X710-DA4FH Intel Quad Port 10GbE SFP+ Plug-in Card PCIe Wired CNAs

Intel X710-DA4FH Quad Port Wired Converged Adapter

Intel X710-DA4FH Quad-Port 10 Gigabit Ethernet SFP+ network interface adapter is a high-performance PCI-Express plug-in card designed for advanced converged networking environments. Built to deliver ultra-fast data transmission and reliable connectivity, this adapter integrates four independent 10GbE SFP+ interfaces, enabling scalable bandwidth for enterprise servers, cloud infrastructures, virtualization platforms, and data-intensive workloads. It is engineered for efficiency, stability, and enhanced network traffic handling in modern IT architectures.

General Information

• Manufacturer: Intel
• Part Number: X710-DA4FH
• Device Type: Converged Network Interface Card

Technical Specifications

• Form Factor: Plug-in PCIe Card
• Bus Interface: PCI Express 3.0 x8

Networking Capabilities

• Port Configuration: 4 × 10 Gigabit SFP+ ports
• Connection Type: Wired Ethernet networking
• Supported Protocols: Gigabit Ethernet, 10 Gigabit Ethernet
• Data Throughput: Up to 10 Gbps per port
• Network Protocol Support: TCP/IP, UDP/IP, iSCSI, SMB, NFS
• Remote Management: SNMP, RMON monitoring protocols
• Status Indicators: Link/activity status and transmission speed monitoring

Advanced Features

• VLAN tagging and segmentation support
• IPv4 and IPv6 protocol compatibility
• TCP/IP offloading engine for reduced CPU usage
• Quality of Service (QoS) traffic prioritization
• Virtual Machine Device Queues (VMDq) for virtualization efficiency
• Single Root I/O Virtualization (SR-IOV) support
• Receive Side Scaling (RSS) for distributed processing
• Large Send Offload (LSO) and TCP Segmentation Offload (TSO)
• UDP/IP checksum and packet offloading
• Data Center Bridging (DCB) capability
• Energy Efficient Ethernet optimization
• Teaming and Adaptive Load Balancing (ALB)
• PXE network boot support
• Watchdog timer functionality for system reliability

Expansion and Connectivity

• Interface support: 4 × SFP+ (1GbE / 10GbE compatible)
• Compatible with standard SFP+ optical transceivers (SR/LR)
• Supports DAC (Direct Attach Copper) and AOC (Active Optical Cable) solutions

Compliance Standards

• IEEE 802.3 Ethernet standard compliance
• IEEE 802.1Q VLAN tagging support
• IEEE 802.1P traffic prioritization
• IEEE 802.3ad Link Aggregation (LACP)
• IEEE 802.1AS time synchronization support
• IEEE 802.1Qbg Edge Virtual Bridging compatibility

System Compatibility

• Designed for enterprise rack servers with PCIe 3.0 x8 slot availability
• Compatible with Intel Xeon-based server platforms
• Supports major operating systems including Windows Server editions
• Linux kernel-based distributions with Intel ixgbe driver support
• Compatible with virtualization platforms such as VMware ESXi
• Optimized for cloud data centers, storage networking, and high-performance computing environments
• Works with standard SFP+ network infrastructure components and switches

High Performance Quad Port 10 Gigabit Converged Adapter

The Intel X710-DA4FH Quad Port 10 Gigabit Ethernet SFP+ Plug-in Card PCI-Express Wired Converged Network Adapter represents a high density networking solution designed for modern enterprise infrastructures, cloud-scale environments, virtualization clusters, and high throughput data center deployments. Built around Intel Ethernet controller technology, this adapter is engineered to deliver consistent throughput, low latency packet processing, and advanced offload capabilities that reduce CPU utilization while maximizing network efficiency across demanding workloads.

As data centers evolve toward software defined networking and hyper-converged infrastructure models, the need for reliable multi-port 10 Gigabit Ethernet connectivity becomes essential. This adapter integrates four independent SFP+ interfaces on a single PCI Express card, enabling consolidated network expansion without requiring multiple single port adapters. The result is improved PCIe slot utilization, simplified cabling infrastructure, and enhanced scalability for rack servers, blade systems, and virtualization hosts.

Core Design and Hardware Integration Characteristics

The architecture of the Intel X710-DA4FH is centered around a highly optimized Ethernet controller that supports multiple networking offloads and virtualization acceleration features. The PCI Express interface ensures high bandwidth communication between the server motherboard and network controller, minimizing bottlenecks during heavy packet transfer operations. Each of the four SFP+ ports is independently controlled, allowing flexible network segmentation and traffic isolation for different workloads.

The design emphasizes energy efficiency while maintaining enterprise-grade performance standards. The controller dynamically adjusts power consumption based on link activity, which contributes to lower operational costs in large scale deployments. The hardware is also optimized for thermal stability, ensuring continuous operation under sustained network load conditions commonly found in virtualization clusters and storage replication environments.

10 Gigabit Ethernet SFP+ Connectivity and Optical Flexibility

The use of SFP+ interfaces provides significant flexibility in selecting optical transceivers or direct attach copper modules depending on deployment requirements. This modular approach allows system administrators to customize connectivity for short range or long range transmission without changing the base network adapter hardware. The Intel X710-DA4FH supports a wide range of compatible SFP+ modules, enabling integration into diverse network topologies.

In high density server environments, SFP+ based connectivity is preferred due to its compact form factor and high bandwidth capability. This adapter supports structured cabling designs where servers connect directly to top of rack switches using fiber or copper interconnects. Such configurations reduce network congestion and simplify infrastructure maintenance in large enterprise data centers.

PCI Express Interface and System Integration Efficiency

The PCI Express interface used in this converged network adapter ensures compatibility with a wide range of modern server platforms. It delivers high speed data transfer between the network controller and system memory, enabling efficient handling of large packet streams. The architecture is designed to take advantage of multiple PCIe lanes, ensuring that network throughput is not constrained by bus limitations.

System integrators benefit from simplified deployment since the adapter is designed to operate seamlessly with standard server motherboards that support PCIe expansion slots. This reduces the need for specialized hardware configurations and allows rapid scaling of network capacity across multiple nodes in a data center environment.

Virtualization Acceleration and Multi Tenant Networking

One of the defining characteristics of the Intel X710-DA4FH is its advanced support for virtualization technologies. It is designed to operate efficiently within environments using hypervisors such as VMware, KVM, and Hyper-V. Through hardware assisted virtualization features, the adapter supports multiple virtual machine traffic flows without significant performance degradation.

Single Root Input Output Virtualization enables the adapter to present multiple virtual functions to the host system, allowing network traffic to be distributed directly to virtual machines with minimal software overhead. This reduces latency and improves network determinism in multi tenant cloud environments where isolation and performance consistency are critical.

The adapter also supports advanced packet steering and traffic classification mechanisms that ensure efficient distribution of workloads across CPU cores. This is particularly important in large scale virtualization clusters where network performance directly impacts application responsiveness.

Advanced Offloading Capabilities and CPU Utilization

Modern server workloads require efficient utilization of CPU resources, and the Intel X710-DA4FH addresses this requirement through a wide range of hardware offloading features. These offloads reduce the processing burden on host CPUs by handling repetitive network tasks directly within the network controller hardware.

Capabilities such as TCP segmentation offload, checksum offload, and large receive offload significantly improve throughput while minimizing system overhead. These features are particularly beneficial in environments running high bandwidth applications such as distributed storage systems, database replication, and real time analytics platforms.

By reducing CPU involvement in packet processing, more computational resources are made available for application workloads, improving overall system efficiency and reducing infrastructure scaling costs.

Data Center Networking and High Density Deployment

The Intel X710-DA4FH is particularly well suited for dense data center environments where space efficiency and performance consistency are critical. Its quad port configuration allows a single adapter to serve multiple network segments, reducing the number of physical cards required per server. This is especially valuable in blade server systems and rack optimized deployments where PCIe slot availability is limited.

In modern cloud infrastructure, network traffic patterns are highly dynamic and often involve east west communication between virtualized workloads. The adapter is designed to handle these traffic patterns efficiently, ensuring low latency communication between compute nodes, storage arrays, and application layers.

High throughput environments such as media streaming platforms, financial trading systems, and large scale analytics clusters benefit from the adapter’s ability to sustain consistent 10 Gigabit performance across multiple simultaneous connections.

Storage Networking and High Speed Data Transfer

In addition to general purpose networking, the Intel X710-DA4FH is widely used in storage intensive environments. Storage area networks and network attached storage systems rely on stable and high bandwidth connectivity to ensure fast data access and replication. The adapter’s low latency design and high throughput capability make it suitable for such workloads.

It supports efficient handling of large data blocks, which is critical for backup systems, disaster recovery solutions, and distributed storage architectures. When deployed in conjunction with high performance storage servers, the adapter helps maintain consistent data transfer rates even under heavy concurrent access conditions.

Network Virtualization and Software Defined Infrastructure

Software defined networking environments require network adapters that can adapt to dynamically changing traffic rules and virtual network overlays. The Intel X710-DA4FH supports encapsulation and decapsulation offloads that are essential for modern overlay networks such as VXLAN and GRE tunneling.

This capability enables efficient operation in cloud platforms where network virtualization is used to separate tenant traffic and create isolated network segments over shared physical infrastructure. The adapter ensures that encapsulated traffic is processed efficiently without introducing performance bottlenecks.

Packet Processing Optimization and Low Latency Performance

Low latency is a critical requirement in environments such as high frequency trading, real time communication systems, and interactive cloud applications. The Intel X710-DA4FH is designed to minimize packet processing delays through optimized hardware architecture and efficient queue management.

Multiple transmit and receive queues allow parallel processing of network traffic, which reduces contention and improves overall responsiveness. This design is particularly effective in multi core server systems where workload distribution across processing units is essential for performance scaling.

Reliability and Enterprise Grade Stability

Enterprise networking environments demand consistent reliability and long term operational stability. The Intel X710-DA4FH is engineered with robust hardware components and firmware optimization to ensure continuous uptime under heavy workloads. Thermal management design ensures stable performance even in high density rack configurations where heat accumulation is a concern.

Error handling mechanisms and link monitoring features contribute to improved network resilience. In the event of link fluctuations or transient network issues, the adapter is capable of maintaining session stability and quickly recovering connectivity without disrupting ongoing services.

Cloud Infrastructure and Hyperscale Deployment

Hyperscale data centers require network adapters that can scale efficiently across thousands of compute nodes. The Intel X710-DA4FH is frequently deployed in such environments due to its ability to deliver predictable performance and support virtualization at scale. Its quad port design allows multiple network paths, improving redundancy and load balancing across distributed systems.

Cloud service providers rely on such adapters to maintain service level agreements for latency, bandwidth, and uptime. The combination of hardware offloads and virtualization support ensures that large scale workloads can be executed without network congestion or performance degradation.

Compatibility with Modern Server Platforms and Integration Flexibility

This converged network adapter is designed to integrate with a wide range of server architectures, including rack mounted systems, blade servers, and custom enterprise hardware configurations. Its PCI Express interface ensures broad compatibility with contemporary server motherboards.

Operating system support typically includes major enterprise distributions and virtualization platforms, enabling seamless deployment across heterogeneous environments. This flexibility makes it suitable for organizations that operate mixed infrastructure environments with varying hardware generations.

Scalability and Future Proof Network Design

As network demands continue to grow, scalability becomes a key requirement for infrastructure planning. The Intel X710-DA4FH is designed with forward compatibility in mind, supporting evolving networking standards and virtualization technologies. Its architecture allows integration into both current and next generation data center designs.

Organizations investing in this type of adapter benefit from long term usability, as it supports high bandwidth requirements and advanced networking features that remain relevant in evolving IT environments. This makes it a strategic choice for infrastructure modernization initiatives.
