DCS-7316X-FM-F Arista Fabric-X Integrated Fans Module For 7316 Chassis

Arista DCS-7316X-FM-F Fabric-X Module

The Arista DCS-7316X-FM-F is a high-performance fabric module engineered to deliver efficient cooling and seamless integration for the Arista 7316 modular chassis. Designed with advanced technology, it ensures optimal airflow, reliability, and scalability for demanding data center environments.

General Details

Manufacturer Information

• Brand: Arista Networks
• Part Number: DCS-7316X-FM-F
• Category: Chassis Module

Technical Specifications

Chassis Compatibility

• Exclusively designed for the Arista 7316 (21RU) modular chassis

• Supports total switching throughput up to 40 Tbps
• Handles up to 30 Bpps (Billion packets per second)
• Ensures sub-2 microsecond port-to-port latency

Energy Efficiency

Power Usage

• Typical consumption: 550 Watts
• Maximum draw: 760 Watts

Physical Characteristics

Dimensions

• Height: 32.2” (81.78 cm)
• Width: 3.7” (9.4 cm)
• Depth: 15.9” (40 cm)

Weight

• Approx. 37.2 lbs (16.8 kg) per module
