MA-ANT-23 Cisco Meraki 2.4GHz 11 dBi Wireless AP Sector Antenna

Cisco MA-ANT-23 Meraki High-Performance Sector Antenna

Enterprise-Grade Wireless Network Enhancement Solution

The Cisco MA-ANT-23 is a professional-grade sector antenna designed to strengthen and optimize wireless network coverage in demanding environments. Built under the Cisco Meraki ecosystem, this antenna supports high-efficiency signal distribution for modern enterprise connectivity requirements.

Key Product Identification Details

• Brand: Cisco
• Model / SKU: MA-ANT-23
• Category: Networking Hardware
• Device Type: Wireless Access Point Antenna

Advanced Electrical Performance Specifications

Optimized Frequency and Signal Strength

Engineered for stable and high-capacity wireless transmission, the antenna delivers efficient coverage across supported frequency bands with enhanced gain performance.

Core Electrical Characteristics

• Antenna Design: Sector-style radiation pattern
• Operating Frequency Range: 5.150 – 5.875 GHz
• Antenna Gain: 13 dBi for improved signal reach
• Beamwidth (Horizontal): 80° half-power coverage angle
• Polarization Modes: Linear (Vertical and Horizontal support)

Physical Build and Environmental Durability

Rugged Construction for Outdoor Deployment

Designed for long-term use in outdoor and industrial environments, the Cisco MA-ANT-23 features a durable structure with weather-resistant materials that ensure consistent performance under harsh conditions.

Material and Structural Features

• UV-resistant reinforced plastic housing for sun protection
• Compact and lightweight build for flexible installation

Dimensions and Weight Details

• Size: 9.2 x 5.5 x 1.6 inches (233 mm x 140 mm x 40 mm)
• Weight: 1.2 lbs (approximately 527 g)

Connectivity and Installation Interface

Dual Connector Configuration for Reliable Integration

The antenna includes dual N-type connectors, enabling secure and stable integration with compatible Cisco wireless access point systems.

Connector Specifications

• 2 x N-type connector interfaces for robust RF connection
• Designed for compatibility with enterprise-grade wireless deployments

Environmental Operating Conditions

Adaptability Across Extreme Temperatures

This antenna is engineered to function efficiently in both freezing and high-temperature environments, ensuring uninterrupted connectivity across diverse geographical locations.

Temperature Resistance Range

• Minimum operating temperature: -40°F (-40°C)
• Maximum operating temperature: 158°F (70°C)

Use Cases and Deployment Advantages

Ideal Applications for Wireless Infrastructure Expansion

The Cisco MA-ANT-23 is widely used in enterprise networking environments requiring directional signal enhancement and expanded wireless coverage zones.

Common Deployment Scenarios

• Campus-wide wireless network expansion
• Outdoor access point installations
• High-density enterprise connectivity zones
• Industrial and warehouse network setups

Performance Benefits Summary

• Improved directional signal strength
• Reduced network interference
• Enhanced long-range wireless stability
• Reliable performance in harsh environmental conditions
