N7K-M108X2-12L Cisco Nexus 8 Ports 10 Gigabit Ethernet Module

Cisco 8 Ports 10 Gigabit Ethernet Expansion Module

The Cisco N7K-M108X2-12L Nexus 8-Port 10 Gigabit Ethernet Module is a high-performance expansion solution designed to enhance network scalability and efficiency. This plug-in module offers advanced features and compliance with global standards, making it ideal for enterprise-grade environments.

General Information

• Manufacturer: Cisco
• Part Number: N7K-M108X2-12L
• Device Type: Expansion Module

Technical Specifications

• Form Factor: Plug-in module
• Speed: 10 Gigabit Ethernet
• Dimensions: 15.3 in (W) x 21.9 in (D) x 1.7 in (H)
• Memory: 2 GB RAM

Advanced Features

• MPLS compatibility for flexible routing
• VLAN support for network segmentation
• Weighted Round Robin (WRR) queuing for traffic prioritization
• Access Control List (ACL) support for enhanced security
• Jumbo Frames support for optimized data transfer

Available Interfaces

• 8 x X2 ports

Slot Compatibility

• 1 x expansion slot

Compliance and Standards

• NEBS Level 3
• ETSI
• CISPR 22 Class A
• CISPR 24
• EN 61000-3-2
• ICES-003
• VCCI Class A ITE
• EN 61000-3-3
• EN55024
• EN55022 Class A
• AS/NZS 60950-1
• EN300-386
• UL 60950-1
• IEC 60950-1
• EN 60950-1
• FCC Part 15 A
• EN 60601-1-2

Cisco N7K-M108X2-12L 8 Ports 10 Gigabit Module Overview

The Cisco N7K-M108X2-12L Nexus 8 Ports 10 Gigabit Ethernet Module is a high-performance line card designed for the Cisco Nexus 7000 Series switches. This module provides advanced networking capabilities, scalability, and flexibility for enterprise data centers and service provider environments. With its 8-port 10 Gigabit Ethernet configuration, it is engineered to deliver exceptional throughput, low latency, and robust reliability, making it an essential component for organizations seeking to optimize their network infrastructure.

Design and Architecture of Cisco N7K-M108X2-12L

The architecture of the Cisco N7K-M108X2-12L is built to support the demanding requirements of modern data centers. Each port is capable of delivering 10 Gigabit Ethernet connectivity, ensuring that high-bandwidth applications and workloads can operate seamlessly. The module integrates with the Nexus 7000 chassis to provide a unified system that supports both Layer 2 and Layer 3 services, offering versatility for different networking scenarios.

Port Density and Connectivity

The module features 8 ports of 10 Gigabit Ethernet, which allows for efficient aggregation of multiple devices and servers. This port density is ideal for environments where high-speed interconnections are critical, such as virtualization clusters, storage area networks, and cloud computing platforms. The ports are designed to support both copper and fiber connections, offering flexibility in deployment.

Scalability and Expansion

Scalability is a core feature of the Cisco N7K-M108X2-12L. As organizations grow, the need for additional bandwidth and connectivity increases. This module allows seamless expansion by integrating additional line cards into the Nexus 7000 chassis. The modular design ensures that enterprises can scale their networks without significant disruption, maintaining performance and reliability.

Performance Features of Cisco N7K-M108X2-12L

Performance is at the heart of the Cisco N7K-M108X2-12L. The module is engineered to deliver high throughput and low latency, ensuring that mission-critical applications run smoothly. It supports advanced features such as quality of service (QoS), traffic shaping, and congestion management, which are essential for maintaining optimal performance in complex network environments.

High Throughput

Each port on the Cisco N7K-M108X2-12L is capable of delivering 10 Gigabits per second of bandwidth. This high throughput ensures that data-intensive applications, such as video streaming, large-scale data analytics, and cloud services, can operate without bottlenecks. The module’s ability to handle large volumes of traffic makes it suitable for enterprise and service provider networks.

Low Latency

Low latency is critical for applications that require real-time responsiveness, such as financial trading platforms and VoIP services. The Cisco N7K-M108X2-12L is designed to minimize latency, ensuring that data packets are transmitted quickly and efficiently across the network. This feature enhances user experience and supports time-sensitive applications.

Quality of Service (QoS)

The module supports advanced QoS features, allowing administrators to prioritize traffic based on application requirements. This ensures that critical applications receive the necessary bandwidth and performance, even during periods of high network congestion. QoS capabilities are essential for maintaining service levels in enterprise environments.

Reliability and Redundancy

Reliability is a key consideration for any network infrastructure. The Cisco N7K-M108X2-12L is designed with redundancy features that ensure continuous operation, even in the event of hardware failures. The module supports redundant power supplies and cooling systems, minimizing the risk of downtime. Additionally, it integrates with the Nexus 7000 chassis to provide system-level redundancy, enhancing overall network resilience.

Redundant Components

The module includes redundant components such as power supplies and fans, which ensure that the system remains operational even if one component fails. This redundancy is critical for maintaining uptime in mission-critical environments, where downtime can result in significant financial losses.

Failover Capabilities

The Cisco N7K-M108X2-12L supports failover capabilities, allowing traffic to be rerouted in the event of a failure. This ensures that network services remain available, even during hardware or software issues. Failover capabilities are essential for maintaining business continuity and minimizing the impact of disruptions.

Integration with Cisco Nexus 7000 Series

The Cisco N7K-M108X2-12L is designed to integrate seamlessly with the Cisco Nexus 7000 Series switches. This integration provides a unified system that supports advanced networking features, scalability, and flexibility. The Nexus 7000 Series is known for its modular design, which allows organizations to customize their network infrastructure based on specific requirements.

Unified System Architecture

The integration of the Cisco N7K-M108X2-12L with the Nexus 7000 chassis creates a unified system architecture that supports both Layer 2 and Layer 3 services. This versatility allows organizations to deploy the module in a variety of networking scenarios, from simple LAN configurations to complex WAN deployments.

Advanced Networking Features

The Nexus 7000 Series supports advanced networking features such as virtualization, automation, and programmability. The Cisco N7K-M108X2-12L leverages these features to provide enhanced performance and flexibility. This integration ensures that organizations can optimize their network infrastructure to meet evolving business needs.

Use Cases for Cisco N7K-M108X2-12L

The Cisco N7K-M108X2-12L is suitable for a wide range of use cases, including enterprise data centers, service provider networks, and cloud computing environments. Its high performance, scalability, and reliability make it an ideal choice for organizations seeking to optimize their network infrastructure.

Enterprise Data Centers

In enterprise data centers, the Cisco N7K-M108X2-12L provides high-speed connectivity for servers, storage systems, and applications. Its ability to deliver 10 Gigabit Ethernet connectivity ensures that data-intensive applications can operate seamlessly. The module’s scalability allows enterprises to expand their networks as needed, supporting growth and innovation.

Service Provider Networks

Service providers require robust and reliable networking solutions to deliver services to their customers. The Cisco N7K-M108X2-12L provides the performance and reliability needed to support large-scale networks. Its advanced features, such as QoS and failover capabilities, ensure that service providers can maintain high levels of service quality and availability.

Cloud Computing Environments

Cloud computing environments demand high performance and scalability. The Cisco N7K-M108X2-12L provides the connectivity needed to support cloud services, ensuring that applications and workloads can operate efficiently. Its integration with the Nexus 7000 Series allows cloud providers to optimize their infrastructure for performance and reliability.

Security Features of Cisco N7K-M108X2-12L

Security is a critical consideration for any network infrastructure. The Cisco N7K-M108X2-12L includes advanced security features that protect against threats and ensure the integrity of network services. These features include access control, encryption, and monitoring capabilities.

Access Control

The module supports access control features that allow administrators to define policies for network access. This ensures that only authorized users and devices can connect to the network, reducing the risk of unauthorized access and potential security breaches.
