CPAK-100G-LR4 Cisco 100GBase-LR4 Ethernet Transceiver SMF

Cisco CPAK-100G-LR4 100Gbps Transceiver Module Overview

The Cisco CPAK-100G-LR4 is a high-performance optical transceiver engineered for next-generation data center and enterprise networking environments. Designed by but must use entity for Cisco: :content Reference[oaicite:0]{index=0}, this module delivers ultra-fast 100 Gigabit Ethernet connectivity over single-mode fiber, ensuring reliable long-distance transmission with exceptional signal integrity and energy efficiency.

General Information

• Type: Optical Transceiver Module
• Application: Data centers, enterprise backbone networks
• Deployment: Long-reach single-mode fiber connectivity

Technical Specifications

• Supports 100G Ethernet throughput
• Optimized for low latency and high stability
• Reliable performance in dense networking environments

IEEE and Industry Compliance

• IEEE 802.3ba (100GBASE-LR4) compliant
• ITU-T OTU4 protocol support
• Designed for carrier-grade infrastructure compatibility

Wavelength Distribution

• 1295.56 nm
• 1300.05 nm
• 1304.58 nm
• 1309.14 nm

Fiber Characteristics

• Core size: 9-micron single-mode fiber
• Duplex LC optical interface
• Optional SC connector variant (depending on deployment)

Operational Range Features

• Minimum cable requirement: 2 meters
• Ideal for inter-building and metro connectivity
• Stable performance in high-traffic networks

Optical Power Specifications

• Transmit power: up to +4.5 dBm per lane
• Minimum transmit power: -4.3 dBm per lane
• Receive sensitivity range: -10.6 dBm to +4.5 dBm per lane

Power Characteristics

• Typical power usage: under 5.5 Watts
• Maximum power consumption: less than 8.0 Watts at 70°C
• Enhanced thermal stability for continuous operation

Monitoring Parameters

• Temperature tracking
• Supply voltage monitoring
• Laser bias current measurement
• Optical power level analysis

Dimensional Specifications

• Size: 11.6 mm x 34.8 mm x 101.2 mm
• Optimized for space-saving deployments
• High-density port compatibility

Cisco CPAK-100G-LR4 100GBASE-LR4 Transceiver Module

The Cisco CPAK-100G-LR4 100GBPS Transceiver Module Single Mode Optical Fiber is a high-performance optical networking component designed for next-generation data center, enterprise backbone, and service provider infrastructures requiring ultra-high bandwidth transmission over long distances. This 100GBASE-LR4 optical module belongs to Cisco’s CPAK form factor family, engineered to deliver compact, energy-efficient, and scalable 100 Gigabit Ethernet connectivity over single-mode fiber (SMF). It is widely used in modern high-density switching environments where long-range optical communication, signal stability, and low latency are critical for mission-critical workloads and cloud computing ecosystems.

CPAK Form Factor Engineering

The CPAK form factor is specifically designed by Cisco to provide a balance between port density and power efficiency. Compared to earlier generations of optical transceivers, the CPAK-100G-LR4 reduces power consumption while maintaining high throughput performance. Its compact architecture allows network engineers to deploy more 100G ports within the same physical switch footprint, which is essential for hyperscale data centers and high-performance computing clusters.

100GBASE-LR4 Transmission Technology

The LR4 specification refers to long reach optical transmission using four separate wavelengths operating over single-mode fiber. Each wavelength carries a 25Gbps data stream, which is multiplexed to form a full 100Gbps Ethernet channel. This wavelength division multiplexing (WDM) approach ensures efficient signal distribution and minimizes interference across long-distance links, typically reaching up to 10 kilometers depending on fiber quality and network conditions.

Single Mode Fiber Optimization

The module is optimized for single-mode optical fiber infrastructure, which is essential for long-distance communication in metropolitan area networks and inter-data center connectivity. Single-mode fiber allows light to travel in a single path, reducing dispersion and ensuring higher signal integrity over extended distances. The CPAK-100G-LR4 leverages this advantage to maintain consistent throughput and minimal packet loss across complex network topologies.

Key Functional Characteristics of Cisco CPAK-100G-LR4

The primary strength of the Cisco CPAK-100G-LR4 lies in its ability to support 100 Gigabit Ethernet speeds, which significantly enhances data transfer capabilities across enterprise and cloud environments. This performance is essential for applications involving large-scale virtualization, cloud computing workloads, big data analytics, and high-frequency trading systems where ultra-low latency is required.

Low Power Consumption Design

Energy efficiency is a critical consideration in modern networking infrastructure. The CPAK-100G-LR4 is engineered to consume significantly lower power compared to older 100G modules, helping reduce operational costs in large-scale deployments. This efficient power profile also contributes to lower heat generation, improving overall system reliability and cooling efficiency within densely packed network racks.

Enhanced Signal Integrity

The module incorporates advanced optical signal processing mechanisms that ensure high signal-to-noise ratios across long-distance transmissions. This reduces the likelihood of errors, retransmissions, and network congestion. As a result, it ensures stable communication between core routers, aggregation switches, and distributed data center nodes.

Data Center Interconnect (DCI)

One of the most prominent applications of the CPAK-100G-LR4 module is in data center interconnect architectures. It enables seamless communication between geographically separated data centers, ensuring synchronized data replication, disaster recovery, and load balancing across distributed systems. The long-reach capability makes it suitable for metro and regional interconnectivity.

Enterprise Backbone Networks

Large enterprises rely on robust backbone networks to support internal communications between departments, branch offices, and cloud systems. The 100G capability of this transceiver ensures that enterprise networks can handle increasing bandwidth demands driven by digital transformation initiatives, unified communications, and enterprise resource planning systems.

Cloud Computing and Hyperscale Infrastructure

Cloud service providers deploy CPAK-100G-LR4 modules in high-density switch environments to support virtualization, container orchestration, and distributed computing workloads. The high throughput ensures efficient resource allocation and fast data access across virtual machines and storage clusters.

Telecommunication Networks

Telecom operators use this optical module to support backbone transmission layers and aggregation networks. It helps maintain high-speed connectivity between core network nodes while supporting increasing consumer demand for video streaming, mobile data, and real-time communication services.

Technical Performance and Optical Specifications

The LR4 module operates using four distinct wavelengths typically within the 1310nm range. Each wavelength carries an independent 25Gbps signal, which is combined and transmitted over a single-mode fiber strand. This multiplexing approach significantly enhances bandwidth efficiency while maintaining signal clarity over long distances.

Transmission Distance Capabilities

The Cisco CPAK-100G-LR4 is optimized for long-reach transmission distances, typically up to 10 kilometers over standard single-mode fiber. This makes it suitable for inter-building, metro, and campus-wide deployments where high-speed connectivity must be maintained across extended physical separation.

Latency Optimization

Low latency is a critical requirement in modern networking, particularly for applications such as financial trading systems and real-time analytics. The CPAK-100G-LR4 minimizes transmission delays by optimizing optical conversion processes and reducing processing overhead within the module itself.

Compatibility with Cisco Networking Equipment

The CPAK-100G-LR4 is designed for seamless integration with Cisco networking hardware, including high-end switches and routers that support CPAK interfaces. This ensures plug-and-play compatibility and reduces configuration complexity during deployment.

Network Scalability

This optical module plays a critical role in scalable network design. As organizations grow and bandwidth requirements increase, CPAK-100G-LR4 modules enable smooth upgrades without requiring complete infrastructure redesigns. This scalability is particularly valuable in cloud-native environments and evolving enterprise networks.

Infrastructure Planning and Fiber Requirements

Proper deployment requires careful planning of single-mode fiber infrastructure. Factors such as fiber quality, connector cleanliness, and splice integrity directly affect performance. Ensuring optimal physical layer conditions enhances the module’s efficiency and extends its operational lifespan.

Reliability in Critical

The module is designed for environments where downtime is not acceptable. Its robust construction, stable optical performance, and error correction capabilities make it suitable for industries such as banking, healthcare systems, government networks, and cloud infrastructure providers.

Maintenance, Monitoring

Network administrators can monitor optical performance metrics such as signal strength, temperature, and error rates to ensure optimal functioning. Continuous monitoring helps detect potential issues before they impact network performance.

Preventive Maintenance Practices

Maintaining fiber cleanliness and ensuring proper module handling are essential for long-term reliability. Preventive maintenance routines help reduce degradation and extend the operational life of both the module and the fiber infrastructure.

Lifecycle Efficiency

The CPAK-100G-LR4 is designed for long operational lifecycles, making it suitable for stable infrastructure deployments. Its durability ensures consistent performance over extended periods, even in high-demand environments.

Future-Ready Networking

As global data consumption continues to increase, optical networking technologies like the CPAK-100G-LR4 serve as foundational components for transitioning toward even higher-speed networks such as 400G and beyond. Its architecture provides a stepping stone for future scalability.

Role in Cloud and AI Infrastructure

Modern artificial intelligence workloads and cloud computing systems require extremely high data throughput. The CPAK-100G-LR4 supports these environments by ensuring fast and reliable data movement across distributed compute nodes and storage systems.
