Cisco Meraki MX400 Cloud Managed Security Appliance Firewall MX400-HW.

Product Overview

Model Details

• Part Number: MX400-HW
• Brand: Meraki
• Product Type: Network Security/Firewall Appliance

Technical Specifications

Firewall Protection Features

• Stateful Packet Filtering: Supported
• Zero Day Event Detection: Included
• Directory Traversal Protection: Enabled
• Traffic Anomaly Detection: Available
• Application Firewall: Provided
• Content Filtering: Enabled
• Intrusion Prevention: Supported
• Antivirus: Included
• Anti-Phishing: Supported

Performance Metrics

• Firewall Throughput: 1 Gbps
• VPN Throughput: 325 Mbps
• VPN Tunnels (Site-to-Site): 2,000
• Concurrent Users: 2,000

Networking and Communication

• Ethernet Technology: 10 Gigabit Ethernet
• Network Standards: 10/100/1000Base-T, 1000Base-X, 10GBase-X

Connectivity and Expansion

Ports and Slots

• Total Ports: 4
• Network RJ-45 Ports: 4
• USB Ports: Yes
• PoE (RJ-45) Ports: None
• Expansion Slots (Total): 2
• Free Expansion Slots: 2

Additional Interfaces

• WAN Interfaces: 2 x Ethernet 1000
• USB Ports: 2 x Type A
• LAN Interfaces: 2 x Ethernet 1000

Management and Protocols

• Manageable: Yes
• Network/Transport Protocols: TCP/IP, IPSec, PPPoE, FTP, DHCP
• Remote Management Protocol: HTTP
• Authentication Method: Active Directory

Physical Characteristics

• Form Factor: Rack-mountable
• Compatible Rack Unit: 1U
• Dimensions (H x W x D): 1.8 in x 22 in x 19 in
• Weight: Approximately 33 lbs

Power and Environmental Specifications

• Power Device: Internal Power Supply
• Installed Power Supplies: 2
• Max Supported Power Supplies: 2
• Power Redundancy: Yes
• Voltage Required: AC 120/230 V (50/60 Hz)
• Power Consumption (Operational): 215 Watts
• Power Provided: 100 Watts

Environmental Considerations

• Environmentally Friendly: Yes
• Environmental Certification: RoHS

Features

• Network Monitoring: Included
• DMZ Port: Available
• DHCP Support: Enabled
• NAT Support: Provided
• VPN Support: Available
• VLAN Support: Included
• Syslog Support: Enabled
• Traffic Shaping: Supported
• High Availability: Provided
• Firmware Upgradable: Yes
• Event Log: Available
• Quality of Service (QoS): Supported
• WAN Failover: Included
• 3G/4G USB Dongle Support: Yes
• Application Level Inspection: Enabled
• Zero Touch Auto Provisioning: Supported
• Static Routing: Available

Meraki MX400 Cisco Cloud Managed Security Appliance

The Meraki MX400 Cisco Cloud Managed Security Appliance Firewall HW is a cutting-edge solution designed to provide robust security and advanced threat protection for businesses of all sizes. With its powerful features and intuitive cloud-based management, this appliance offers unparalleled security and ease of use.

Advanced Threat Protection

One of the key benefits of the Meraki MX400 Cisco Cloud Managed Security Appliance Firewall HW is its advanced threat protection capabilities. With the proliferation of cyber threats in today's digital landscape, businesses need a comprehensive security solution that can detect and mitigate sophisticated attacks.

This appliance leverages advanced security technologies, including next-generation firewall (NGFW), intrusion prevention system (IPS), and content filtering, to defend against a wide range of threats. It can identify and block malicious traffic, prevent data breaches, and protect sensitive information, ensuring that your network remains secure.

Real-time Threat Detection

The Meraki MX400 Cisco Cloud Managed Security Appliance Firewall HW employs real-time threat detection mechanisms to identify and respond to emerging threats promptly. It continuously monitors network traffic, analyzing patterns and behaviors to detect anomalies that may indicate a potential security breach.

By leveraging machine learning algorithms and threat intelligence feeds, this appliance can identify known malware signatures as well as zero-day attacks. It provides proactive protection by automatically updating its threat database to stay ahead of evolving threats, ensuring that your network is always protected.

Secure Remote Access

In today's mobile workforce, secure remote access is crucial for businesses. The Meraki MX400 Cisco Cloud Managed Security Appliance Firewall HW offers robust VPN capabilities, enabling employees to securely connect to the corporate network from anywhere in the world.

With its client VPN functionality, this appliance allows authorized users to establish encrypted connections to the network. It ensures that sensitive company data remains secure, even when accessed from untrusted networks. This feature is particularly important for businesses with remote workers or branch offices, as it enables secure collaboration and access to critical resources.

Cloud-based Management

The Meraki MX400 Cisco Cloud Managed Security Appliance Firewall HW is part of Cisco's Meraki cloud-managed portfolio, which brings simplicity and scalability to network management. Unlike traditional security appliances that require complex on-premises configurations, this appliance can be easily deployed and managed through a centralized cloud-based dashboard.

Intuitive Dashboard

The cloud-based management dashboard provides a user-friendly interface that allows administrators to configure, monitor, and troubleshoot the appliance with ease. It offers comprehensive visibility into the network, allowing administrators to identify potential security issues and take immediate action.

The intuitive nature of the dashboard eliminates the need for specialized IT skills, making it accessible to businesses of all sizes. It streamlines security management, saving time and resources while ensuring that the network remains secure.

Scalability and Flexibility

The cloud-managed nature of the Meraki MX400 Cisco Cloud Managed Security Appliance Firewall HW allows for seamless scalability and flexibility. Businesses can easily add or remove appliances as their needs change, without the hassle of reconfiguration or complex setup processes.

This flexibility extends to the deployment options as well. The appliance supports both traditional on-premises deployments and cloud-based deployments, allowing businesses to choose the approach that suits their infrastructure and preferences. It ensures that businesses can adapt to changing security requirements without compromising on performance or convenience.

Centralized Security Policies

With the cloud-based management dashboard, administrators can define and enforce security policies across the entire network from a single location. This centralized approach simplifies policy management and ensures consistent security across all devices and locations.

Administrators can create granular policies based on user roles, device types, and network segments. These policies can include firewall rules, content filtering settings, and intrusion prevention configurations. The ability to centrally manage security policies reduces the risk of misconfigurations and ensures that all devices adhere to the organization's security standards.

In conclusion, the Meraki MX400 Cisco Cloud Managed Security Appliance Firewall HW is a powerful and comprehensive security solution that offers advanced threat protection, secure remote access, and easy cloud-based management. With its real-time threat detection capabilities, intuitive dashboard, scalability, and centralized security policies, this appliance provides businesses with the peace of mind they need to protect their network and sensitive data. Whether it's a small business or a large enterprise, the Meraki MX400 Cisco Cloud Managed Security Appliance Firewall HW is an essential tool for mitigating cyber threats and ensuring a secure network infrastructure.
