HWIC-1B-U Cisco 1 Port WAN Interface Card

Overview Of Cisco HWIC-1B-U 1-Port WAN Interface Card

The Cisco HWIC-1B-U WAN Interface Card is a high-performance modular networking solution designed for enterprise-grade connectivity. Built to expand the capabilities of Cisco Integrated Services Routers (ISR), this interface card delivers reliable ISDN Basic Rate Interface (BRI) communication with integrated NT1 functionality, making it a compact and efficient WAN connectivity upgrade for branch offices and business networks.

Core Product Details

• Manufacturer: Cisco Systems, Inc
• Part Number: HWIC-1B-U
• Product Type: WAN Interface Card (HWIC Module)
• Interface Standard: ISDN BRI with built-in NT1 (U reference point)
• Form Factor: Single-slot HWIC plug-in module

Interface Specifications

• Interface Type: ISDN BRI (Integrated Services Digital Network)
• Built-in NT1 device (U reference point support)
• Physical Port: 1 x RJ-49C connector
• Data Transfer Rate: Up to 128 Kbps
• Channel Configuration: 2 x 64 Kbps B-channels

Performance Highlights

• Maximum throughput up to 128 Kbps
• Dual B-channel architecture for efficient load distribution
• Stable ISDN communication over public switched telephone networks

Physical Characteristics

• Form Factor: HWIC plug-in module
• Compact design for space-saving installation
• Integrated NT1 reduces external equipment requirements

LED Status Indicators

• B1 Channel Status Indicator
• B2 Channel Status Indicator
• NT1 Central Office Connection Status

Supported Cisco Router Series

Cisco ISR 1840 & 1900 Series

• 1841
• 1921
• 1941

Cisco 2800 & 2900 Series

• 2801
• 2811
• 2821
• 2851
• 2901
• 2911
• 2921
• 2951

Cisco 3800 & 3900 Series

• 3825
• 3845
• 3925
• 3945

Cisco IOS-Based Control System

Management Features

• Command-Line Interface (CLI) configuration support
• SNMP-based remote monitoring
• Centralized router-based management

Primary Benefits

• Space Optimization: Built-in NT1 eliminates the need for external devices
• Cost Efficiency: Reduces hardware and cabling expenses
• Flexible Deployment: Easily transferable between compatible Cisco routers
• Centralized Control: Simplified management via Cisco IOS

Investment Protection and Scalability

• Modular design supports future upgrades
• Reusable across multiple Cisco ISR platforms
• Ideal for evolving network infrastructures

Recommended Applications

• Branch office WAN connectivity
• Backup communication links
• Legacy ISDN infrastructure support
• Remote site networking solutions

Technical Summary

• Interface Type: ISDN BRI with NT1 integration
• Port: 1 x RJ-49C
• Speed: Up to 128 Kbps
• Form Factor: HWIC single-slot module
• Management: Cisco IOS CLI and SNMP
• Compatibility: Cisco ISR 1800, 2800, 2900, 3800, 3900 series
