows IT administrators to tailor their infrastructure based on bandwidth requirements, distance limitations, and cost considerations.

Enterprise Applications and Use Cases

Cloud Infrastructure and Virtualization

The Supermicro AOC-MTG-I4TM is particularly well-suited for virtualized environments where multiple virtual machines require high-speed, reliable network connections. Its Intel X710 controller supports technologies such as Virtual Machine Device Queues (VMDq), Single Root I/O Virtualization (SR-IOV), and Network Virtualization using Generic Routing Encapsulation (NVGRE) and VXLAN offloads, enabling efficient traffic management and reduced server CPU utilization.

Data Center and High-Performance Computing (HPC)

For enterprise data centers and HPC deployments, theAOC-MTG-I4TM ensures high-bandwidth, low-latency network performance critical for distributed computing applications, big data analytics, and scientific simulations. The adapter's high port density and modular SIOM design streamline network topologies and reduce infrastructure complexity.

Enterprise Storage Networks

As storage demands increase, enterprise environments rely on high-speed interconnects to support technologies such as NVMe over Fabrics (NVMe-oF) and iSCSI. The Supermicro AOC-MTG-I4TM provides the bandwidth and reliability necessary to sustain data-intensive workloads and enhance storage network performance.

Technical Specifications

Port Configuration and Speed

• Number of Ports: 4
• Port Type: SFP+
• Speed: 10 Gigabit Ethernet per port
• Connector Type: SFP+

Controller and Protocol Support

• Controller: Intel X710 Ethernet Controller
• Protocols Supported: IPv4, IPv6, TCP/UDP, VLAN tagging (IEEE 802.1Q), QoS, SR-IOV, VMDq, VXLAN, NVGRE
• Checksum Offloads: IPv4, IPv6, TCP, UDP
• RSS (Receive Side Scaling) and MSI-X interrupt support

Form Factor and Compatibility

• Form Factor: Super I/O Module (SIOM)
• Compatible Supermicro Systems: Wide range of Supermicro 1U, 2U, and multi-node servers with SIOM slots
• Hot-swappable: Yes

Benefits of Deploying the AOC-MTG-I4TM Network Adapter

Enhanced Network Performance

With its four 10GbE ports and Intel X710 controller, the Supermicro AOC-MTG-I4TM delivers exceptional network throughput and low latency, which are essential for high-traffic environments and latency-sensitive applications. This ensures optimal performance for business-critical operations and enterprise workloads.

Operational Efficiency

The SIOM form factor minimizes internal cabling and preserves PCIe slot availability, contributing to better airflow and easier server maintenance. The hot-swappable design allows network upgrades or replacements without server downtime, enhancing operational efficiency and minimizing service interruptions.

Future-Proof Infrastructure

As enterprise networking continues to evolve towards higher speeds and increased virtualization, the AOC-MTG-I4TM’s support for advanced networking technologies ensures infrastructure investments remain viable and scalable. Its compatibility with a range of Supermicro servers allows seamless expansion and infrastructure standardization.

Deployment Scenarios

High-Density Server Environments

Modern data centers often employ high-density server configurations to maximize compute power per rack unit. The SIOM architecture of the AOC-MTG-I4TM enables multiple network adapters to be installed without consuming PCIe slots, preserving valuable expansion capacity for storage controllers or accelerators.

Virtualized Enterprise Networks

For environments running extensive virtual machine workloads, this adapter provides reliable, high-speed connections supporting virtualized networking technologies. Its support for VMDq and SR-IOV enables efficient VM-to-VM and VM-to-external network traffic routing while minimizing CPU overhead.

Redundant Network Topologies

To ensure high availability and network resilience, the four SFP+ ports can be configured for redundancy or link aggregation (LACP). This provides fault tolerance and increased aggregate bandwidth, essential for enterprise applications and database servers requiring uninterrupted connectivity.

Management and Diagnostics

Supermicro Server Management Integration

The AOC-MTG-I4TM integrates with Supermicro’s server management utilities, providing comprehensive monitoring, configuration, and diagnostics capabilities. IT administrators can view link status, port speed, and error statistics through the server’s IPMI (Intelligent Platform Management Interface) or management software suite.

Advanced Diagnostic Tools

The Intel X710 controller includes support for extensive diagnostics, including loopback testing, error counters, and firmware updates. These tools aid in rapid fault isolation, performance optimization, and proactive infrastructure management.

Network Security Features

Data Protection and Secure Networking

The AOC-MTG-I4TM supports advanced security features, including VLAN tagging, secure boot, and firmware protection. IEEE 802.1q VLAN support enables network segmentation for improved traffic management and security. Additionally, hardware-based traffic filtering and checksum offloads contribute to secure, efficient network data handling.

SR-IOV and Virtualization Security

By leveraging SR-IOV, the adapter allows network traffic to bypass the hypervisor, reducing exposure to software-based attacks and improving overall VM-to-VM isolation. This enhances security in multi-tenant cloud and enterprise virtualization environments.

Compatible Cables and Transceivers

Supported SFP+ Modules

• 10GBase-SR for short-range fiber connections up to 300 meters
• 10GBase-LR for long-range fiber connections up to 10 kilometers
• Direct Attach Copper (DAC) cables for cost-effective short-distance connections

Vendor Compatibility

The adapter is compatible with a wide range of certified transceivers and DAC cables from leading networking manufacturers including Intel, Supermicro, Finisar, and Avago. This ensures deployment flexibility and simplifies procurement for enterprise IT teams.

Summary of Advantages

High-Performance Networking

• Four 10 Gigabit Ethernet SFP+ ports
• Intel X710 controller with advanced offloads

Modular, Scalable Design

• SIOM form factor for seamless server integration
• Hot-swappable module for zero-downtime upgrades

Enterprise-Class Security and Virtualization Support

• SR-IOV, VMDq, and VXLAN offloads
• Secure boot and firmware protection

Flexible Cable and Transceiver Options

• Compatible with fiber and DAC connections
• Vendor-agnostic transceiver support
