MA-ANT-3-C5 Meraki Cisco Indoor Dual-Band Omni Antenna, 5-Port

Cisco Meraki MA-ANT-3-C5 Indoor Dual-Band Omni Antenna

Product Overview and Identification

Core Specifications

• Manufacturer: Cisco
• Model / SKU: MA-ANT-3-C5
• Category: Networking Hardware
• Subtype: Indoor Omni-Directional Antenna
• Configuration: 5-Port antenna array

Deployment Use Cases

• Engineered for enterprise-grade Wi-Fi infrastructures
• Ideal for offices, campuses, and commercial indoor environments
• Supports high-density client connectivity scenarios

Wireless Performance and Frequency Support

Dual-Band Frequency Coverage

• 2.4 GHz band: 2.400 – 2.500 GHz for extended range
• 5 GHz band: 5.150 – 5.875 GHz for faster data throughput

Signal Gain Capabilities

• Consistent gain per element: 4.9 dBi on both 2.4 GHz and 5 GHz bands
• Balanced performance for stable and reliable wireless coverage

Radiation Pattern and Beamwidth

• Horizontal coverage: Omni-directional for 360° signal distribution
• Vertical beamwidth: 60° for focused vertical propagation

Polarization and Signal Behavior

Transmission Characteristics

• Linear polarization ensures consistent signal integrity
• Supports both vertical and horizontal orientation
• Enhances compatibility with diverse wireless client devices

Cabling and Connectivity

Integrated Cable Details

• Includes high-quality Times AA-9303 cables
• Cable length: 1 meter for flexible installation

Connector Interface

• RP-TNC connectors for secure and stable attachment
• Ensures compatibility with supported Cisco Meraki access points

Mounting Flexibility and Installation Options

Supported Mounting Methods

• Wall mounting for structured indoor deployment
• Pole installation for elevated positioning
• Ceiling tile integration for discreet setups

Additional Mounting Accessories

• Flush-mount kit included for seamless installation
• Optional surface and pipe mounting kits available separately

Physical Dimensions and Build Quality

Size and Weight Specifications

• Dimensions: 11.81” x 1.38” (300 mm x 35 mm)
• Weight (C5): 34.39 oz (0.98 kg)
• Weight (C6): 37.04 oz (1.05 kg)

Construction Materials

• Manufactured using durable PC-ABS composite material
• Provides excellent resistance to heat and mechanical stress

Environmental Operating Conditions

Temperature and Humidity Range

• Operating temperature: 0°C to 40°C (32°F to 104°F)
• Humidity tolerance: 5% to 95% non-condensing

Key Advantages for Network Optimization

Performance Benefits

• Ensures uniform signal propagation across indoor spaces
• Reduces interference and dead zones in dense environments
• Supports consistent performance for multiple connected devices

Design Efficiency

• Slim, low-profile form factor for unobtrusive installation
• Versatile mounting options for diverse deployment scenarios
• Optimized for seamless integration with Cisco wireless ecosystems
