ASR-9006-AC Cisco Router Chassis - 6 Slots - Redundant Power Supply

Product Overview of the Cisco ASR-9006-AC Services Router

The Cisco ASR-9006-AC is a high-performance aggregation services router chassis designed for enterprise and carrier networks. With a six-slot configuration, it offers exceptional flexibility and scalability for diverse network demands.

General Information

• Manufacturer: Cisco
• Series: 9000 Series
• Model: 9006
• Product Type: Router Chassis
• Part Number/SKU: ASR-9006-AC
• Device Name: Cisco ASR-9006-AC 9006 Aggregation Services Router Chassis
• Expansion Capacity: 6 slots for versatile deployment

Expansive I/O & Modular

• Six fully accessible expansion slots supporting both line cards and route processors
• Flexible modular architecture allows easy upgrades and network scalability
• Optimized design to accommodate future growth and evolving connectivity demands
• Enhanced performance with balanced slot allocation for high-throughput operations

Power Efficiency

• Input Voltage: 220V AC suitable for standard enterprise environments
• Equipped with reliable Power Supply Units (PSU) for consistent operation
• Redundant power modules prevent downtime and maintain continuous service
• Optimized energy consumption for cost-effective deployment

Compatibility

• Seamless integration with Cisco 9000 Series line cards and modules
• Supports multiple Cisco Route Processors for flexible network design
• Works with Cisco IOS-XR software for advanced routing and management
• Compatible with existing enterprise-grade network infrastructure
• Interoperable with other Cisco ASR family devices for network expansion

The Cisco ASR-9006-AC 9006 Aggregation Services Router

The Cisco ASR-9006-AC 9006 Aggregation Services Router Chassis is designed to deliver high-performance routing and reliable network aggregation capabilities for enterprise and service provider environments. Built with six modular slots, the chassis supports scalable network growth while providing robust redundancy features to ensure uninterrupted network services. Ideal for large-scale deployments, the ASR-9006-AC is engineered to handle demanding traffic loads, offering high availability, advanced security features, and simplified network management.

Scalable Slot Architecture for Flexible Deployment

The six-slot design of the Cisco ASR-9006-AC allows network engineers to install various line cards, service modules, and interface cards to meet evolving network requirements. Each slot supports multiple types of modules, including 10GbE, 40GbE, and 100GbE line cards, providing versatility for data center interconnects, core routing, and metro aggregation. The modular architecture ensures that the network can expand without a complete chassis replacement, reducing operational costs and simplifying upgrades.

Redundant Power Supply for Enhanced Reliability

The ASR-9006-AC chassis includes a dual, redundant power supply system to ensure continuous operation even in the event of a component failure. This feature is critical for mission-critical applications and environments where network downtime is not acceptable. The redundant power design allows for hot-swapping of power modules, minimizing service interruptions and maintaining network uptime. Additionally, the chassis supports load balancing across power supplies to optimize energy efficiency.

High-Performance Packet Processing

Equipped with Cisco’s advanced hardware and software architecture, the ASR-9006-AC offers high-speed packet forwarding, low-latency routing, and advanced QoS (Quality of Service) capabilities. The chassis leverages the Cisco QuantumFlow Processor, enabling efficient handling of multiple routing protocols and high-density interfaces. Network administrators can deploy complex traffic policies and prioritize critical applications, ensuring optimal performance for voice, video, and data traffic.

Advanced Networking Features

The Cisco ASR-9006-AC chassis supports a wide array of networking protocols and features that enhance network functionality. These include MPLS (Multiprotocol Label Switching), VPN support, IPv6 readiness, and advanced multicast routing. MPLS capabilities allow service providers to implement scalable Layer 3 VPNs, while IPv6 support ensures future-proof network deployments. Advanced multicast features facilitate efficient delivery of video and streaming content to multiple endpoints.

Security and Compliance

Security is a core component of the ASR-9006-AC platform. The chassis supports hardware-based encryption, firewall services, and secure control plane functions. Integrated security features enable organizations to protect sensitive data, enforce compliance standards, and prevent unauthorized network access. Role-based access control (RBAC) allows network administrators to manage permissions effectively, reducing the risk of internal security breaches.

Cisco ASR-9006-AC Line Cards and Modules

The ASR-9006-AC chassis supports a diverse portfolio of line cards and service modules. Network operators can choose from high-speed Ethernet, MPLS, and WAN interface cards to tailor the chassis to specific traffic requirements. Each module is designed for plug-and-play installation, allowing for quick upgrades and expansions without downtime. The modularity also facilitates testing of new technologies and scaling for increasing bandwidth demands.

High-Density Interface Modules

High-density interface modules for the ASR-9006-AC provide maximum port density for Ethernet, T1/E1, or WAN interfaces. These modules support high-performance routing, advanced QoS, and packet filtering, enabling organizations to optimize network performance for both enterprise and service provider environments. The flexibility in module selection ensures that the ASR-9006-AC can accommodate diverse network topologies and traffic patterns.

Service Modules for Enhanced Functionality

Service modules add specialized functions to the ASR-9006-AC, such as deep packet inspection, firewall services, and encryption. These modules allow operators to implement security policies, traffic shaping, and policy-based routing directly within the chassis, reducing the need for external appliances. Integration of service modules improves operational efficiency and simplifies network architecture.

Cisco ASR-9006-AC Software and Licensing

The ASR-9006-AC chassis operates using Cisco IOS XR software, a robust operating system that supports high availability, advanced routing protocols, and automation. Licensing options allow network administrators to unlock additional features as needed, such as advanced MPLS, VPN services, and IPv6 support. Cisco’s software licensing model ensures that organizations can scale features without hardware replacement, providing cost-effective network growth.

Security Licensing and Compliance Features

Additional software licenses for the ASR-9006-AC can enable enhanced security features, including IPsec VPN, MACsec encryption, and advanced firewall functions. These licenses allow organizations to meet regulatory compliance requirements while protecting sensitive data across WAN, LAN, and data center networks. By combining hardware redundancy with software security features, the ASR-9006-AC ensures a comprehensive approach to network resilience.

Cisco ASR-9006-AC Performance Optimization

Performance optimization for the ASR-9006-AC chassis involves leveraging hardware and software capabilities to maximize throughput and minimize latency. Features such as traffic shaping, load balancing, and QoS prioritization ensure that critical applications receive the necessary bandwidth while non-critical traffic is managed efficiently. Administrators can also monitor performance metrics in real-time, allowing proactive network tuning and predictive maintenance.

Redundancy and Failover Strategies

The chassis supports multiple redundancy mechanisms, including dual control planes, redundant power supplies, and failover line cards. These strategies ensure uninterrupted network service even during hardware or software failures. Network operators can implement proactive failover tests to validate redundancy and minimize the impact of unplanned outages on mission-critical services.

Cisco ASR-9006-AC Data Center and Enterprise Use Cases

The ASR-9006-AC chassis is widely deployed in enterprise campuses, large data centers, and service provider networks. In data centers, it functions as a high-performance core router, enabling interconnectivity between multiple racks, server clusters, and storage systems. Enterprises utilize the chassis for campus aggregation, connecting branch offices with high-speed WAN links and secure VPNs. Its scalability and reliability make it suitable for cloud providers, telecommunications carriers, and large-scale enterprise networks.

Enterprise Network Aggregation

In enterprise environments, the ASR-9006-AC consolidates traffic from multiple access switches and branch offices, providing centralized routing and policy enforcement. It supports advanced QoS, multicast optimization, and VPN services to ensure consistent user experience across locations. Redundant power and fan systems further enhance uptime, making it ideal for mission-critical business operations.

Service Provider Core and Edge Routing

For service providers, the ASR-9006-AC serves as both core and edge routing infrastructure. Its high throughput, modularity, and advanced MPLS capabilities allow for scalable delivery of IP services, voice, and video. Redundant architecture ensures uninterrupted service for thousands of customers, and integration with Cisco Network Services Orchestrator enables rapid provisioning and configuration of network services.
