WS-X6708-10G-3CXL Cisco 8 Ports Ethernet Module

Cisco WS-X6708-10G-3CXL 8-Port 10 Gigabit Expansion Module

The WS-X6708-10G-3CXL is a high-performance networking expansion module for advanced enterprise switching environments. This 8-port 10 Gigabit Ethernet module delivers scalable bandwidth, robust forwarding capacity, and optimized data center connectivity for mission-critical infrastructures.

General Information

• Manufacturer: Cisco
• Part Number: WS-X6708-10G-3CXL
• Device Category: Expansion / Switching Module
• Deployment Type: Enterprise core and aggregation networking

Technical Specifications

• Maximum Data Rate: Up to 10 Gbps per port (Gigabit Ethernet standards)
• Total Port Count: 8 x X2 high-speed optical slots
• Transmission Efficiency: Optimized for low latency switching environments

Supported Media Types

• Multi-mode optical fiber support
• Single-mode optical fiber compatibility
• Enterprise-grade long-distance optical transmission

Switch Fabric and Throughput Architecture

• Switch Fabric Connection: 40 Gbps full-duplex
• Aggregated Throughput: Up to 80 Gbps performance capability
• Architecture Type: Distributed switching design

Forwarding and Routing Performance

• Supports up to 1 million routes via DFC3CXL daughter card
• Hardware-based forwarding acceleration
• Reduced CPU overhead for high traffic environments

Hardware Expansion and Internal Architecture

• 8 x X2 optical transceiver slots
• Flexible port provisioning for enterprise deployment
• High-density interface architecture for backbone routing

Daughter Card Integration

• Hardware-based route computation acceleration
• Enhanced scalability for large routing tables
• Optimized QoS handling and traffic segmentation

Management and Network Control Features

• SNMP (Simple Network Management Protocol)
• RMON (Remote Network Monitoring)
• VLAN configuration and segmentation support
• SIMON management integration

Quality of Service (QoS) Optimization

Traffic Prioritization

• CoS-based queue mapping
• Traffic prioritization for enterprise workloads
• Bandwidth allocation control per service class

Memory, Buffering, and System Resources

• Default Memory: 1 GB onboard memory
• Optimized packet buffering system
• Enhanced performance for burst traffic scenarios

Port Buffer Allocation

• Buffer Size: 200 MB per port allocation
• Improved congestion management
• Stable throughput under peak traffic conditions

System Integration

• Compatible with Supervisor Engine 720
• Seamless integration with Cisco Catalyst modular systems
• Designed for enterprise backbone and aggregation layers
