N9K-C9508-FAN Cisco Fan Tray for Nexus 9508 Chassis FD

Cisco Nexus 9508 Chassis Cooling Module

The Cisco N9K-C9508-FAN is engineered to provide consistent cooling for the Cisco Nexus 9508 chassis. Designed for cloud-scale networking environments, this fan assembly supports mission-critical operations by delivering efficient airflow and maintaining proper operating temperatures for installed hardware components.

General Information

• Manufacturer: Cisco
• Part Number: N9K-C9508-FAN
• Product Type: Fan Tray

Technical Specifications

• Airflow Direction: Port-side intake (Front-to-Back)
• Cooling Design: High-efficiency airflow for continuous operation
• Installation Location: Rear fan assembly compartment
• Dedicated Fan Slots: 3 fan assembly bays
• Slot Requirement: Occupies one dedicated fan tray slot
• Designed for: Quick replacement and maintenance

Power and Performance

• Typical Power Consumption: 176 Watts
• Energy-Efficient Cooling: Supports continuous enterprise workloads
• Optimized Thermal Performance: Maintains stable operating temperatures

Compatibility

• Compatible Chassis: Cisco Nexus 9508
• Purpose-built for 8-slot modular switch architecture
• Provides reliable thermal management for high-density deployments

Physical Characteristics

• Weight: Approximately 9.59 lbs (4.4 kg)
• Construction: Durable enterprise-grade design
• Form Factor: Dedicated modular fan tray

Environmental Conditions

• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Designed For: Standard enterprise and data center environments
• Reliable Operation: Supports continuous network availability
