7600-ES+4TG3CXL Cisco 7600 Series 4x 10GB XFP Router Line Card

Overview of Cisco 7600-ES+4TG3CXL Router Line Card

The Cisco 7600-ES+4TG3CXL Router Line Card is engineered for high-speed networking, offering advanced scalability and robust performance for enterprise and service provider environments. This line card integrates seamlessly with Cisco 7600 Series chassis, delivering reliable connectivity and intelligent traffic management.

General Information

• Brand: Cisco
• Part Number: 7600-ES+4TG3CXL
• Category: Router Line Card

Port Availability

• 4 x 10 Gigabit Ethernet XFP interfaces

Supported Media

• Optical Fiber connections

Expansion Options

• Total Expansion Slots: 4
• Slot Type: XFP

Data Transfer Rate

• 10 Gigabits per second throughput

Forwarding Entries

• Up to 1 million hardware-based forwarding entries supported via DFC-3CXL

NetFlow Support

• Handles up to 256,000 NetFlow entries

MAC Address Scale

• Supports up to 96,000 MAC addresses per line card

Buffering Capabilities

• 512 MB packet memory
• Provides up to 200ms bidirectional buffering at 10 Gbps

Chassis Compatibility

• Supported on Cisco 7600 Series chassis: 7604, 7606, 7609, 7613
• Note: 7603 unsupported; 7603-S fully supported

Supervisor Engine Compatibility

• Compatible with Supervisor Engine 720 (Sup720)
• Route Switch Processor 720 (RSP720) and later versions supported

Power Consumption

• Maximum power usage: approximately 399 Watts
