C887VAGW+7-E-K9 Cisco ISR Integrated Services Router

Overview Cisco C887VAGW+7-E-K9 Integrated Services Router

The Cisco C887VAGW+7-E-K9 router is a powerful integrated services solution designed for enterprises and branch offices that require secure, flexible, and high-speed connectivity. With advanced wireless capabilities, dual-band Wi-Fi, and robust security features, it ensures reliable performance for modern business environments.

General Information

• Manufacturer: Cisco
• Part Number: C887VAGW+7-E-K9
• Product Type: Integrated Services Router

Technical Information

Core Connectivity

• DSL WAN: Multimode VDSL2 and ADSL2/2+ over POTS (Plain Old Telephone Service)
• Wireless WAN (3.7G): Embedded HSPA+ Release 7 modem with speeds up to 21.1 Mbps downlink and 5.76 Mbps uplink
• Wi-Fi Access Point: Dual-radio/dual-band 802.11a/b/g/n supporting both 2.4 GHz and 5 GHz frequencies
• Wired LAN: 4-port 10/100 Mbps managed Fast Ethernet switch

Special Features & Interfaces

MIMO Technology

• 2x3 Multiple-Input, Multiple-Output (MIMO) for enhanced Wi-Fi throughput and reliability

Advanced Cellular Tools

• Standalone GPS support
• Native SMS gateway for sending and receiving messages
• Dual SIM card slots for cellular failover

Additional Interfaces

• PoE Support: Two LAN ports with Power over Ethernet capability for IP phones or external access points
• Expansion Slots: 2 x mini-SIM (2FF) slots for reliable cellular connectivity

Security & Performance

Security Suite

• Zone-Based Firewall (ZBFW)
• Intrusion Prevention System (IPS)
• Content filtering for enhanced protection

VPN Capabilities

Encryption Standards

• DES
• 3DES
• AES (128/192/256-bit)

VPN Support

• Hardware-accelerated support for up to 20 IPsec tunnels

Management Tools

• CLI via Console port
• SNMP monitoring
• Web-based Cisco Configuration Professional

Physical Specifications

Enclosure

• Desktop, fanless design for quiet operation

Dimensions

• Height: 1.9 inches (48 mm)
• Width: 12.8 inches (325 mm)
• Depth: 10.4 inches (264 mm)

Weight

• Approximately 5.6 lbs (2.54 kg)

Power

• 60W external power adapter
• Input: 100–240 VAC

Cisco C887VAGW+7-E-K9 Integrated Services Router

The Cisco C887VAGW+7-E-K9 Integrated Services Router represents a highly versatile and compact networking solution designed to meet the evolving requirements of small to medium-sized businesses and branch offices. Built on a robust architectural foundation, this router integrates advanced security, wireless connectivity, and WAN access technologies into a single platform. The system is engineered to simplify network deployment while ensuring enterprise-grade performance, reliability, and scalability across diverse environments.

At its core, the router incorporates integrated VDSL2 and ADSL2+ capabilities, allowing seamless connectivity over existing copper infrastructure. This dual compatibility ensures organizations can leverage high-speed broadband access regardless of regional infrastructure limitations. The integrated wireless access point supports IEEE 802.11n standards, delivering consistent wireless performance suitable for modern office applications, including VoIP, video conferencing, and cloud-based workloads.

The compact form factor does not compromise on capability, as the router includes multiple Gigabit Ethernet ports, advanced routing protocols, and hardware-based encryption. These features collectively enable businesses to maintain secure and efficient network operations without requiring additional hardware components. The architecture supports modular expansion and flexible deployment scenarios, making it an ideal choice for organizations seeking cost-effective yet powerful networking solutions.

Integrated WAN and Broadband Connectivity

The Cisco C887VAGW+7-E-K9 router is equipped with integrated WAN interfaces that support both VDSL2 and ADSL2+ technologies. This dual-mode functionality ensures compatibility with various service providers and network infrastructures. The router dynamically adapts to available broadband technologies, enabling smooth transitions between different connection types without requiring hardware replacement.

Advanced traffic management capabilities enhance WAN performance by optimizing bandwidth utilization and prioritizing critical applications. Quality of Service mechanisms ensure latency-sensitive traffic such as voice and video is delivered efficiently, even under high network load conditions. This capability is essential for maintaining productivity and communication quality in modern business environments.

Wireless Connectivity and Coverage

The integrated wireless access point offers reliable connectivity using 802.11n technology, providing sufficient throughput for typical business operations. It supports multiple SSIDs, enabling segmentation of network traffic for different user groups or applications. This segmentation enhances both performance and security, allowing administrators to isolate guest networks from internal resources.

Wireless security protocols, including WPA2 encryption and advanced authentication methods, protect data transmitted over the air. The router also supports centralized management features, enabling IT teams to monitor and control wireless performance efficiently. This ensures consistent coverage and minimizes interference within office environments.

Advanced Security Capabilities for Enterprise Protection

Security is a fundamental aspect of the Cisco C887VAGW+7-E-K9 Integrated Services Router. The device incorporates multiple layers of protection to safeguard network infrastructure against evolving cyber threats. Built-in firewall capabilities provide stateful packet inspection, ensuring only legitimate traffic is allowed to pass through the network perimeter.

Integrated VPN support enables secure remote access and site-to-site connectivity. Organizations can establish encrypted tunnels using IPsec and SSL technologies, ensuring sensitive data remains protected during transmission. This feature is particularly valuable for businesses with distributed workforces or multiple branch locations.

Firewall and Intrusion Prevention

The router includes a robust firewall system designed to monitor and control incoming and outgoing network traffic based on predefined security rules. It supports advanced filtering mechanisms, enabling administrators to define granular access policies that align with organizational requirements. Intrusion prevention capabilities further enhance security by detecting and mitigating potential threats in real time.

These security features operate without significantly impacting network performance, thanks to hardware acceleration and optimized processing. This ensures that businesses can maintain high levels of protection without sacrificing speed or reliability.

VPN and Secure Remote Access

Virtual Private Network functionality allows organizations to extend their network securely across remote locations. Employees can access corporate resources from remote environments without compromising data integrity. The router supports multiple VPN protocols, providing flexibility in deployment and compatibility with various client devices.

Encryption algorithms ensure that all transmitted data remains confidential and protected from unauthorized access. This capability is essential for maintaining compliance with data protection regulations and industry standards.

Performance Optimization and Routing Efficiency

The Cisco C887VAGW+7-E-K9 router is designed to deliver consistent performance across a wide range of networking scenarios. Its advanced routing engine supports multiple protocols, enabling efficient data transmission across complex network topologies. The device is capable of handling high volumes of traffic while maintaining low latency and minimal packet loss.

Dynamic routing protocols such as OSPF and EIGRP allow the router to adapt to changing network conditions automatically. This ensures optimal path selection and enhances overall network resilience. The router also supports static routing configurations for simpler deployments, providing flexibility based on organizational needs.

Quality of Service Implementation

Quality of Service features play a critical role in managing network traffic and ensuring optimal performance for critical applications. The router prioritizes traffic based on predefined policies, ensuring that high-priority data such as voice and video is transmitted without delay. This capability enhances user experience and supports business-critical operations.

Traffic shaping and bandwidth allocation mechanisms further improve network efficiency by preventing congestion and ensuring fair distribution of resources. These features are particularly important in environments with limited bandwidth or high demand for network resources.

Hardware Acceleration and Throughput

The integration of hardware-based acceleration technologies enables the router to process data more efficiently. Encryption, routing, and packet inspection tasks are handled by dedicated components, reducing the load on the main processor. This results in improved throughput and consistent performance even under heavy network usage.

The router’s architecture ensures scalability, allowing businesses to accommodate growing network demands without requiring significant infrastructure changes. This makes it a future-proof solution for organizations planning long-term expansion.

Scalability

The Cisco C887VAGW+7-E-K9 Integrated Services Router is designed with scalability in mind, enabling organizations to expand their network infrastructure as needed. Its modular design and flexible configuration options allow it to adapt to a variety of deployment scenarios, from small offices to distributed enterprise environments.

The router supports multiple connectivity options, including wired and wireless interfaces, ensuring compatibility with diverse network architectures. This flexibility simplifies deployment and reduces the need for additional hardware components.

Branch Office Deployment

In branch office environments, the router serves as a comprehensive networking solution, combining routing, security, and wireless connectivity into a single device. This reduces complexity and simplifies management, allowing IT teams to focus on strategic initiatives rather than routine maintenance tasks.

The integrated features eliminate the need for separate devices, reducing both capital and operational expenses. This makes the router an attractive option for organizations seeking cost-effective networking solutions.

Application Support

The Cisco C887VAGW+7-E-K9 Integrated Services Router is designed to support a wide range of applications, making it suitable for various industry use cases. Its integrated features and robust performance capabilities enable organizations to deploy it in diverse environments, from retail and healthcare to education and finance.

The router’s ability to handle voice, video, and data traffic simultaneously makes it an ideal solution for unified communications. It ensures high-quality transmission of multimedia content, supporting collaboration and productivity across teams.

Unified Communications Integration

Support for voice and video applications allows the router to serve as a central component in unified communications systems. It ensures reliable transmission of real-time data, minimizing latency and jitter. This capability is essential for maintaining clear and uninterrupted communication between users.

The router also supports advanced features such as call prioritization and traffic segmentation, enhancing the overall quality of communication services.

Cloud and SaaS Application Performance

As businesses increasingly rely on cloud-based applications, the router’s performance optimization features play a crucial role in ensuring seamless access to these services. It prioritizes cloud traffic and optimizes routing paths, reducing latency and improving user experience.

The integration of security features ensures that data transmitted to and from cloud platforms remains protected, enabling organizations to leverage cloud technologies with confidence.

Power Optimization Technologies

Advanced power management features enable the router to adjust energy consumption based on network activity. This ensures optimal performance while minimizing unnecessary power usage. These capabilities are particularly beneficial for organizations seeking to reduce energy costs and meet sustainability goals.

The router’s efficient design ensures that it delivers consistent performance without excessive power consumption, making it an environmentally responsible choice.
