57-1000117-01 Brocade 8GBPS SFP+ Transceiver Module.

Brocade 57-1000117-01 Multi-mode Fibre Channel Transceiver

The Brocade 57-1000117-01 8Gbps Multi-mode Fibre Channel SFP+ Transceiver Module represents a high-performance optical networking component designed for enterprise-grade storage area networks (SANs). This optical transceiver is engineered to deliver reliable, low-latency, and high-bandwidth data transmission across fibre channel environments where stability and speed are critical.

As organizations continue to scale their digital infrastructure, Fibre Channel remains a dominant protocol for storage networking due to its deterministic performance and resilience. This transceiver module is specifically optimized for short to medium-range connections using multi-mode fiber, making it ideal for intra-data center communication between switches, storage arrays, and host bus adapters.

Technical Architecture and Core Design Principles

Optical Transceiver Engineering Structure

The Brocade 57-1000117-01 module is built around a compact SFP+ form factor, enabling hot-swappable installation into compatible Fibre Channel switches and networking devices. The engineering design focuses on reducing signal loss while maintaining consistent optical modulation at 8Gbps. The module integrates both transmitter and receiver optics within a single enclosure, allowing full-duplex communication over a pair of multi-mode fiber strands.

At its core, the device converts electrical signals into optical signals using a laser diode transmitter, while a photodiode receiver performs the reverse conversion. This bidirectional optical conversion ensures high-speed communication with minimal latency and extremely low bit error rates, which is essential for storage-heavy workloads.

8Gbps Fibre Channel Performance Characteristics

Operating at 8 gigabits per second, this transceiver supports Fibre Channel Generation 5 standards. The 8Gbps rate allows efficient handling of large-scale storage replication, database synchronization, and virtualization traffic. The bandwidth efficiency is further enhanced by encoding mechanisms that reduce overhead while maintaining data integrity across long operational cycles.

The module is engineered to maintain signal stability across supported distances using multi-mode fiber cabling. Depending on fiber quality and network conditions, it can support reliable communication over short-reach links typically used within enterprise data center racks and adjacent switching fabrics.

Signal Integrity Optimization

Signal integrity is maintained through advanced equalization and error correction techniques embedded within compatible Brocade switching environments. These optimizations help reduce jitter, attenuation, and dispersion effects that commonly occur in high-speed optical transmissions. As a result, the module ensures stable communication even in densely populated switching fabrics.

Multi-mode Fiber Compatibility and Use Cases

Role of Multi-mode Fiber in Enterprise Networks

Multi-mode fiber is widely used in short-range data center environments due to its cost efficiency and ease of installation. The Brocade 57-1000117-01 module leverages this medium to provide high-throughput connectivity between storage arrays and Fibre Channel switches. Multi-mode fiber allows multiple light paths within the fiber core, making it suitable for high-speed, short-distance communication scenarios.

Short Reach Data Center Interconnectivity

In enterprise deployments, the module is commonly used to connect top-of-rack switches with storage arrays or to link SAN switches within the same data hall. This short-reach capability is essential for reducing latency between compute and storage layers, thereby improving application responsiveness and system throughput.

High-Density Rack Environments

Modern data centers are increasingly adopting high-density rack architectures. The compact SFP+ design of this transceiver allows multiple ports to be utilized simultaneously without excessive space consumption or thermal buildup. This ensures that administrators can scale connectivity without compromising physical infrastructure efficiency.

Enterprise Storage Networking Applications

Storage Area Network Optimization

Within Storage Area Networks, the Brocade 57-1000117-01 module plays a critical role in maintaining deterministic performance. SAN environments require predictable latency and guaranteed bandwidth, particularly for transactional databases, virtualization clusters, and enterprise resource planning systems. Fibre Channel technology provides a dedicated transport layer that isolates storage traffic from general network congestion.

By deploying this transceiver, organizations can achieve optimized data flows between servers and storage arrays, ensuring that input/output operations remain consistent even under peak workloads.

Virtualization and Cloud Infrastructure Integration

Virtualized environments depend heavily on fast and reliable storage access. Hypervisors such as VMware, Hyper-V, and KVM rely on underlying Fibre Channel fabrics to deliver storage to virtual machines without bottlenecks. The 8Gbps capability of this module ensures that multiple virtual machines can access shared storage resources simultaneously without performance degradation.

Scalability in Hybrid Cloud Systems

Hybrid cloud infrastructures often integrate on-premises SANs with cloud-based storage systems. The Brocade transceiver enables seamless data movement within on-premises environments, supporting replication, backup, and migration operations that bridge local data centers and cloud platforms.

Hardware Compatibility and Integration Ecosystem

Brocade Switch Compatibility Framework

This transceiver is designed to integrate seamlessly with compatible Brocade Fibre Channel switches. The hardware compatibility ensures plug-and-play functionality, reducing configuration complexity during deployment. When installed in supported switches, the module is automatically recognized and configured according to network policies.

Compatibility extends across a wide range of enterprise-grade SAN switches, enabling organizations to maintain consistent hardware standards across their infrastructure. This reduces maintenance overhead and simplifies inventory management.

Interoperability with Storage Arrays

The module is also widely compatible with major storage array vendors. This interoperability ensures that enterprises can build heterogeneous storage environments without sacrificing performance or reliability. Fibre Channel standards guarantee that communication remains stable across different vendor ecosystems.

Firmware and Protocol Synchronization

Firmware synchronization between switches and transceivers ensures optimal performance. The Brocade ecosystem supports automatic tuning of optical parameters to match network conditions, reducing manual intervention and improving operational efficiency.

Reliability, Durability, and Environmental Stability

Industrial-Grade Operational Standards

The Brocade 57-1000117-01 module is engineered to operate under strict environmental conditions typical of enterprise data centers. It maintains performance stability across a range of temperatures, humidity levels, and airflow conditions. This durability is essential for 24/7 mission-critical operations where downtime is not acceptable.

Thermal Efficiency and Power Consumption

One of the key advantages of SFP+ optical modules is their low power consumption. This transceiver is designed to minimize heat output while maintaining full 8Gbps performance. Lower thermal output contributes to improved rack density and reduces the burden on cooling systems within data centers.

Heat Dissipation Mechanisms

Efficient internal design allows heat to be distributed evenly across the module housing. This prevents localized thermal stress and ensures consistent optical performance even during sustained high-throughput operations.

Deployment Scenarios and Network Architecture Design

Core-Aggregation Storage Topologies

In core-aggregation network designs, the transceiver facilitates high-speed communication between core SAN switches and aggregation layers. This architecture supports scalable storage growth while maintaining consistent performance across the network fabric.

Redundant Fabric Design Implementation

Redundancy is a key principle in enterprise Fibre Channel networks. By deploying multiple instances of this transceiver across redundant paths, organizations can ensure continuous availability even in the event of link failure. Redundant fabric designs eliminate single points of failure and enhance disaster recovery capabilities.

Load Balancing Across Fibre Channel Paths

Load balancing mechanisms distribute storage traffic across multiple active links, improving bandwidth utilization and reducing congestion. The consistent performance of 8Gbps links ensures predictable traffic distribution across the fabric.

Economic and Operational Value in Enterprise IT

Cost Efficiency in Storage Networking

The Brocade 57-1000117-01 module offers a cost-effective solution for organizations seeking to maintain high-performance Fibre Channel networks without excessive infrastructure investment. Multi-mode fiber cabling reduces installation costs compared to long-haul single-mode alternatives, while still delivering sufficient performance for intra-data center connectivity.

Return on Investment in SAN Infrastructure

Investing in reliable transceiver modules contributes directly to improved system uptime and application performance. Reduced latency and stable throughput translate into higher productivity and lower operational risk for enterprise systems.

Long-Term Infrastructure Scalability

Scalability is a key advantage of Fibre Channel architectures. As storage demands increase, additional transceivers can be deployed without redesigning the entire network fabric. This modular approach ensures long-term infrastructure adaptability.

Future Relevance of 8Gbps Fibre Channel Modules

Continued Role in Legacy and Hybrid Systems

Although higher-speed Fibre Channel standards such as 16Gbps and 32Gbps have emerged, 8Gbps modules remain widely deployed in legacy systems and hybrid infrastructures. Many organizations continue to rely on these modules due to their stability, compatibility, and cost efficiency.

Integration with Modern Data Center Evolution

As data centers evolve toward software-defined storage and hyper-converged infrastructure, traditional Fibre Channel components still play a foundational role. The Brocade 57-1000117-01 module remains relevant in environments where deterministic performance and dedicated storage networking are required.

Interoperability with Next-Generation Storage Systems

Modern storage systems often integrate multiple networking protocols. Fibre Channel modules like this one continue to provide reliable backbone connectivity, ensuring that performance-critical workloads maintain dedicated transport channels.
