9GCCD Dell E40GQSFPSR QSFP+ 40GBPS Transceiver Module

Dell 9GCCD QSFP+ 40Gbps Transceiver Module Overview

The Dell 9GCCD Multi-mode Intel E40GQSFPSR QSFP+ transceiver module is a high-speed networking component engineered to support modern data center and enterprise networking environments. Designed for superior performance and reliability, this optical module delivers 40 Gigabit Ethernet connectivity over multi-mode fiber, ensuring fast and stable data transmission for bandwidth-intensive applications.

Product Information

• Manufacturer: Dell
• Part Number: 9GCCD
• Device Type: Optical Transceiver Module
• Form Factor: Plug-in QSFP+

Advanced Data Link Capabilities

• Supports 40 Gigabit Ethernet protocol
• Ensures consistent high-bandwidth connectivity
• Optimized for scalable network architectures

Optical Performance Specifications

• Wavelength: 850 nm
• Cabling Type: 40GBase-SR4
• Maximum Distance: Up to 490 feet

Benefits of Multi-Mode Technology

• Lower deployment costs compared to single-mode fiber
• Ideal for short-distance, high-speed connections
• Simplified installation and maintenance

Form Factor Advantages

• Quick and hassle-free deployment
• Supports high port density in switches and routers
• Efficient space utilization in network hardware

Networking Features

• Wired connectivity for consistent performance
• Compatible with 40GBase-SR4 network standards
• Designed for seamless integration with Dell networking equipment

Compliance Highlights

• Meets IEEE 802.3ba specifications
• Ensures industry-standard performance
• Supports multi-vendor network environments

Interface Details

• 1 x Ethernet 40GBase-SR4 interface
• MPO multi-mode connector
• Designed for high-density fiber connections

Scalability Benefits

• Supports growing network demands
• Enables efficient bandwidth scaling
• Ideal for modular network expansion

Use Case Scenarios

• High-speed server-to-switch connectivity
• Data center interconnects
• Enterprise network backbone deployments

Dell 9GCCD QSFP+ 40Gbps Transceiver Module Overview

The Dell 9GCCD Multi-mode Intel E40GQSFPSR QSFP+ 40Gbps transceiver module represents a high-performance optical networking solution engineered for enterprise-grade data communication environments. Designed to support 40 Gigabit Ethernet connectivity, this QSFP+ transceiver delivers reliable, high-speed data transfer over multimode fiber infrastructure. Its advanced optical design ensures consistent signal integrity, reduced latency, and optimized throughput across short-range data center and enterprise networking deployments.

This category of QSFP+ transceivers is specifically tailored to meet the growing demand for high-bandwidth applications such as virtualization, cloud computing, big data analytics, and high-performance computing clusters. The Dell 9GCCD module leverages Intel compatibility to provide seamless integration with supported networking hardware, ensuring dependable operation in mission-critical environments.

Technical Specifications and Optical Performance

40Gbps Data Transmission Capabilities

The Dell 9GCCD QSFP+ module is built to deliver a full-duplex data transmission rate of up to 40Gbps. This high-speed capability allows organizations to handle large volumes of data traffic efficiently, reducing bottlenecks in network infrastructure. The module uses parallel optical technology, enabling simultaneous transmission across multiple channels for enhanced bandwidth performance.

Multi-mode Fiber Compatibility

Optimized for multi-mode fiber (MMF), the transceiver supports OM3 and OM4 fiber standards, providing flexibility for existing cabling infrastructures. Multi-mode fiber compatibility ensures cost-effective deployment while maintaining high-speed connectivity for short-distance applications such as within data centers or campus networks.

Short-Range Transmission Distance

The module typically supports transmission distances of up to 100 meters over OM3 fiber and up to 150 meters over OM4 fiber. This makes it ideal for rack-to-rack, row-to-row, and switch-to-switch connections within confined networking environments.

850nm Wavelength Technology

Operating at an 850nm wavelength, the Dell 9GCCD transceiver utilizes Vertical Cavity Surface Emitting Laser (VCSEL) technology. This ensures efficient optical signal generation, lower power consumption, and consistent performance across supported distances.

QSFP+ Form Factor Advantages

Compact Design for High-Density Networking

The QSFP+ (Quad Small Form-factor Pluggable Plus) design allows for increased port density on networking devices. Compared to traditional SFP+ modules, QSFP+ provides four channels of data transmission within a single compact form factor, maximizing space utilization in switches and routers.

Hot-Swappable Functionality

The Dell 9GCCD module supports hot-swappable installation, enabling network administrators to replace or upgrade transceivers without powering down the system. This minimizes downtime and enhances operational efficiency in enterprise environments.

Ease of Maintenance

Hot-swappable capability simplifies maintenance tasks, allowing IT teams to quickly address connectivity issues or perform upgrades without disrupting network operations.

Scalable Network Expansion

With plug-and-play functionality, organizations can easily scale their network infrastructure by adding additional QSFP+ modules as bandwidth demands increase.

Intel Compatibility and Integration

Seamless Interoperability with Intel-Based Systems

The Dell 9GCCD transceiver is engineered for compatibility with Intel E40GQSFPSR standards, ensuring seamless integration with Intel-based network interface cards and switches. This compatibility guarantees reliable communication between hardware components, reducing the risk of connectivity issues.

Optimized Firmware and Performance Tuning

Intel-compatible modules benefit from optimized firmware configurations that enhance performance, stability, and interoperability. This ensures that the transceiver operates efficiently within supported environments.

Vendor-Specific Coding

The module includes vendor-specific EEPROM coding that enables recognition by compatible devices, ensuring proper functionality and preventing compatibility errors.

Reliable Data Transmission

Integration with Intel systems ensures consistent data transmission with minimal packet loss, making the module suitable for high-performance computing and data-intensive applications.

Application Scenarios and Use Cases

Data Center Networking

The Dell 9GCCD QSFP+ transceiver is widely used in data center environments where high-speed connectivity is essential. It supports server-to-switch and switch-to-switch connections, enabling efficient data flow across the network infrastructure.

Enterprise Network

In enterprise settings, the module serves as a backbone connectivity solution, linking core switches and aggregation layers. Its 40Gbps capability ensures smooth operation of business-critical applications.

Cloud Computing Infrastructure

Cloud service providers rely on high-bandwidth transceivers to manage large-scale data processing and storage. The Dell 9GCCD module supports the high-speed requirements of cloud environments.

High-Performance Computing

HPC environments require low-latency, high-throughput networking solutions. The QSFP+ module delivers the performance needed for complex computational tasks.

Virtualization and Storage Networks

The module supports virtualization platforms and storage area networks (SANs), ensuring efficient data transfer between virtual machines and storage systems.

Energy Efficiency and Thermal Management

Low Power Consumption

The Dell 9GCCD QSFP+ transceiver is designed with energy efficiency in mind, consuming significantly less power compared to older optical modules. This reduces operational costs and supports environmentally sustainable data center practices.

Advanced Heat Dissipation

Efficient thermal management ensures that the module operates within safe temperature ranges, preventing overheating and maintaining consistent performance.

Enhanced Reliability

Proper heat dissipation contributes to the longevity of the transceiver, reducing the risk of hardware failure and minimizing maintenance requirements.

Stable Operation in Dense Environments

The module is suitable for high-density networking setups where multiple transceivers operate in close proximity, ensuring stable performance without thermal interference.

Advantages of Choosing Dell 9GCCD QSFP+ Transceivers

High Bandwidth Efficiency

The 40Gbps capability provides ample bandwidth for modern applications, supporting data-intensive workloads and high-speed communication requirements.

Cost-Effective Networking Solution

By utilizing multi-mode fiber and QSFP+ technology, the module offers a cost-effective solution for high-speed networking without compromising performance.

Reduced Infrastructure Costs

The ability to use existing multi-mode fiber infrastructure helps organizations save on cabling and deployment costs.

Future-Proof Networking

Investing in 40Gbps transceivers prepares networks for future growth, ensuring scalability and adaptability to evolving technological demands.

Enhanced Network Performance

Improved data transfer rates and reduced latency contribute to overall network performance, supporting a wide range of applications and services.

Comparison with Other Optical Transceiver Categories

QSFP+ vs SFP+ Modules

QSFP+ modules offer significantly higher bandwidth compared to SFP+ modules, making them suitable for high-performance networking environments. While SFP+ supports up to 10Gbps, QSFP+ provides four times the bandwidth in a similar footprint.

Multi-mode vs Single-mode Transceivers

Multi-mode transceivers like the Dell 9GCCD are ideal for short-distance applications, offering cost advantages and ease of deployment. Single-mode transceivers, on the other hand, are designed for long-distance communication but typically involve higher costs.

Performance Considerations

The choice between multi-mode and single-mode depends on the specific networking requirements, including distance, budget, and infrastructure.

Deployment Flexibility

Multi-mode transceivers provide greater flexibility for data center environments, where short-range connectivity is the primary requirement.
