MA-QSFP-40G-CSR4 Meraki Cisco 40GBPS Transceiver LAN Plug-in Module

Meraki MA-QSFP-40G-CSR4 40 Gigabit Transceiver Module

High-Performance Cisco-Compatible Networking Component

The Meraki MA-QSFP-40G-CSR4 is a high-speed optical transceiver designed for modern enterprise networking environments. Built for reliable 40 Gigabit Ethernet connectivity, this plug-in module ensures efficient data transmission across advanced LAN infrastructures.

Manufacturer and Product Identification

• Brand: Meraki
• Model / Part Number: MA-QSFP-40G-CSR4
• Device Category: Optical Transceiver Module
• Speed Class: 40 Gigabit Ethernet

Core Technical Attributes

Design and Physical Format

Engineered as a compact plug-in unit, this module supports seamless integration into compatible switches, providing stable and scalable networking performance.

Hardware Specifications

• Form Factor: Hot-swappable plug-in module
• Connection Type: Wired fiber optic interface
• Cabling Standard: 40GBASE-CSR4
• Optical Wavelength: 850 nm for multimode fiber transmission

Performance Capabilities

• Data Rate: Up to 40 Gbps high-speed throughput
• Network Protocol: 40 Gigabit Ethernet LAN support
• Maximum Transmission Distance: Approximately 1310 feet

Connectivity and Interface Details

Fiber Optic Integration

This transceiver is designed for efficient multimode fiber connectivity, ensuring low-latency and high-bandwidth communication across enterprise networks.

Interface Configuration

• Port Type: 1 x Ethernet 40GBASE-CSR4
• Connector Type: MPO (Multi-fiber Push-On) interface
• Transmission Medium: Multimode fiber cabling

System Compatibility and Supported Hardware

Supported Cisco Meraki Platforms

• Meraki Cloud Managed MS420-24 Switch
• Meraki Cloud Managed MS420-48 Switch
• Meraki MS410-16 Ethernet Aggregation Switch
• Meraki MS410-32 Switch System
• Meraki MS425-16 Network Switch
• Meraki MS425-32 High-Performance Switch

Deployment Benefits in Enterprise Networking

Key Advantages for Network Infrastructure

• Enhanced backbone throughput for data centers and enterprise LANs
• Reliable optical transmission for long-distance switch interconnection
• Scalable 40Gbps bandwidth for demanding workloads
• Seamless integration into cloud-managed Meraki environments

Use Case Scenarios

• Data center aggregation layers
• High-speed backbone connectivity between switches
• Enterprise campus network expansion
• Cloud-managed switching architectures

Operational Efficiency Highlights

• Low-latency optical transmission for real-time applications
• Stable performance under heavy network traffic loads
• Energy-efficient design supporting modern IT infrastructures

Overview of 40Gbps QSFP+ Transceiver Modules in Enterprise Networking

The Meraki MA-QSFP-40G-CSR4 Cisco 40Gbps Transceiver LAN Plug-in Module represents a critical component within high-speed networking environments where scalability, performance, and reliability are essential. Designed for modern enterprise infrastructures, this QSFP+ optical transceiver enables data transmission over fiber channels with exceptional bandwidth capabilities, making it suitable for data centers, cloud environments, and large-scale enterprise networks. The increasing demand for faster data throughput and reduced latency has made 40Gbps transceivers a foundational element in network expansion strategies, particularly for organizations transitioning from legacy 10Gbps systems to higher-capacity solutions.

Core Architecture and Design Philosophy

The design of the MA-QSFP-40G-CSR4 module is centered around efficiency, compactness, and interoperability. Utilizing the Quad Small Form-Factor Pluggable Plus interface, it consolidates four independent transmit and receive channels into a single module. This architecture allows for aggregated data rates up to 40Gbps while maintaining a compact footprint, making it ideal for high-density switch environments. Its plug-and-play functionality simplifies deployment and maintenance, reducing the complexity associated with network upgrades and expansions.

Optical Transmission Technology

At the heart of this module lies advanced optical transmission technology that leverages multimode fiber connectivity. By distributing signals across four parallel lanes, each operating at 10Gbps, the module achieves its total throughput efficiently. This parallel optics approach not only enhances performance but also improves redundancy and signal integrity across the network infrastructure. The CSR4 designation indicates its capability to operate over extended distances compared to standard SR4 modules, providing greater flexibility in network design.

Compatibility and Integration Capabilities

One of the defining characteristics of the MA-QSFP-40G-CSR4 is its seamless integration with compatible networking hardware. Engineered to function within Cisco Meraki ecosystems, it ensures optimal performance when deployed with supported switches and networking devices. The module adheres to industry standards, enabling interoperability with a wide range of networking equipment while maintaining consistent performance metrics. This compatibility simplifies procurement decisions and reduces the risk of integration challenges in complex IT environments.

Performance Characteristics and Data Throughput Optimization

Performance remains a key consideration for organizations deploying 40Gbps transceivers. The MA-QSFP-40G-CSR4 module is engineered to deliver high-speed data transmission with minimal latency, ensuring efficient handling of large volumes of network traffic. Its architecture supports data-intensive applications such as virtualization, high-frequency trading platforms, video streaming, and large-scale data analytics.

Bandwidth Efficiency and Signal Integrity

Bandwidth efficiency is achieved through precise signal modulation and advanced encoding techniques. The module maintains consistent signal integrity even under heavy network loads, ensuring reliable communication between connected devices. Error detection and correction mechanisms further enhance performance by minimizing data loss and maintaining transmission accuracy across fiber links.

Low Latency Communication

In high-performance networks, latency can significantly impact application responsiveness. The MA-QSFP-40G-CSR4 is optimized to reduce latency, enabling near real-time data transfer between endpoints. This makes it particularly valuable in environments where milliseconds matter, such as financial services, online gaming platforms, and mission-critical enterprise systems.

Energy Efficiency and Thermal Management

Despite its high-performance capabilities, the module is designed with energy efficiency in mind. Advanced thermal management mechanisms ensure optimal operating temperatures, preventing overheating and prolonging the lifespan of the device. Efficient power consumption not only reduces operational costs but also contributes to environmentally sustainable networking practices.

Deployment Scenarios and Use Cases

The versatility of the MA-QSFP-40G-CSR4 transceiver makes it suitable for a wide range of deployment scenarios. From enterprise campuses to hyperscale data centers, this module plays a crucial role in enabling high-speed connectivity and seamless communication across network infrastructures.

Data Center Interconnects

In data center environments, the need for high-bandwidth connectivity between servers, storage systems, and switches is paramount. The MA-QSFP-40G-CSR4 facilitates efficient data center interconnects by providing reliable and high-speed optical links. Its ability to support extended distances allows for flexible layout designs, accommodating both intra-rack and inter-rack connections.

Enterprise Network Backbone

For enterprise networks, the backbone infrastructure requires robust and scalable connectivity solutions. This transceiver module serves as a critical component in backbone networks, ensuring seamless data flow between core switches and distribution layers. Its high throughput capabilities support the growing demand for bandwidth-intensive applications within modern organizations.

Cloud and Virtualized Environments

Cloud computing and virtualization have transformed the way organizations manage their IT resources. The MA-QSFP-40G-CSR4 supports these environments by enabling rapid data transfer between virtual machines, storage arrays, and compute nodes. Its performance characteristics ensure that virtualized workloads operate efficiently without bottlenecks.

Advantages of 40Gbps QSFP+ Technology

The adoption of 40Gbps QSFP+ technology offers numerous advantages over traditional networking solutions. As organizations continue to scale their operations, the need for higher bandwidth and improved performance becomes increasingly critical.

Scalability for Future Growth

One of the primary benefits of QSFP+ modules is their scalability. The MA-QSFP-40G-CSR4 provides a pathway for organizations to expand their network capacity without significant infrastructure changes. This scalability ensures that networks can adapt to evolving business requirements and technological advancements.

Cost Efficiency in High-Density Deployments

Compared to deploying multiple lower-speed transceivers, a single 40Gbps module offers greater cost efficiency. By consolidating multiple data channels into a single interface, organizations can reduce hardware requirements and simplify network management. This results in lower capital expenditures and operational costs over time.

Enhanced Network Reliability

Reliability is a critical factor in enterprise networking. The MA-QSFP-40G-CSR4 is designed to deliver consistent performance under demanding conditions, ensuring uninterrupted connectivity. Its robust construction and adherence to industry standards contribute to long-term reliability and reduced maintenance requirements.

Technical Specifications and Functional Capabilities

The technical specifications of the MA-QSFP-40G-CSR4 highlight its advanced capabilities and suitability for high-performance networking environments. Understanding these specifications is essential for selecting the right transceiver for specific applications.

Form Factor and Interface

The QSFP+ form factor provides a compact and efficient solution for high-speed data transmission. Its hot-swappable design allows for easy installation and replacement without disrupting network operations. The module interfaces seamlessly with compatible ports, ensuring quick deployment and minimal downtime.

Transmission Distance and Fiber Compatibility

This transceiver supports transmission over multimode fiber, offering extended reach compared to standard short-range modules. Its compatibility with various fiber types provides flexibility in network design, enabling organizations to optimize their infrastructure based on specific requirements.

Data Rate and Channel Configuration

With four independent channels operating at 10Gbps each, the module achieves an aggregate data rate of 40Gbps. This configuration ensures efficient utilization of bandwidth while maintaining high levels of performance and reliability. The parallel channel design also enhances fault tolerance and signal distribution.
