JL563B HPE Aruba Cat 6 A T-Base SFP+ 10 GB Transceiver Module 1 X RJ 45 TS 80 Switch Plug-in Module

Highlight HPE JL563B Aruba SFP+ Transceiver Module

The HPE JL563B Aruba Cat6A T-Base SFP+ 10 Gigabit Transceiver Module is a high-performance plug-in solution designed for seamless integration with Aruba CX series switches. This advanced networking device ensures reliable data transmission and efficient connectivity for enterprise-level infrastructures.

General Information

• Manufacturer: HPE
• Part Number: JL563B
• Device Type: Transceiver Module
• Product Name: 10GBASE-T SFP+ RJ-45 30m Cat6A Transceiver

Technical Specifications

• Application: Data Networking
• Form Factor: Plug-in Module
• Network Technology: 10GBASE-T
• Twisted Pair Cable Standard: Category 6A
• Ethernet Technology: 10 Gigabit Ethernet
• Media Type Supported: Twisted Pair

Interfaces and Ports

• Interface Details: 1 x RJ-45 10GBASE-T LAN
• Connector Type: RJ-45
• Total Number of Ports: 1

Compatibility

• Aruba CX 8360-12C V2
• Aruba CX 8360-16Y2C V2

Overview of HPE JL563B T-Base SFP+ 10GB Transceiver Module

The HPE JL563B Aruba Cat 6A T-Base SFP+ 10GB Transceiver Module represents a highly advanced networking solution designed to deliver exceptional performance in enterprise environments. This plug-in module integrates seamlessly with Aruba TS 80 Switch systems, offering a reliable and efficient way to extend 10 Gigabit Ethernet connectivity over copper cabling. With its RJ-45 interface, the transceiver simplifies deployment by eliminating the need for fiber optic infrastructure, making it a cost-effective option for organizations seeking high-speed data transfer and robust compatibility.

Form Factor and Interface

The JL563B transceiver adopts the compact SFP+ form factor, which allows for hot-pluggable installation and easy integration into Aruba TS 80 Switches. The RJ-45 connector type ensures compatibility with standard Ethernet cabling, simplifying installation and reducing infrastructure costs. The module complies with IEEE 802.3an standards, guaranteeing interoperability across a wide range of networking equipment.

Performance and Efficiency

With a power consumption of approximately 2.5 to 3.5 watts, the JL563B balances high-speed performance with energy efficiency. This makes it suitable for large-scale deployments where minimizing power usage is crucial. The module operates within a temperature range of 0°C to 70°C, ensuring reliable performance in diverse environmental conditions. Additionally, it supports storage temperatures from -40°C to 85°C, providing durability and resilience during transport or downtime.

Networking Capabilities

The JL563B Aruba transceiver is designed to support wired connectivity technologies, specifically optimized for 10GBASE-T Ethernet. It enables seamless communication using Cat 6A or Cat 7 cabling, ensuring high-speed data transfer without the need for fiber optics. This makes it particularly advantageous for enterprises seeking to upgrade their infrastructure without incurring the costs associated with fiber deployment.

Data Link Protocols and Transfer

The module supports multiple data link protocols, including 100Mb LAN, Gigabit Ethernet, and 10 Gigabit Ethernet. This versatility ensures backward compatibility with existing infrastructure while providing a pathway to higher speeds. The maximum data transfer rate of 10 Gbps allows organizations to handle bandwidth-intensive applications such as virtualization, cloud computing, and large-scale data analytics with ease.

Expansion and Connectivity Options

Equipped with a single Ethernet 10GBASE-T RJ-45 interface, the JL563B transceiver provides straightforward connectivity for switches and servers. This design simplifies network expansion, allowing administrators to scale their infrastructure efficiently. The plug-in nature of the module ensures that upgrades can be performed quickly, minimizing downtime and disruption to critical operations.

Compatibility with Aruba Networking Platforms

The JL563B module is fully compatible with Aruba networking switches that feature 10G SFP+ ports. It is specifically designed for Aruba CX and Aruba OS-Switch platforms, ensuring seamless integration and optimal performance. This compatibility makes it an ideal choice for organizations already invested in Aruba’s networking ecosystem, providing a reliable and efficient solution for expanding 10GbE connectivity.

Deployment Scenarios and Use Cases

The JL563B Aruba transceiver is suitable for a wide range of deployment scenarios, from data centers to enterprise networks. Its ability to deliver 10GbE connectivity over copper cabling makes it particularly useful in environments where fiber optic cabling is impractical or cost-prohibitive. Common use cases include switch-to-switch connections, switch-to-server links, and high-speed backbone infrastructure within enterprise networks.

Data Center Applications

In data centers, the JL563B module enables high-speed communication between servers and switches, supporting bandwidth-intensive applications such as virtualization, cloud services, and big data analytics. Its compatibility with Cat 6A and Cat 7 cabling ensures reliable performance, while its compact form factor allows for efficient use of rack space.

Enterprise Networking Solutions

For enterprise networks, the JL563B transceiver provides a cost-effective way to upgrade to 10GbE connectivity without the need for fiber optics. This makes it ideal for organizations seeking to enhance their network performance while minimizing infrastructure costs. The module’s backward compatibility with lower-speed protocols ensures smooth integration with existing systems.

Switch-to-Server Connectivity

The JL563B module is particularly effective for switch-to-server connections, where high-speed data transfer is essential for supporting modern applications. By leveraging Cat 6A or Cat 7 cabling, organizations can achieve reliable 10GbE connectivity, ensuring that servers can handle demanding workloads efficiently.

Compliance and Standards

The JL563B Aruba transceiver complies with industry standards, including SFP+ MSA, IEEE 802.3an, RoHS, and CE certifications. This ensures that the module meets stringent requirements for performance, safety, and environmental sustainability. Compliance with these standards guarantees interoperability with a wide range of networking equipment, providing organizations with flexibility and peace of mind.

Environmental Considerations

With RoHS compliance, the JL563B module adheres to environmental regulations by minimizing the use of hazardous materials. This makes it a sustainable choice for organizations seeking to reduce their environmental impact. Its wide operating and storage temperature ranges further enhance its durability, ensuring reliable performance in diverse conditions.

Hot-Pluggable Design

The hot-pluggable nature of the JL563B transceiver allows administrators to install or replace the module without shutting down the system. This feature minimizes downtime and ensures continuous operation, making it particularly valuable in mission-critical environments where uninterrupted connectivity is essential.

Ease of Deployment

The RJ-45 interface and compatibility with standard Ethernet cabling simplify deployment, allowing organizations to upgrade their infrastructure quickly and efficiently. This ease of deployment reduces installation time and costs, making the JL563B module a practical choice for enterprises of all sizes.
