76-ES+T-4TG Cisco 7600 Series 4x 10GB XFP Router Line Card

Outline of Cisco 7600 Series Line Card

The Cisco 76-ES+T-4TG is a high-performance router expansion module designed for the Cisco 7600 Series. It delivers advanced networking capabilities with 4x 10GB XFP ports and integrated DFC 3CXL support.

General Information

• Brand: Cisco
• Part Number: 76-ES+T-4TG
• Device Type: Router Expansion Module

Technical Information

• Form Factor: Plug-in module
• Height: 4.4 cm
• Width: 39.1 cm
• Depth: 40.6 cm
• Weight: 5.6 kg
• Compatible Slots: 1 x Expansion Slot

Supported Standards

Networking Protocols

• IEEE 802.1Q
• IEEE 802.3ad (LACP)
• IEEE 802.3ae
• IEEE 802.1s
• IEEE 802.1ah
• ITU-T G.709

Compliance Certifications

• CISPR 22 Class A
• EN 60950, EN 61000-3-2
• VCCI Class A ITE
• IEC 60950
• EN 61000-3-3, EN55024
• UL 60950
• EN50082-1, EN 61000-6-1
• ACA TS001, AS/NZS 3260
• AS/NZ 3548 Class A
• CSA C22.2 No. 60950-00
• ICES-003 Class A
• FCC Part 15 A
• EN 55022 Class A
• EN 300

Connectivity

• Technology: Wired
• Protocol: 10 Gigabit Ethernet
• Interfaces: 4 x Network - XFP
• MAC Address Table Size: 96K entries

Switching Capabilities

• Layer 2 and Layer 3 Switching
• MPLS Support
• VLAN Support
• DiffServ Support
• IPv6 Compatibility
• MPLS Fast Reroute (FRR)

Traffic Management

• Low-latency Queuing (LLQ)
• Class-Based Weighted Fair Queuing (CBWFQ)
• Weighted Random Early Detection (WRED)
• Rapid Spanning Tree Protocol

Operating Range

• Temperature: 0°C to 40°C
• Humidity: 10% - 90% (non-condensing)

Memory and Management

• RAM: 512 MB
• Remote Management Protocols: SNMP, RMON, SMON
• Status Indicators: Operational Status

Compatibility

• Cisco 7603-S
• Cisco 7604, 7604 Security Bundle
• Cisco 7606, 7606-S, 7606 Security Bundle
• Cisco 7609, 7609-S, 7609 Security Bundle
• Cisco 7613, 7613-S, 7613 Security Bundle

Category Overview of Cisco 76-ES+T-4TG 7600 Series Line Card
