N7K-C7010-FAN-S Cisco Nexus 7000 10 Slot Sys Fan

Cisco N7K-C7010-FAN-S Nexus 7000 10 Slot System Fan

The N7K-C7010-FAN-S is a spare fan module designed for the Cisco Nexus 7010 Switch. It provides efficient front-to-back airflow to maintain optimal operating temperatures. The module is hot-swappable, allowing replacement without interrupting network operations. It helps ensure reliable cooling, improves system stability, and supports continuous data center performance.

General Information

• Manufacturer: Cisco
• Part Number: N7K-C7010-FAN-S
• Device Type: Cooling Fan Tray

Technical Specifications

• System fan tray engineered for Cisco Nexus 7000 Series
• Designed for Cisco Nexus 7010 (10-Slot) chassis
• Provides cooling airflow for supervisor modules, line cards, fabric modules, and power supplies
• High-performance cooling with hot-swappable capability
• Front-access, tool-less installation for quick replacement
• Supports replacement without powering off the chassis
• Operates within a redundant cooling architecture
• Two system fan trays required per Cisco Nexus 7010 chassis
• Power Consumption: Typical 300 W per tray; maximum up to 2184 W combined

Compatibility

Supported Chassis

• Compatible only with Cisco Nexus 7010 (N7K-C7010) chassis
• Not compatible with Cisco Nexus 7004, 7009, 7018, 7700, or Nexus 9000 Series

Supervisor Modules

• N7K-SUP1
• N7K-SUP2
• N7K-SUP2E

Line Cards & Fabric Modules

• Works with all supported Cisco Nexus 7010 line cards
• Compatible with fabric modules installed in the chassis

Cooling System Integration

• Operates together with N7K-C7010-FAN-F (Fabric Fan Tray)
• Part of the complete cooling system architecture
• Cannot be used as a standalone fan module

Operational Excellence

• Designed for continuous 24×7 data center operation
• Authentic Cisco replacement system fan tray
