HWIC-1B-U Cisco 1 Port WIC Expansion Module

Overview Of Cisco HWIC-1B-U 1 Port WAN Interface Card

The Cisco HWIC-1B-U 1 Port WAN Interface Card is a high-performance modular networking expansion unit designed for Cisco Integrated Services Routers (ISR). This WAN interface module enables reliable ISDN Basic Rate Interface (BRI) connectivity with built-in NT1 functionality, delivering stable voice and data communication for enterprise branch networks and legacy telecommunication environments.

Manufacturer and Product Identification

• Manufacturer: Cisco Systems, Inc
• Part Number: HWIC-1B-U
• Product Type: WAN Interface Expansion Card
• Form Factor: High-Speed WAN Interface Card (HWIC) module
• Deployment Purpose: ISDN BRI network connectivity expansion

Key Interface Specifications

• Interface Type: ISDN BRI with built-in NT1
• Physical Port: 1 x RJ-49C connector
• Data Transfer Rate: Up to 128 Kbps
• B-Channel Speed: 64 Kbps per channel (dual-channel support)

Performance Highlights

• Dual B-channel architecture for combined bandwidth efficiency
• Low-latency ISDN communication support
• Optimized for legacy enterprise WAN infrastructures

Physical Characteristics

• Form Factor: Single-slot HWIC plug-in module
• Connector Type: RJ-49C interface port
• Integrated NT1 eliminates external hardware dependency

Indicator Functions

• B1 Channel Status LED
• B2 Channel Status LED
• NT1 Central Office Connection Indicator

Supported Cisco Platforms

• Cisco ISR 1800 Series: 1841
• Cisco ISR 1900 Series: 1921, 1941
• Cisco ISR 2800 Series: 2801, 2811, 2821, 2851
• Cisco ISR 2900 Series: 2901, 2911, 2921, 2951
• Cisco ISR 3800 Series: 3825, 3845
• Cisco ISR 3900 Series: 3925, 3945

Management Features

• Cisco IOS Command-Line Interface (CLI) control
• SNMP-based remote monitoring support
• Centralized router-based configuration

Primary Advantages

• Integrated NT1 reduces need for external devices and cabling
• Lower installation and maintenance costs
• Efficient use of router expansion slots

Investment Protection and Flexibility

• Modular design allows easy relocation between routers
• Supports evolving network bandwidth requirements
• Extends lifecycle of existing Cisco infrastructure

Operational Management Features

• Remote configuration via Cisco IOS
• Real-time diagnostics and monitoring tools
• Integrated WAN performance visibility

Technical Features

• 1-port ISDN BRI WAN interface card
• Built-in NT1 support (U reference point)
• Up to 128 Kbps data transfer capability
• Single-slot HWIC modular design
• Full Cisco ISR compatibility
• CLI and SNMP-based management support
