WS-X45-SUP6L-E Cisco Catalyst 4500 E-Series Management Module

Key Features of Cisco WS-X45-SUP6L-E

• Manufacturer: Cisco
• Model Number: WS-X45-SUP6L-E
• Product Name: X45-SUP6L-E High-Performance Access Supervisor Engine
• Product Type: Supervisor Engine

Technical Information and Usage

Applications for Data Networking

• Ideal for optimizing data networking environments
• Provides seamless integration into existing networks
• Supports a range of management protocols for effective monitoring

Interfaces and Connectivity

Port Specifications

• 1x 10/100Base-TX Ethernet port
• 1x RJ-45 Console Management port
• 1x RJ-45 10/100Base-TX Management port

Data Transmission Rates

• 10 Mbps Ethernet
• 100 Mbps Fast Ethernet for enhanced performance

Supported Media Types

• Twisted Pair cables for 10/100Base-TX connectivity

I/O Expansion Capabilities

Expansion Slots

• 1x Compact Flash port for storage expansion
• 2x X2 slots for flexible module support

Advanced Management and Protocols

Management Features

• Supports Command Line Interface (CLI) for detailed configuration
• Web-based management for user-friendly configuration
• Integration with CiscoWorks for streamlined network management

Supported Protocols

• SNMP v1, v2, v3 for effective network monitoring
• DHCP for dynamic IP management
• Syslog for comprehensive event logging
• Telnet for remote access to the system

Quality of Service and VLAN Support

• IEEE 802.1p QoS for traffic prioritization
• IEEE 802.1Q VLAN for efficient traffic segmentation

Performance Optimization

Real-Time Monitoring

• RMON support for proactive monitoring and troubleshooting

Features

Enhanced Layer 2-4 services

The Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module offers enhanced Layer 2-4 services, providing users with advanced capabilities to optimize their network performance. With these enhanced services, users can experience improved efficiency and reliability in their network operations. The module supports features such as VLANs, QoS, and multicast routing, allowing for efficient traffic management and prioritization. By utilizing these services, users can ensure that critical applications are given priority, resulting in a smooth and uninterrupted user experience.

Up to 250 Mpps forwarding performance

One of the key benefits of the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module is its impressive forwarding performance of up to 250 Mpps (Million Packets per Second). This high-speed forwarding capability allows for seamless data transmission within the network, ensuring that data packets are processed and delivered efficiently. With this level of performance, users can handle large amounts of network traffic without encountering bottlenecks or slowdowns. This is particularly important for organizations that deal with data-intensive applications or have a high volume of network traffic.

Support for up to 384 Gigabit Ethernet ports

For organizations requiring a large number of network connections, the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module offers support for up to 384 Gigabit Ethernet ports. This extensive port density allows for the connection of numerous devices and facilitates easy expansion as the network grows. Having a sufficient number of ports eliminates the need for additional equipment, reducing both costs and complexity. Whether it's connecting servers, switches, or other network devices, this module provides the flexibility and scalability required to meet evolving business needs.

IPv6 support

As the world transitions to IPv6, the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module ensures compatibility by offering comprehensive support for this latest Internet Protocol version. IPv6 provides a larger address space, improved security features, and enhanced network efficiency compared to its predecessor, IPv4. By supporting IPv6, users can future-proof their network infrastructure and seamlessly integrate with IPv6-enabled devices and services. This enables organizations to stay ahead of technological advancements and ensures their network is ready for the future.

Integrated security features

Security is paramount in today's digital landscape, and the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module includes integrated security features to protect networks from potential threats. The module supports features such as Network Access Control (NAC), which allows administrators to enforce security policies and ensure that only authorized devices can connect to the network. Additionally, it offers features like port security and access control lists (ACLs) to prevent unauthorized access and mitigate potential risks. With these integrated security features, users can have peace of mind knowing that their network is safeguarded against unauthorized access and potential cyber-attacks.

Redundant power supplies

Network uptime is crucial for businesses, and the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module addresses this by providing redundant power supply options. Redundancy ensures that even if one power supply fails, the other can seamlessly take over, minimizing downtime and ensuring uninterrupted network operation. This feature is particularly important for organizations that rely heavily on their network infrastructure, such as data centers or enterprises with critical applications that cannot tolerate any disruption. With redundant power supplies, users can achieve maximum reliability and minimize the risk of costly downtime.

Benefits of Enhanced Layer 2-4 services

The enhanced Layer 2-4 services offered by the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module provide users with numerous benefits. By utilizing VLANs, users can logically segment their network, enhancing security and simplifying network management. Quality of Service (QoS) features enable prioritization of critical applications, ensuring a consistent user experience even during peak network traffic. Multicast routing capabilities reduce network congestion and optimize bandwidth utilization, improving overall network efficiency. These benefits together result in a more robust, reliable, and efficient network infrastructure.

Importance of Up to 250 Mpps forwarding performance

The forwarding performance of up to 250 Mpps offered by the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module is of utmost importance for organizations that require high-speed data transmission. With this level of performance, data packets can be processed and forwarded swiftly, ensuring minimal latency and improved application response times. This is particularly crucial for time-sensitive applications such as voice and video communication or real-time data processing. The module's high forwarding performance guarantees that network traffic flows smoothly, meeting the demands of modern business operations.

Advantages of Support for up to 384 Gigabit Ethernet ports

The support for up to 384 Gigabit Ethernet ports provided by the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module offers several advantages to users. Firstly, it eliminates the need for additional networking equipment, reducing costs and simplifying network architecture. The extensive port density enables easy connectivity for a wide range of devices, facilitating seamless communication and collaboration across the organization. Moreover, it provides scalability options as businesses grow and evolve, ensuring that the network infrastructure can expand without limitations. The ability to accommodate a large number of ports is invaluable for organizations with substantial networking requirements.

Benefits of IPv6 support

The inclusion of comprehensive IPv6 support in the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module brings several benefits to users. Firstly, IPv6 offers a significantly larger address space, eliminating the limitations imposed by the finite number of IPv4 addresses. This enables organizations to connect a larger number of devices and supports the growth of the Internet of Things (IoT) ecosystem. Additionally, IPv6 enhances network security through features such as built-in IPsec encryption and improved address auto-configuration. The module's IPv6 support ensures that users can leverage these advantages and seamlessly integrate with IPv6-enabled networks and services.

Significance of Integrated security features

The integrated security features provided by the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module play a vital role in safeguarding networks against potential threats. Network Access Control (NAC) enables administrators to enforce security policies, ensuring that only authorized devices can connect to the network. Port security features protect against unauthorized access by allowing administrators to define which devices are allowed to connect to specific ports. Access control lists (ACLs) offer granular control over network traffic, filtering out potentially harmful packets. These integrated security features are essential for maintaining network integrity, protecting sensitive data, and preventing unauthorized access or intrusions.

Advantages of Redundant power supplies

The inclusion of redundant power supplies in the Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module provides significant advantages for organizations that prioritize network uptime and reliability. By having redundant power supplies, businesses can ensure uninterrupted network operation even in the event of a power supply failure or maintenance activities. This is particularly crucial for organizations that rely heavily on their network infrastructure for critical operations or have stringent uptime requirements. With redundant power supplies, users can mitigate the risk of downtime, guarantee business continuity, and maintain high levels of productivity.

Conclusion

The Cisco Catalyst 4500 E-Series WS-X45-SUP6L-E Management Module offers a range of features that enhance network performance, scalability, security, and reliability. The module's enhanced Layer 2-4 services provide advanced capabilities for efficient traffic management, while its high forwarding performance ensures swift data transmission. Support for a large number of Gigabit Ethernet ports enables seamless connectivity and future scalability. IPv6 support ensures compatibility with the latest Internet Protocol version, while integrated security features protect against unauthorized access and potential threats. Lastly, redundant power supplies guarantee uninterrupted network operation. By incorporating these features into their network infrastructure, users can experience numerous benefits and ensure their network meets the demands of modern business operations.
