RSP720-3CXL-GE Cisco 7600 10 Gigabit Switch Processor

Overview of Cisco RSP720-3CXL-GE 10 Gigabit Switch Processor

The Cisco RSP720-3CXL-GE is a robust routing engine engineered to deliver exceptional throughput and scalability for demanding network infrastructures. Designed for enterprise-grade deployments, this processor enhances routing efficiency while maintaining consistent performance across complex environments.

Manufacturer Information

• Manufacturer: Cisco
• Part Number: RSP720-3CXL-GE
• Product Type: Router Switch Processor

Technical Specification

• Router Type: 10 Gigabit Ethernet
• Data Transfer Speeds: 10 Mbps (Ethernet), 100 Mbps (Fast Ethernet), 1 Gbps (Gigabit Ethernet)
• Connectivity Type: Twisted Pair 10/100/1000Base-T
• Expansion Capability: 2 x CompactFlash Card Slots
• Daughter Card Support: Includes PFC-3CXL module

Interfaces and Ports

• 1 x 10/100/1000Base-T Uplink Port
• 1 x RJ-45 10/100/1000Base-T Shared Uplink
• 1 x Console Management Interface
• Application: Suitable for Wide Area Network (WAN)

I/O Expansion Slots

• 1 x SFP (mini-GBIC) Free Slot
• 1 x SFP (mini-GBIC) Shared Slot
• 2 x CompactFlash Card Slots for Additional Expansion

Environmental Specifications

• Operating Temperature Range: 32 to 104°F (0 to 40°C)
• Storage Temperature Range: -40 to 167°F (-40 to 75°C)
• Humidity Tolerance: 10% to 90% (non-condensing)

Regulatory Compliance for Safety

• UL 60950
• EN 60950
• IEC 60950
• AS/NZS 3260
• IEC 60825-1, -2
• 21CFR1040-10
• TS001

Electromagnetic Compliance (EMC)

• FCC Part 15 (CFR 47) Class A
• ICES-003 Class A
• EN 55022 Class A
• CISPR 22 Class A
• AS/NZS 3548 Class A
• VCCI Class A
• EN55024

Emission Standards

• 47 CFR Part 15: 2005
• CISPR22: 2005
• EN300386: V1.3.3: 2005

Immunity and Safety Features

• EN50082-1: 1992
• EN55024: 1998
• EN61000-6-1: 2001

Reliability and Availability

• Fast Software Upgrade (FSU)
• Route Processor Redundancy+ (RPR+)
• Stateful Switchover with Nonstop Forwarding (SSO + NSF)
• Online Insertion and Removal (OIR) for Hot-Swap

Advanced Management and Protocols

• Supports Quality of Service (QoS) Enhancements
• Layer 3 Routing Protocols: BGPv4, OSPF, IS-IS, RIP
• Distributed FIB Switching
• Supports Multicast Forwarding with Protocol Independent Multicast (PIM)

MPLS and Multicast Support

• Comprehensive MPLS Support
• Multicast Forwarding in both Sparse and Dense Modes

Compatibility and Cisco IOS Software

• Compatible with Cisco IOS® Software Release 12.2.33SRB

Outline of Cisco 7600 Series Router Switch Processor

The Cisco RSP720-3CXL-GE for the 7600 Series represents a high-performance routing and switching processor engineered to deliver exceptional throughput, scalability, and reliability for enterprise and service provider environments. Built to support advanced networking requirements, this processor integrates powerful hardware acceleration, enabling data forwarding at speeds up to 720Gbps. It is designed to handle complex routing tables, high traffic volumes, and demanding applications while maintaining consistent performance and low latency across large-scale networks.

Advanced Processing Capabilities and Performance Optimization

The RSP720-3CXL-GE module is equipped with enhanced CPU performance and optimized memory allocation, ensuring efficient packet processing even under heavy network loads. Its architecture allows for seamless handling of IPv4 and IPv6 traffic, enabling organizations to transition to modern networking protocols without compromising performance. The processor’s ability to support large routing tables makes it ideal for core and edge deployments where high scalability is essential.

Enhanced Throughput for High-Density Networks

With a forwarding capacity of up to 720Gbps, this processor supports high-density network environments that require rapid data transmission across multiple interfaces. The architecture is optimized for parallel processing, allowing simultaneous handling of multiple data streams. This ensures minimal packet loss and consistent throughput even during peak usage periods.

Efficient Traffic Management and Load Distribution

The processor incorporates intelligent traffic management features that optimize load distribution across network paths. This ensures balanced utilization of resources, reducing congestion and improving overall network efficiency. The integration of advanced queuing mechanisms allows for prioritization of critical traffic, ensuring that essential services maintain high performance levels.

Scalability and Flexibility in Enterprise and Service Provider Networks

The Cisco RSP720-3CXL-GE is designed with scalability in mind, allowing organizations to expand their network infrastructure without significant hardware changes. Its compatibility with the Cisco 7600 Series platform ensures seamless integration with existing systems, enabling incremental upgrades and cost-effective network expansion.

Support for Large Routing Tables and Complex Configurations

This processor is capable of handling extensive routing tables, making it suitable for environments with complex network topologies. Its ability to manage multiple routing protocols simultaneously ensures flexibility in network design and deployment. The processor supports dynamic routing updates, enabling networks to adapt quickly to changes in topology or traffic patterns.

Modular Design for Easy Expansion

The modular nature of the Cisco 7600 Series allows the RSP720-3CXL-GE to be deployed in a variety of configurations. This flexibility enables organizations to scale their networks according to evolving requirements. The processor can be integrated with various line cards and modules, providing a versatile solution for diverse networking needs.

Future-Ready Networking Infrastructure

The design of this processor ensures compatibility with future networking technologies, allowing organizations to invest in infrastructure that remains relevant over time. Its support for advanced protocols and features ensures readiness for next-generation applications and services.

High Availability and Redundancy Features

Reliability is a critical factor in network infrastructure, and the Cisco RSP720-3CXL-GE is engineered to provide high availability through robust redundancy mechanisms. These features ensure continuous operation and minimize downtime, making it suitable for mission-critical applications.

Redundant Supervisor Engine Support

The processor supports redundant configurations, allowing multiple supervisor engines to operate simultaneously. This ensures that if one processor fails, another can take over without disrupting network operations. This redundancy is essential for maintaining uptime in environments where network availability is crucial.

Stateful Switchover and Nonstop Forwarding

Stateful switchover and nonstop forwarding capabilities enable seamless transition between active and standby processors. This ensures that network traffic continues to flow uninterrupted during failover events. These features are particularly important in environments where even brief interruptions can have significant impacts.

Resilient System Design

The overall design of the processor incorporates multiple layers of fault tolerance, ensuring reliable operation even under adverse conditions. This includes hardware redundancy, software stability, and robust error-handling mechanisms.

Comprehensive Security and Network Protection

Security is a fundamental aspect of modern networking, and the Cisco RSP720-3CXL-GE includes a range of features designed to protect network infrastructure from threats. These capabilities ensure secure data transmission and safeguard critical resources.

Advanced Access Control and Filtering

The processor supports sophisticated access control mechanisms that allow administrators to define granular security policies. These policies enable filtering of traffic based on various criteria, ensuring that only authorized data is allowed to pass through the network.

Integrated Threat Mitigation Features

Built-in security features provide protection against common network threats, including denial-of-service attacks and unauthorized access attempts. These capabilities enhance the overall security posture of the network, reducing the risk of disruptions and data breaches.

Secure Management and Monitoring

The processor includes secure management interfaces that allow administrators to monitor and control network operations. These interfaces support encryption and authentication mechanisms, ensuring that management activities are protected from unauthorized access.

Support for Advanced Networking Features and Protocols

The Cisco RSP720-3CXL-GE is designed to support a wide range of networking features and protocols, enabling organizations to deploy sophisticated network architectures. These capabilities ensure flexibility and adaptability in diverse environments.

Multiprotocol Label Switching and Traffic Engineering

The processor supports Multiprotocol Label Switching, enabling efficient routing and traffic engineering. This allows organizations to optimize network performance and ensure reliable delivery of data across complex networks.

Quality of Service and Traffic Prioritization

Quality of Service features enable prioritization of critical traffic, ensuring that important applications receive the necessary bandwidth and performance. This is particularly important in environments with diverse traffic types and varying performance requirements.

IPv6 and Dual-Stack Support

The processor supports IPv6, allowing organizations to transition to modern addressing schemes while maintaining compatibility with existing IPv4 networks. Dual-stack capabilities ensure seamless operation during the transition period.

Integration with Cisco 7600 Series Platform

The RSP720-3CXL-GE is specifically designed for the Cisco 7600 Series, providing seamless integration and optimized performance within this platform. This compatibility ensures that organizations can leverage existing infrastructure while enhancing network capabilities.

Compatibility with Line Cards and Modules

The processor works with a wide range of line cards and modules, enabling flexible network configurations. This compatibility allows organizations to tailor their network infrastructure to meet specific requirements.

Centralized Management and Control

The processor provides centralized control of network operations, simplifying management and reducing complexity. This enables administrators to monitor performance, configure settings, and troubleshoot issues from a single interface.

Optimized System Performance

The integration of the processor with the Cisco 7600 Series ensures optimized system performance, allowing all components to work together efficiently. This results in improved reliability and enhanced network capabilities.
